Secure 5G Supported Routers with Stateful Firewall and MAC Filtering
1 Set
$1851 Set
$295Product information
High-quality Secure 5G Supported Routers with Stateful Firewall and MAC Filtering supplied by Shenzhen E-Lins Communication Co., Limited. Bulk wholesale pricing ranges from $185 to $295 per Set with a minimum order of 1 Set. Inquiry for latest prices.
SIM Card Slot:
1
RJ45:
1 x GE WAN, 1 x GE LAN
Transfer Rate:
10/100/1000Mbps
WiFi:
2.4/5 GHz, up to Wi-Fi6/Wi-Fi7
DI / DO:
4 x DI / DO
Power:
5-40V (Option 5-60V)
Production Capacity:
50, 000PCS/Month
Specification:
5G Cellular
Specifications
SIM Card Slot:
1
RJ45:
1 x GE WAN, 1 x GE LAN
Transfer Rate:
10/100/1000Mbps
WiFi:
2.4/5 GHz, up to Wi-Fi6/Wi-Fi7
DI / DO:
4 x DI / DO
Power:
5-40V (Option 5-60V)
Production Capacity:
50, 000PCS/Month
Specification:
5G Cellular
Network:
5G NR SA & NSA
HS Code:
8517629900
Case:
Alloy Metal
Transport Package:
Box
Certificates:
CE, RoHS, UKCA, FCC, UL, TUV, RU, Anatel, etc.
Management:
E-Lins NMS, Web, SMS, SSH, Telnet, Command, SNMP
Trademark:
E-Lins, OEM, ODM, Neutral
Application:
Enterprise, Industrial
Antenna:
External Replaceable
Trade Term:
FOB
Firewall:
Firewall
GNSS:
Galileo, GPS, Beidou, Glonass
Model NO.:
H685f-W-RS232-G-P1
VPN:
IPSec, Openvpn, Zerotier, PPTP, L2TP, Wireguad
Class:
Industrial 5G Router
Performance:
Line-Rate Router
Port Structure:
Modular
Din Rail:
Optional
PoE:
PoE PD
Serial:
RS232 or RS485
Origin:
Shenzhen, China
Architecture:
Single Bus Master-slave CPU
Payment Term:
To be discussed
Ports:
≤4
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
Not specified
Annual Revenue Amount:
Not specified
Numbers Of Employees:
Not specified
Preferred Payment Term:
Not specified
Preferred Trade Term:
FOB
Port Of Loading:
Not specified
Certificates:
RoHS
Product descriptions from the supplier
SONA2024 2.2.1
E-Lins IoT / M2M products are widely used in industrial fields, such as CCTV, finance, ATM, kiosk, vending machine, power control, water schedule, traffic, oil field, weather forecast, environmental protection, street lamp control, post, bank and many other areas.
Main
Series No. | H685 |
P/N | H685f-W-RS232-G-P1 |
Class | Industrial for M2M, IoT, and in-vehicle use |
Cellular | 5G NR, SA, NSA, fall back to 4G, 3G |
WAN | 1 * GE |
LAN | 1 * GE (Can be configured as LAN) |
Digital Input / Output | 4 * DI / DO |
PoE | Active PoE PD |
GNSS | GPS, Galileo, GLONASS, Beidou |
Serial | With DTU feature (Serial to Cellular Gateway feature, RS232) |
WiFi | 802.11n: 300Mbps 2.4GHz/5GHz, Access Point (AP), Station (STA), Client. |
VPN | OpenVPN, IPsec, GRE, PPTP, L2TP, DMVPN, ZeroTier, WireGuard, others. |
Network Backup | Cellular WAN, Wi-Fi WAN, VRRP, Wired options, each can be used as an automatic Failover |
Load Balancing | Balance Internet traffic over multiple WAN connections |
Monitoring & Management | WEB UI, FOTA, SSH, TR-069, MQTT, SNMP, JSON-RPC, E-Lins Network Management System (NMS) |
Antennas | External style, replaceable for high gain |
Installation | Desktop, Wall-mount, Din-Rail |
Wide Power-in | DC5-40V, DC5-60V optional |
E-SIM | Optional |
Trademark | E-Lins, Neutral, OEM, ODM and other customization |
E-Lins IoT / M2M products are widely used in industrial fields, such as CCTV, finance, ATM, kiosk, vending machine, power control, water schedule, traffic, oil field, weather forecast, environmental protection, street lamp control, post, bank and many other areas.
The E-Lins H685 series is a compact, ruggedized 5G/4G/3G cellular networking solution designed for mission-critical connectivity in the most challenging environments. It is qualified for M2M (Machine to Machine), IoT (Internet of Things) and In-Vehicle applications. Super mini size suitable for embedding applications.
Support VPN, Port forwarding, DMZ, DDNS, remote control, and optimized EMC design, highly stable and reliable.
The H685 series is a professional Ethernet router.
This professional router combines the best of wired and wireless routing functionalities with Fast Ethernet and advanced remote management capabilities, along with numerous supported security and networking protocols, making H685 an ideal choice for professional applications.
