Single-Sided Metal Core PCB Custom Aluminum PCB/ PCBA Board for Lamp/ LED/ Light
1 Piece
$0.011 Piece
$100Product information
High-quality Single-Sided Metal Core PCB Custom Aluminum PCB/ PCBA Board for Lamp/ LED/ Light supplied by Abis Circuits Co., Ltd.. Bulk wholesale pricing ranges from $0.01 to $100 per Piece with a minimum order of 1 Piece. Inquiry for latest prices.
Impedance Control Tolerance:
+/-10%
Layer:
1-2 Layers
Specification:
200*30 mm
Min Line Width/Space:
3mil(0.075mm)
Production Capacity:
500000m2/Year
HS Code:
85340090
Trademark:
Abis
Brand:
Abis
Specifications
Impedance Control Tolerance:
+/-10%
Layer:
1-2 Layers
Specification:
200*30 mm
Min Line Width/Space:
3mil(0.075mm)
Production Capacity:
500000m2/Year
HS Code:
85340090
Trademark:
Abis
Brand:
Abis
Base Material:
Aluminum
Material:
Aluminum
Raw Material:
Aluminum Base, Copper Base
Solder Mask/ Silkscreen:
Custom
Processing Technology:
Electrolytic Foil
Trade Term:
FOB, EXW, CFR, CIF, DAP, FCA
Dielectric:
FR-4
Payment Term:
LC, T/T, PayPal, Western Union
Application:
Lamp/ LED/ Light
Insulation Materials:
Metal Composite Materials
Model NO.:
PCB-A78
Mechanical Rigid:
Rigid
Origin:
Shenzhen, China
Port Of Loading:
Shenzhen, HongKong
Transport Package:
Vacuum Packing
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
2006-10-04
Annual Revenue Amount:
Not specified
Numbers Of Employees:
Not specified
Preferred Payment Term:
LC, T/T, PayPal, Western Union
Preferred Trade Term:
FOB, EXW, CFR, CIF, DAP, FCA
Port Of Loading:
Shenzhen, HongKong
Certificates:
American UL, Canada UL, ISO14001, ISO9001
Product descriptions from the supplier
Single-sided Metal Core PCB Custom Aluminum PCB/ PCBA Board for Lamp/ LED/ Light
Technical & Capability
|
Item |
Speci. |
|
Layers |
1~2 |
|
Common Finish Board Thickness |
0.3-5mm |
|
Material |
Aluminum Base, Copper base |
|
Max Panel Size |
1200mm*560mm(47in*22in) |
|
Min Hole Size |
12mil(0.3mm) |
|
Min Line Width/Space |
3mil(0.075mm) |
|
Copper Foil Thickness |
35μm-210μm(1oz-6oz) |
|
Common Copper Thickness |
18μm, 35μm, 70μm, 105μm. |
|
Remain Thickness Tolerance |
+/-0.1mm |
|
Routing Outline Tolerance |
+/-0.15mm |
|
Punching Outline Tolerance |
+/-0.1mm |
|
Solder Mask Type |
LPI(liquid photo image) |
|
Mini. Solder Mask Clearance |
0.05mm |
|
Plug Hole Diameter |
0.25mm--0.60mm |
|
Impedance Control Tolerance |
+/-10% |
|
Surface finish |
HASL Lead-free , immersion gold(ENIG), immersion silver, OSP, etc |
|
Solder Mask |
Custom |
|
Silkscreen |
Custom |
|
MC PCB Production Capacity |
10,000 s.q.m/monthly |
| Production capacity of hot-sale products | |
| Double Side/Multilayer PCB Workshop | Aluminum PCB Workshop |
| Technical Capability | Technical Capability |
| Raw materials: CEM-1, CEM-3, FR-4(High TG), Rogers, TELFON | Raw materials: Aluminum base, Copper base |
| Layer: 1 layer to 20 Layers | Layer: 1 layer and 2 Layers |
| Min.line width/space: 3mil/3mil(0.075mm/0.075mm) | Min.line width/space: 4mil/4mil(0.1mm/0.1mm) |
| Min.Hole size: 0.1mm(dirilling hole) | Min.Hole size: 12mil(0.3mm) |
| Max. Board size: 1200mm* 600mm | Max.Board size: 1200mm* 560mm(47in* 22in) |
| Finished board thickness: 0.2mm- 6.0mm | Finished board thickness: 0.3~ 5mm |
| Copper foil thickness: 18um~280um(0.5oz~8oz) | Copper foil thickness: 35um~210um(1oz~6oz) |
| NPTH Hole Tolerance: +/-0.075mm, PTH hole Tolerance: +/-0.05mm | Hole position tolerance: +/-0.05mm |
| Outline Tolerance: +/-0.13mm | Routing outline tolerance: +/ 0.15mm; punching outline tolerance:+/ 0.1mm |
| Surface finished: Lead-free HASL, immersion gold(ENIG), immersion silver, OSP, gold plating, gold finger, Carbon INK. | Surface finished: Lead-free HASL, immersion gold(ENIG), immersion silver, OSP etc |
| Impedance control tolerance: +/-10% | Remain thickness tolerance: +/-0.1mm |
| Production capability: 50,000 s.q.m/month | MC PCB Production capability: 10,000 s.q.m/month |
