SLC TTS2A Ball Plunger Machine IP67 UL Thermoplastics 1C CE CCC CQC
Piece
Negotiable
Product information
High-quality SLC TTS2A Ball Plunger Machine IP67 UL Thermoplastics 1C CE CCC CQC supplied by Shenzhen Tongchuang Mechatronics Co., Ltd.. Bulk wholesale pricing is negotiable. Inquiry for latest prices.
Package Gross Weight:
0.150kg
Package Size:
50.00cm * 40.00cm * 30.00cm
Safety Certificated:
CE CCC(CQC)
Origin:
China
Refund Policy:
Claim a refund if your order doesn't ship, is missing, or arrives with product issues.
Shipping Cost:
Contact the supplier about freight and estimated delivery time.
Trade Term:
FOB, EXW, CFR, CIF, DDP, DAP, FCA
Protection Grade:
IP67
Specifications
Package Gross Weight:
0.150kg
Package Size:
50.00cm * 40.00cm * 30.00cm
Safety Certificated:
CE CCC(CQC)
Origin:
China
Refund Policy:
Claim a refund if your order doesn't ship, is missing, or arrives with product issues.
Shipping Cost:
Contact the supplier about freight and estimated delivery time.
Trade Term:
FOB, EXW, CFR, CIF, DDP, DAP, FCA
Protection Grade:
IP67
Payment Term:
LC, T/T, D/P, PayPal
Trademark:
SLC
Trigger Method:
See Production Selection Guide
Port Of Loading:
Shenzhen, Guangzhou, Dongguan
Payment Methods:
Support payments in USD
Material:
UL Thermoplastics Function Features
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
2015-12-25
Annual Revenue Amount:
Not specified
Numbers Of Employees:
Not specified
Preferred Payment Term:
LC, T/T, D/P, PayPal
Preferred Trade Term:
FOB, EXW, CFR, CIF, DDP, DAP, FCA
Port Of Loading:
Shenzhen, Guangzhou, Dongguan
Certificates:
CE-Door lock TRL2, CE-TUV Safety Light Curtains, CE-TUV Safety Relay, certificate, certificates, CQC, EU LCM, ISO 14001-2015, ISO 9001-2015, OBS, SLC Light Curtain, Vehicle Separation Gratings
Product descriptions from the supplier
Function Features:
The TTS2 safety switch uses a key, roller plunger, ball plunger, hinged trigger A sensor placed at the switch housing to monitor protective door motion. Features include small footprint, lightweight design, multiple contact setups, and various actuation mechanisms.
Products certification
Company Cooperative units
Q: Can i get some samples ?/Do you offer samples available?
A:We can send a sample, but the customer is responsible for the sample fee. Once you're satisfied and place a follow-up bulk order, we’ll cover the sample cost.
Q: How is the warranty?
A:The product comes with an 18-month guarantee. Should any quality issues arise during this period, kindly send it back to us for servicing; if repair is not feasible, we will replace it with a fresh unit. However, damages caused by user error, incorrect usage, or unforeseen circumstances are not covered. You are responsible for return shipping fees, while we will cover the cost of sending the item back to you.
Q:How about the quality of the products?
A:we have the certification of CE,CCC,CQC,EU,TUV,UL, and products Safety Level archived Ple,SIL,Type 4,Cat.4 etc.
Q: What is the quality guarantee?
A:Fully compliant with ISO 9001-2015 and ISO 14001-2015 standards, we maintain a rigorous quality assurance process. In addition to calibration, every product set undergoes extended aging testing prior to dispatch, ensuring consistent performance and reliability.
Q: Do you have any products in stock?
A: Depend on the order quantity.
Q: Can I be your distributor?
A: Yes, we are looking for distributors in oversea market.
The TTS2 safety switch uses a key, roller plunger, ball plunger, hinged trigger A sensor placed at the switch housing to monitor protective door motion. Features include small footprint, lightweight design, multiple contact setups, and various actuation mechanisms.
| Switch Safety level | |
| Standard | EN60947-5-1/GB/T14048.5 |
| Security classification | Dual-channel interlocking is suitable for class 3 or Class 4 systems |
| B10D | 1 million times |
| Certification | CE CCC(CQC) |
| Mechanical life | More than 1 million |
| Electrical life | More than 1 million |
| Electrical characteristics | |
| Rated insulation voltage (Ui) | Rated insulation voltage (Ui)300V |
| Protection level against electric shock | Class II (double insulation) |
| Pollution degree (operating environment) | 3(EN60947-5-1) |
| Pulse voltage withstand (EN60947-5-1) | 2.5KV |
| Contact resistance | Below 25mΩ |
| Insulation resistance | Below 100mΩ |
| Rated open heating current (lth) | 10A |
| Conditional short-circuit current | 100A |
| Contact spacing | 2.5mm |
| Operating characteristics | |
| Minimum power | 15N |
| Maximum execution speed | 160mm/s |
| Maximum execution frequency | 2 cycles per second |
| Minimum switching current at a specified voltage | 5mA@5VDC |
| Contact type | |
| Safety contact | 2-way NC 1- way NC |
| Auxiliary contact | 1 way NO |
| Type of use | |
| Load class | AC-15 DC-13 |
| Rated operating voltage (Ue) | 230V 24V |
| Rated operating current (Le) | 4A |
| Environment | |
| Housing protection class | Ip67 |
| Operating temperature | -20~+80ºC |
| Use environment | Below 95% |
| Vibration resistance | 10-55Hzunilateralamplitude 0.75mm |
| Stamping resistance | 300m/s2 |
| Material | |
| weight | About 200g |
| Shell material | The thermoplastic is UL certified |
| Execution materials | SUS304 |