This professional router combines the best of wired and wireless routing functionalities with Fast Ethernet and advanced remote management capabilities, along with numerous supported security and networking protocols, making H685 an ideal choice for professional applications.
Features
ETHERNET | |
WAN | 1 x WAN port 10/100/1000 Mbps, can be set as LAN Ethernet |
LAN | 1 x LAN port, 10/100/1000 Mbps |
WIRELESS | |
Wireless mode | Optional. 802.11b/g/n/ac/ax (Wi-Fi 4/5/6), Access Point (AP), Station (STA), Client. |
Wi-Fi security | WPA2-Enterprise: PEAP, WPA2-PSK, WPA-EAP, WPA-PSK, WPA3-SAE, WPA3-EAP, OWE; AES-CCMP, TKIP, Auto-cipher modes, client separation, EAP-TLS with PKCS#12 certificates, disable auto-reconnect, 802.11w Protected Management Frames (PMF) |
Wi-Fi users | Up to 64 simultaneous connections |
Wireless MAC filter | Allowlist, blocklist |
SECURITY | |
Main | Authentication, SSL, RADIUS and TACACS+; 802.1x authentication for Ethernet, VLAN |
Attack prevention | DDOS prevention, port scan prevention |
WEB filter | Blacklist for blocking out unwanted websites, Whitelist for specifying allowed sites only |
Access control | Flexible access control of SSH, Web interface, CLI, and Telnet |
Firewall | Preconfigured firewall rules can be enabled via WebUI, unlimited firewall configuration via CLI, DMZ, NAT, NAT-T, NAT64 |
Monitoring & Management | |
WEB UI | HTTP/HTTPS, status, configuration, FW update, CLI, troubleshoot, multiple event log servers, firmware update availability notifications, event log, system log, kernel log, Internet status |
NMS | E-Lins Enterprise Batch Network Management System (NMS) |
Others | API, CLI/SSH/Telnet Data Usage Alerts (router and per client) Advanced Troubleshooting (support) Device Alerts SNMP SMS control TR-069 FOTA MQTT |
NETWORK | |
Routing | Static routing, Dynamic routing (BGP, OSPF v2, RIP v1/v2, EIGRP, NHRP), Policy based routing |
Network protocols | TCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, SFTP, FTP, SMTP, SSL/TLS, ARP, VRRP, PPP, PPPoE, UPNP, SSH, DHCP, Telnet, SMPP, SNMP, MQTT, Wake On Lan (WOL), VXLAN |
Firewall | Port forward, traffic rules, custom rules, TTL target customisation |
Firewall status page | View all your Firewall statistics, rules, and rule counters |
Hotspot | Captive portal (hotspot), internal/external Radius server, Radius MAC authentication, SMS authorisation |
DHCP | Static and dynamic IP allocation, DHCP relay, DHCP server configuration, status, static leases: MAC with wildcards |
Network backup | Wi-Fi WAN, VRRP, Wired options, each of which can be used as an automatic Failover |
Others | Traffic management, load balancing, DNS over HTTPS, QoS, MQTT, DNP3 |
MODBUS | |
Supported modes | Server, Client |
Supported connection types | TCP, USB |
Firmware / Configuration | |
WEB UI | Update FW from file, check FW on server, configuration profiles, configuration backup |
OTA WAN | Update FW remotely |
NMS | Update FW/configuration for multiple devices at once |
Keep settings | Update FW without losing current configuration |
Factory settings reset | A full factory reset restores all system settings, including the IP address, PIN, and user data to the default manufacturer's configuration |
INPUT / OUTPUT | |
DI / DO | 4 x Digital Input or Output. 0-3.3V |
Events | Status monitor via SMS and Email |
E-Lins switch control board | 5-40VDC supported |
POWER | |
Connector | Terminal DC Adapter |
Input voltage range | 5 - 40 V DC; Option 5 -60V DC. |
PoE (PD) option | Possibility to power up through LAN port, compatible with IEEE802.3af, 802.3at and 802.3bt standards |
PHYSICAL INTERFACES | |
Ethernet | 2 x RJ45 ports, 10/100/1000 Mbps |
DI / DO | 4 x Digital Input or Output on 10-pin terminal connector |
Status LEDs | 1 x LAN 1 x WAN 1 x WIFI 1 x CELL 1 x SIGNAL 1 x VPN 1 x SYS |
Power | 1 x DC power connector 1 x Terminal connector |
Antennas | 2 ~ 6 CELL 2 x WIFI (for models with WiFi feature) 1 x GPS (for models with GPS feature) 1 x Serial Cable (for models with Serial feature) Replaceable connectors |
Reset | Reboot/User default reset/Factory reset button |
PHYSICAL SPECIFICATION | |
Casing material | Aluminium housing |
Dimensions (W x H x D) | PCBA: 96mm x 14mm x 56mm With case: 100mm x 21mm x 60mm |
Weight | 220g |
Mounting options | DIN rail, wall mount, flat surface (all require additional kit) |
