Self Contained Industrial Refrigeration Unit Water Cooled Water Chiller
Piece
Negotiable
Product information
High-quality Self Contained Industrial Refrigeration Unit Water Cooled Water Chiller supplied by Shenzhen Eurostars Technology Co., Ltd.. Bulk wholesale pricing is negotiable. Inquiry for latest prices.
Compressor Number:
1,2,3,4,5
Selected Voltage:
220~460V-50Hz/60Hz-3pH
Production Capacity:
3000 Units Per Year
HS Code:
8418692090
Casing:
Anti-Corrosion
Casters:
Available for Small Models
Color:
Blue White (Can Be Customized Color)
Certification:
CE
Specifications
Compressor Number:
1,2,3,4,5
Selected Voltage:
220~460V-50Hz/60Hz-3pH
Production Capacity:
3000 Units Per Year
HS Code:
8418692090
Casing:
Anti-Corrosion
Casters:
Available for Small Models
Color:
Blue White (Can Be Customized Color)
Certification:
CE
Structure:
Cabinet or Open Type
Compressor:
Copeland, Danfoss, SANYO
Expansion Valve:
Danfoss, Emerson
Trademark:
ESACIR
Model NO.:
ESSW Series
Trade Term:
FOB, CIF, CFR
Unit Structure:
Integral
Payment Term:
LC, T/T
Noise Level:
Low
Controller:
Microcomputer Control Punp
Condition:
New
Service:
OEM, ODM
Solenoid Valve:
Optional Castel
Application Fields:
Pharmaceutical
Evaporator:
Plate, Shell Tube, Coil in Tank
Transport Package:
Plywood Case
Application Machine:
Precision Machine Tool
Refrigerant:
R407c, R22, R134A, R404A
Specification:
Scroll Cooling Only
Condenser:
Shell and Tube
Origin:
Shenzhen
Port Of Loading:
Shenzhen Port
Water Pump:
Stainless Steel Chilled Pump (Cnp)
Tank:
Stainless Steel, Unpressurized
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
2013-06-03
Annual Revenue Amount:
Not specified
Numbers Of Employees:
45
Preferred Payment Term:
LC, T/T
Preferred Trade Term:
FOB, CIF, CFR
Port Of Loading:
Shenzhen Port
Certificates:
CE
Product descriptions from the supplier
Self Contained Industrial Refrigeration Unit Water Cooled Water Chiller
1. Water cooled industrial chiller applications
Water-cooled chillers are typically intended for indoor installation and operation, and are cooled by a separate condenser water loop and connected to outdoor cooling towers to expel heat to the atmosphere. Eurostars water cooled industrial chillers are mainly applied in the following fields:
Induction heating equipment, diathermy equipment
High frequency, medium frequency power supply, IGBT quenching equipment
Die-casting machines, injection molding machines
Rectifier equipment, resistance welding machine
Single crystal furnace, continuous casting mold machine, glass melting furnace
Food, chemical, air compressors, central air conditioning
2. The benefits of water cooled industrial chillers
By using Eurostars water-cooled chillers in your business, you'll be able to:
(1)Quickly cool produced parts, resulting in less delay during production
(2)Increase the number of parts generated in a working day
(3)Produce more precise and consistent products
(4)Increase profitability due to sped-up production
(5)Utilize the process for numerous applications, including molding and hydraulics
3. Eurostars water cooled water chiller main components
(1)Powerful Compressor:
High performance compressor, high EER value, low power consumption, low noise, low vibration, low failure rate, life up to 15 years, smooth operation.
(2)Shell and Tube Condenser:
Shell and tube evaporator with inner grooved cooper tubes optimizes the cooling and heating efficiency.
Self-cleaning,high intensity,anti-shaking design and heat insulation covering material ensure shell and tube heat exchanger unstained,reliable,quiet,highly efficient.
(3)Pump:
It's the heart of the water cycle, 100% copper motor, no leakage, no burning machine, long life, stainless steel flexible connection for easy replacement, repair and disassembly.
(4)Intelligent Controller:
Electronic panel, intelligent control switch, intelligent operation, simple, convenient and easy maintenance. Judging the running state of the unit by display time, one-click start automatic integration of efficient work.
