Single-Layer Cold-Formed Tile Pressing Machine Color Steel Cold Roll Forming Machine Roofing Panel Making Machine
Set
Negotiable
Product information
High-quality Single-Layer Cold-Formed Tile Pressing Machine Color Steel Cold Roll Forming Machine Roofing Panel Making Machine supplied by Botou Xianfa Roll Forming Machine Factory. Bulk wholesale pricing is negotiable. Inquiry for latest prices.
Production Capacity:
20sets/Month
Stations:
20steps(Customizable)
Large Frame:
350h Steel
Voltage:
380V 50Hz 3phases(Customizable)
Power(W):
4+4kw
Roller & Shaft Material:
45# Steel with Chrome Treatment
Package Gross Weight:
8000.000kg
HS Code:
8455221000
Specifications
Production Capacity:
20sets/Month
Stations:
20steps(Customizable)
Large Frame:
350h Steel
Voltage:
380V 50Hz 3phases(Customizable)
Power(W):
4+4kw
Roller & Shaft Material:
45# Steel with Chrome Treatment
Package Gross Weight:
8000.000kg
HS Code:
8455221000
Weight:
8t
Package Size:
950.00cm * 170.00cm * 190.00cm
Color:
Blue(Customizable)
Origin:
Botou China
Certification:
CE
Refund Policy:
Claim a refund if your order doesn't ship, is missing, or arrives with product issues.
Tile Type:
Colored Steel
Shipping Cost:
Contact the supplier about freight and estimated delivery time.
Cutter Material:
Cr12
Specification:
Customized
Customized:
Customized
Trade Term:
FOB, CIF, CFR, EXW
Payment Term:
LC, T/T, D/P, Western Union, PayPal
Transmission Method:
Machinery
Transport Package:
Naked and Covered by Plastic Film Into Container
Condition:
New
Control System:
PLC System
Type:
Roof Panel Machinery
Usage:
Roof, Wall
Payment Methods:
Support payments in USD
Port Of Loading:
Tianjin Port
Trademark:
XF
Model NO.:
XF22-70-420-610
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
2008-01-06
Annual Revenue Amount:
Not specified
Numbers Of Employees:
22
Preferred Payment Term:
LC, T/T, D/P, Western Union, PayPal
Preferred Trade Term:
FOB, CIF, CFR, EXW
Port Of Loading:
Tianjin Port
Certificates:
BV, CE
Product descriptions from the supplier
Product Details
Single-layer cold-formed tile pressing machine Color steel cold roll forming machine Roofing Panel Making Machine
Finished product display
Company product type
Development and Cooperation
Botou Xianfa Press Factory has a 28-year production history.
Currently, our products have been exported to Australia, the United States, Romania, Dominican Republic, Mexico, Kenya, Thailand, Philippines, Zimbabwe, Peru, Colombia, Croatia, Saudi Arabia, Macedonia, etc., more than 130 countries and regions around the world.
We maintain a good cooperative relationship with our customers.
We firmly believe that technological innovation and making every detail of the product perfect are our eternal pursuit.
Welcome to visit our factory and establish friendly cooperation with us!
Package
Our equipment will be inspected before shipment, and then wrapped in plastic wrap to prevent moisture and protect the surface. We will take anti-collision measures on important parts before packing.
Contact Us
Welcome to inquire, we will serve you wholeheartedly!
Single-layer cold-formed tile pressing machine Color steel cold roll forming machine Roofing Panel Making Machine
Main rollers
Rollers manufactured from 45# steel,CNC lathes,Heat Treatment,hard Chrome Coated
1.Roller stations: 20row wheels (according to different design, depend on the profile drawing)
2.Shaft diameter: 70mm, solid.
3.Wheel speed: 10-15M/min
The processed rollers are smooth, hard and will not rust.
Will not leave any scratches on the sheet when working.
Rollers manufactured from 45# steel,CNC lathes,Heat Treatment,hard Chrome Coated
1.Roller stations: 20row wheels (according to different design, depend on the profile drawing)
2.Shaft diameter: 70mm, solid.
3.Wheel speed: 10-15M/min
The processed rollers are smooth, hard and will not rust.
Will not leave any scratches on the sheet when working.
Computer control cabinet
It adopts Delta PLC to control,
Computed mode has two modes: Automatic and manual.
touchscreen
The unit length of the targeted sheet can be set in the control cabinet.
the operation is easy, running is steady and reliable, endurable.
It adopts Delta PLC to control,
Computed mode has two modes: Automatic and manual.
touchscreen
The unit length of the targeted sheet can be set in the control cabinet.
the operation is easy, running is steady and reliable, endurable.
hydraulic pump station
The hydraulic system uses the CDF-10 hydraulic pump, long operating life, no noise.
It is controlled by gear wheel oil pump, after filling the hydraulic oil into the hydraulic oil tank,
the pump drive the cutting machine to begin the cutting job.
The hydraulic system uses the CDF-10 hydraulic pump, long operating life, no noise.
It is controlled by gear wheel oil pump, after filling the hydraulic oil into the hydraulic oil tank,
the pump drive the cutting machine to begin the cutting job.
Feeding table
Feeding is smooth and level
The tail is equipped with a hand-pulled knife for early cutting and cost saving
Feeding is smooth and level
The tail is equipped with a hand-pulled knife for early cutting and cost saving
Cutting knife
1.Work type: Hydraulic
2.Driving method: By Cylinder
3.Cutter material : Cr 12/CR12MOV, Heat treatment
4.Cutting length tolerance: ±1.0mm
5.Advantages:Energy saving effect, hydraulic technology can achieve higher energy conversion efficiency and reduce energy consumption, the hydraulic drive response speed is fast.
1.Work type: Hydraulic
2.Driving method: By Cylinder
3.Cutter material : Cr 12/CR12MOV, Heat treatment
4.Cutting length tolerance: ±1.0mm
5.Advantages:Energy saving effect, hydraulic technology can achieve higher energy conversion efficiency and reduce energy consumption, the hydraulic drive response speed is fast.
remote control
The device is equipped with a remote control for easier operation. You can start or pause it anytime and anywhere.
The device is equipped with a remote control for easier operation. You can start or pause it anytime and anywhere.
Finished product display
Company product type
| Glazed tile forming machine | Ridge cap roll forming machine |
| Double-layer color steel roll forming machine | Downspout forming machine |
| Color steel roll forming machine | Keel roll forming machine |
| Joint-hidden type forming machine | C/Z/U/Π profile steel forming machine |
| Russian dedicated color steel forming machine | Highway guardrail roll forming machine |
| No-girder arched roll forming machine | Windshield dust-controlling board forming machine |
| Floor deck roll forming machine | Carriage board roll forming machine/High frequency pipe welder |
| Roll shutter door forming machine | Heat retaining Sandwich panel production line |
Development and Cooperation
Botou Xianfa Press Factory has a 28-year production history.
Currently, our products have been exported to Australia, the United States, Romania, Dominican Republic, Mexico, Kenya, Thailand, Philippines, Zimbabwe, Peru, Colombia, Croatia, Saudi Arabia, Macedonia, etc., more than 130 countries and regions around the world.
We maintain a good cooperative relationship with our customers.
We firmly believe that technological innovation and making every detail of the product perfect are our eternal pursuit.
Welcome to visit our factory and establish friendly cooperation with us!
Package
Our equipment will be inspected before shipment, and then wrapped in plastic wrap to prevent moisture and protect the surface. We will take anti-collision measures on important parts before packing.
Contact Us
Welcome to inquire, we will serve you wholeheartedly!
