Single-Sided Alunimum PCB LED Light Prototyping LED Metal Core PCB Board
Piece
Negotiable
Product information
High-quality Single-Sided Alunimum PCB LED Light Prototyping LED Metal Core PCB Board supplied by Abis Circuits Co., Ltd.. Bulk wholesale pricing is negotiable. Inquiry for latest prices.
Impedance Control Tolerance:
+/-10%
Package Gross Weight:
0.500kg
Layer:
1 Layer
Production Capacity:
120000m2/Year
Min Hole Size:
12mil(0.3mm)
Specification:
300*180 mm
Package Size:
35.00cm * 20.00cm * 12.00cm
Min Line Width/Space:
3mil(0.075mm)
Specifications
Impedance Control Tolerance:
+/-10%
Package Gross Weight:
0.500kg
Layer:
1 Layer
Production Capacity:
120000m2/Year
Min Hole Size:
12mil(0.3mm)
Specification:
300*180 mm
Package Size:
35.00cm * 20.00cm * 12.00cm
Min Line Width/Space:
3mil(0.075mm)
HS Code:
85340090
Trademark:
Abis
Brand:
Abis
Base Material:
Aluminum
Raw Material:
Aluminum Base, Copper Base
Refund Policy:
Claim a refund if your order doesn't ship, is missing, or arrives with product issues.
Application:
Consumer Electronics
Shipping Cost:
Contact the supplier about freight and estimated delivery time.
Processing Technology:
Electrolytic Foil
Insulation Materials:
Epoxy Resin
Trade Term:
FOB, EXW, CFR, CIF, DAP, FCA
Dielectric:
FR-4
Material:
Fiberglass Epoxy
Payment Term:
LC, T/T, PayPal, Western Union
Model NO.:
PCB-A77
Mechanical Rigid:
Rigid
Origin:
Shenzhen, China
Port Of Loading:
Shenzhen, HongKong
Payment Methods:
Support payments in USD
Transport Package:
Vacuum Packing
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
2006-10-04
Annual Revenue Amount:
Not specified
Numbers Of Employees:
Not specified
Preferred Payment Term:
LC, T/T, PayPal, Western Union
Preferred Trade Term:
FOB, EXW, CFR, CIF, DAP, FCA
Port Of Loading:
Shenzhen, HongKong
Certificates:
American UL, Canada UL, ISO14001, ISO9001
Product descriptions from the supplier
Single-Sided Alunimum PCB LED Light Prototyping LED Metal Core PCB Board
Technical & Capability
|
Item |
Speci. |
|
Layers |
1~2 |
|
Common Finish Board Thickness |
0.3-5mm |
|
Material |
Aluminum Base, Copper base |
|
Max Panel Size |
1200mm*560mm(47in*22in) |
|
Min Hole Size |
12mil(0.3mm) |
|
Min Line Width/Space |
3mil(0.075mm) |
|
Copper Foil Thickness |
35μm-210μm(1oz-6oz) |
|
Common Copper Thickness |
18μm, 35μm, 70μm, 105μm. |
|
Remain Thickness Tolerance |
+/-0.1mm |
|
Routing Outline Tolerance |
+/-0.15mm |
|
Punching Outline Tolerance |
+/-0.1mm |
|
Solder Mask Type |
LPI(liquid photo image) |
|
Mini. Solder Mask Clearance |
0.05mm |
|
Plug Hole Diameter |
0.25mm--0.60mm |
|
Impedance Control Tolerance |
+/-10% |
|
Surface finish |
Lead free HASL, immersion gold(ENIG), immersion sliver, OSP, etc |
|
Solder Mask |
Custom |
|
Silkscreen |
Custom |
|
MC PCB Production Capacity |
10,000 s.q.m/monthly |
| Production capacity of hot-sale products | |
| Double-Sided/Multilayer PCB Workshop | Aluminum PCB Workshop |
| Technical Capability | Technical Capability |
| Raw materials: CEM-1, CEM-3, FR-4(High TG), Rogers, TELFON | Raw materials: Aluminum base, Copper base |
| Layer: 1 layer to 20 Layers | Layer: 1 layer and 2 Layers |
| Min.line width/space: 3mil/3mil(0.075mm/0.075mm) | Min.line width/space: 4mil/4mil(0.1mm/0.1mm) |
| Min.Hole size: 0.1mm(dirilling hole) | Min.Hole size: 12mil(0.3mm) |
| Max. Board size: 1200mm* 600mm | Max.Board size: 1200mm* 560mm(47in* 22in) |
| Finished board thickness: 0.2mm- 6.0mm | Finished board thickness: 0.3~ 5mm |
| Copper foil thickness: 18um~280um(0.5oz~8oz) | Copper foil thickness: 35um~210um(1oz~6oz) |
| NPTH Hole Tolerance: +/-0.075mm, PTH hole Tolerance: +/-0.05mm | Hole position tolerance: +/-0.05mm |
| Outline Tolerance: +/-0.13mm | Routing outline tolerance: +/ 0.15mm; punching outline tolerance:+/ 0.1mm |
| Surface finished: Lead free HASL, immersion gold(ENIG), immersion silver, OSP, gold plating, gold finger, Carbon INK. | Surface finished: Lead free HASL, immersion gold(ENIG), immersion silver, OSP etc |
| Impedance control tolerance: +/-10% | Remain thickness tolerance: +/-0.1mm |
| Production capability: 50,000 s.q.m/month | MC PCB Production capability: 10,000 s.q.m/month |
Q/T Lead Time
| Category | Quickest Lead Time | Normal Lead Time |
| Double sideds | 24hrs | 120hrs |
| 4 Layers | 48hrs | 172hrs |
| 6 Layers | 72hrs | 192hrs |
| 8 Layers | 96hrs | 212hrs |
| 10 Layers | 120hrs | 268hrs |
| 12 Layers | 120hrs | 280hrs |
| 14 Layers | 144hrs | 292hrs |
| 16-20 Layers | Depends on the specific requirements | |
| Above 20 Layers | Depends on the specific requirements | |
Quality Control
Pre-Sale and After-Sale Service
1 Hour quotation
2 hours complaint feedback
7*24 hour technical support
7*24 order service
7*24 hour delivery
7*24 production run