(5)Throttling Device:
Adopt superior quality famous exterior balanced thermal expansion valve or capillary type throttling device, which is high reliability and adjustability, can realize precise refrigerant and temperature control to ensure operating in precise and reliable status.
Please ask salesman for detailed complete data or visit our website:
eurostarschiller.en.made-in-china.com
eurostarschiller.en.made-in-china.com
Remarks:
(1) Rated Cooling Capacity Based on:Evaporating temperature 7ºC;Condensing temperature 40ºC.
(2)Chilled Water Range: 5~25ºC;
(3)Cooling Water Range: 20~40ºC.
1. Water cooled industrial chiller applications
Water-cooled chillers are typically intended for indoor installation and operation, and are cooled by a separate condenser water loop and connected to outdoor cooling towers to expel heat to the atmosphere. Eurostars water cooled industrial chillers are mainly applied in the following fields:
Induction heating equipment, diathermy equipment
High frequency, medium frequency power supply, IGBT quenching equipment
Die-casting machines, injection molding machines
Rectifier equipment, resistance welding machine
Single crystal furnace, continuous casting mold machine, glass melting furnace
Food, chemical, air compressors, central air conditioning
2. The benefits of water cooled industrial chillers
By using Eurostars water-cooled chillers in your business, you'll be able to:
(1)Quickly cool produced parts, resulting in less delay during production
(2)Increase the number of parts generated in a working day
(3)Produce more precise and consistent products
(4)Increase profitability due to sped-up production
(5)Utilize the process for numerous applications, including molding and hydraulics
3. Eurostars water cooled water chiller main components
(1)Powerful Compressor:
High performance compressor, high EER value, low power consumption, low noise, low vibration, low failure rate, life up to 15 years, smooth operation.
(2)Shell and Tube Condenser:
Shell and tube evaporator with inner grooved cooper tubes optimizes the cooling and heating efficiency.
Self-cleaning,high intensity,anti-shaking design and heat insulation covering material ensure shell and tube heat exchanger unstained,reliable,quiet,highly efficient.
(3)Pump:
It's the heart of the water cycle, 100% copper motor, no leakage, no burning machine, long life, stainless steel flexible connection for easy replacement, repair and disassembly.
(4)Intelligent Controller:
Electronic panel, intelligent control switch, intelligent operation, simple, convenient and easy maintenance. Judging the running state of the unit by display time, one-click start automatic integration of efficient work.
(5)Throttling Device:
Adopt superior quality famous exterior balanced thermal expansion valve or capillary type throttling device, which is high reliability and adjustability, can realize precise refrigerant and temperature control to ensure operating in precise and reliable status.
4.Factory testing of Eurostars every chiller unit
(1)Pressurization and helium leak detection of refrigeration circuit
(2)Pressurization and leak testing of fluid circuit
(3)Chiller performance and power consumption at full load
(4)Proper operation of all controls, safety devices, and alarms
(5)Electrical tests according to standards
5. Eurostars water cooled industrial chiller brief technical data (1)Pressurization and helium leak detection of refrigeration circuit
(2)Pressurization and leak testing of fluid circuit
(3)Chiller performance and power consumption at full load
(4)Proper operation of all controls, safety devices, and alarms
(5)Electrical tests according to standards
Please ask salesman for detailed complete data or visit our website:
eurostarschiller.en.made-in-china.com
eurostarschiller.en.made-in-china.com
| Water Cooled Chiller Unit | |||||||||
| Model ESSW- | 03ISCN | 04ISCN | 05ISCN | 06ISCN | 08IDCN | 10IDCN | 12IDCN | ||
| Item NO. | 3 | 4 | 5 | 6 | 8 | 10 | 12 | ||
| Rated Cooling Capacity | KW | 10.15 | 12.93 | 16.13 | 20.40 | 25.00 | 32.26 | 40.80 | |
| USRT | 2.89 | 3.68 | 4.59 | 5.80 | 7.11 | 9.17 | 11.60 | ||
| ×1000 kcal/h | 8.73 | 11.12 | 13.87 | 17.54 | 21.50 | 27.74 | 35.09 | ||
| Water Cooled Chiller Unit | |||||||||
| Model ESSW- | 15IDCN | 20IDCN | 25IDCN | 30IDCN | 40IQCN | 50IQCN | 60IQCN | ||
| Item NO. | 15 | 20 | 25 | 30 | 40 | 50 | 60 | ||
| Rated Cooling Capacity | KW | 49.23 | 66.21 | 80.44 | 99.56 | 132.42 | 160.89 | 199.12 | |
| USRT | 14.00 | 18.83 | 22.87 | 28.31 | 37.65 | 45.75 | 56.62 | ||
| ×1000 kcal/h | 42.34 | 56.94 | 69.18 | 85.62 | 113.88 | 138.37 | 171.24 | ||
(1) Rated Cooling Capacity Based on:Evaporating temperature 7ºC;Condensing temperature 40ºC.
(2)Chilled Water Range: 5~25ºC;
(3)Cooling Water Range: 20~40ºC.
6. Our OEM ODM Service
EUROSTARS was established in 2006, has a professional technical team to research and develope HVAC products. We offer OEM/ODM service to our clients.
Now EUROSTARS collaborate with our clients in the following ways:
(1)Produce EUROSTARS standard products under clients' brand.
(2)Modify the products to satisfy clients' personalized requirements.
(3)If clients have their own idea and design of the products, EUROSTARS can actualize it and modify it make it easy for mass production.
(4)Based on strong capability of research and development, EUROSTARS can work together with clients to design and produce a totally new products.
7. Why Choose Eurostars Company?
(1)Designing
*Solid external structure design to make sure a chiller runs on a strong foundation
*Strict calculation and repeated trials for every component before putting it into a Eurostars product
*Rational internal structure design to ensure stable performance of every part
(2)Manufacturing
*Experienced production team consists of senior workers with more than 10 years experience in industrial refrigeration area
*Established production process is strictly applied on every product, which is detailed to every welding spot, pipe connection and screw fastening
(3)Quality control
*120+ incoming inspection rules
*80+ final QC rules
*72hr 18 Bar nitrogen pressure holding testing
*48hr running test
(4)Unit built-in protection
*Motor overload protection for compressor, pump and condenser fan
*Compressor motor overheat protection
*Discharge temperature overheat protection
*High&low pressure protection
*Returning water overheat protection
*Low water flow/level protection
*Phase protection
*Anti-freezing protection
(5)Warranty
*12 months warranty on every unit
*Extended warranty up to 5 years
8. Eurostars Company Ceritifcate & Customer Visiting
We, EUROSTARS, which established in year 2006, is a modern hi-tech enterprise, specializing in Heating Ventilation Air Conditioning and Industrial Refrigeration research, development, production, sales and engineering services.
(1)With more certificate
(2) Professional team with over more than 10 years industry knowledge
(3) Oversea installation.
(4) Customer-made accepted.
(5) Diamond member of Made-In-China
(6) Audited supplier by SGS
9. Our factory view
Modern new process and assemble line, including copper tube straighten machine, aluminum fin punching machine, three dimensional copper tube bending machine, tube expander machine, sheet metal laser cutting machine, numerical control punching machine, CNC bending machine, chiller, fan coil unit and AHU assemble line,. etc..
Chiller production at our previous location as below
10. Eurostars industrial chiller package and delivery
Our standard package is plastic film with plywood case for safe delivery and easy to load/unload.
11. Eurostars industrial chiller projects
We exported chillers to Ukraine, New Zealand, Guatelmala, Peru, Chile, Norway, Serbia, Romania, Greece, France, South Africa, Australia, Uzbekistan, Sri Lanka, India, Saudi Arabia, Iran, Mexico, Argentina, etc..
EUROSTARS was established in 2006, has a professional technical team to research and develope HVAC products. We offer OEM/ODM service to our clients.
Now EUROSTARS collaborate with our clients in the following ways:
(1)Produce EUROSTARS standard products under clients' brand.
(2)Modify the products to satisfy clients' personalized requirements.
(3)If clients have their own idea and design of the products, EUROSTARS can actualize it and modify it make it easy for mass production.
(4)Based on strong capability of research and development, EUROSTARS can work together with clients to design and produce a totally new products.
7. Why Choose Eurostars Company?
(1)Designing
*Solid external structure design to make sure a chiller runs on a strong foundation
*Strict calculation and repeated trials for every component before putting it into a Eurostars product
*Rational internal structure design to ensure stable performance of every part
(2)Manufacturing
*Experienced production team consists of senior workers with more than 10 years experience in industrial refrigeration area
*Established production process is strictly applied on every product, which is detailed to every welding spot, pipe connection and screw fastening
(3)Quality control
*120+ incoming inspection rules
*80+ final QC rules
*72hr 18 Bar nitrogen pressure holding testing
*48hr running test
(4)Unit built-in protection
*Motor overload protection for compressor, pump and condenser fan
*Compressor motor overheat protection
*Discharge temperature overheat protection
*High&low pressure protection
*Returning water overheat protection
*Low water flow/level protection
*Phase protection
*Anti-freezing protection
(5)Warranty
*12 months warranty on every unit
*Extended warranty up to 5 years
8. Eurostars Company Ceritifcate & Customer Visiting
We, EUROSTARS, which established in year 2006, is a modern hi-tech enterprise, specializing in Heating Ventilation Air Conditioning and Industrial Refrigeration research, development, production, sales and engineering services.
(1)With more certificate
(2) Professional team with over more than 10 years industry knowledge
(3) Oversea installation.
(4) Customer-made accepted.
(5) Diamond member of Made-In-China
(6) Audited supplier by SGS
9. Our factory view
Modern new process and assemble line, including copper tube straighten machine, aluminum fin punching machine, three dimensional copper tube bending machine, tube expander machine, sheet metal laser cutting machine, numerical control punching machine, CNC bending machine, chiller, fan coil unit and AHU assemble line,. etc..
Chiller production at our previous location as below
10. Eurostars industrial chiller package and delivery
Our standard package is plastic film with plywood case for safe delivery and easy to load/unload.
11. Eurostars industrial chiller projects
We exported chillers to Ukraine, New Zealand, Guatelmala, Peru, Chile, Norway, Serbia, Romania, Greece, France, South Africa, Australia, Uzbekistan, Sri Lanka, India, Saudi Arabia, Iran, Mexico, Argentina, etc..
User Reviews
Write a review
File a complaint
Supplier Review
Summary by Vivian
TRUST STARS
3.0/5
0 Reviews
Company Verification
0/4
Profile Completeness
67%
Avg. Product Score
0/5
Responsiveness
0%
Certification
CE
Related searches
Frequently Asked Questions (FAQs)
How can I buy & import Industrial Pumps from China?
You can contact verified China supplier Shenzhen Eurostars Technology Co., Ltd. through platforms like Freshdi.com to purchase Self Contained Industrial Refrigeration Unit Water Cooled Water Chiller. For direct inquiries, please contact Mr. Alex, the company’s representative. The supplier has a 3.0-star rating on Freshdi and has verified. You’ll receive product details, pricing, and shipping terms directly from supplier.
What are the payments and trade terms for Self Contained Industrial Refrigeration Unit Water Cooled Water Chiller?
For Self Contained Industrial Refrigeration Unit Water Cooled Water Chiller, Shenzhen Eurostars Technology Co., Ltd. accepts LC, T/T as the preferred payment method, the trade term is FOB, CIF, CFR, and shipments are typically arranged from port Shenzhen Port, ensuring secure and timely international delivery.
What is the current price of Self Contained Industrial Refrigeration Unit Water Cooled Water Chiller?
The supplier Shenzhen Eurostars Technology Co., Ltd. offers Self Contained Industrial Refrigeration Unit Water Cooled Water Chiller at negotiation.
What are the specifications of Self Contained Industrial Refrigeration Unit Water Cooled Water Chiller from China?
Self Contained Industrial Refrigeration Unit Water Cooled Water Chiller is sourced from China and meets international export standards. Key specifications include: Color: Blue White (Can Be Customized Color), Noise Level: Low, Model NO.: ESSW Series, Refrigerant: R407c, R22, R134A, R404A, Condition: New, Certification: CE, Trade Term: FOB, CIF, CFR, Payment Term: LC, T/T
You are viewing details for Self Contained Industrial Refrigeration Unit Water Cooled Water Chiller. The information provided here is either posted directly by the supplier, who is responsible for its accuracy, or collected by Freshdi AI from publicly available sources. Freshdi strives to make product information as useful and reliable as possible, but we do not guarantee complete accuracy. If you notice any incorrect or misleading details, please use the Report Product option so our team can review and address it quickly.
Negotiable
Min. order: Negotiable
Mr. Alex
Year Established: 2013-06-03
Visit Store
