Small Scale Autoclave Sterilizer for Canned Food Pet Food Sterilization Equipment
Piece
Negotiable
Product information
High-quality Small Scale Autoclave Sterilizer for Canned Food Pet Food Sterilization Equipment supplied by Wenzhou Ranking Imp. & Exp. Co., Ltd.. Bulk wholesale pricing is negotiable. Inquiry for latest prices.
Working Pressure:
0.2MPa
Working Temp.:
121 Degree C
Package Size:
230.00cm * 200.00cm * 190.00cm
Production Capacity:
500PCS/Season
HS Code:
8419899090
Package Gross Weight:
900.000kg
Origin:
China
Refund Policy:
Claim a refund if your order doesn't ship, is missing, or arrives with product issues.
Specifications
Working Pressure:
0.2MPa
Working Temp.:
121 Degree C
Package Size:
230.00cm * 200.00cm * 190.00cm
Production Capacity:
500PCS/Season
HS Code:
8419899090
Package Gross Weight:
900.000kg
Origin:
China
Refund Policy:
Claim a refund if your order doesn't ship, is missing, or arrives with product issues.
Shipping Cost:
Contact the supplier about freight and estimated delivery time.
Specification:
DN400~DN1500
Model NO.:
DN900x1500
Trade Term:
FOB, CIF, CFR, EXW
Energy:
Heat Sterilization
Type:
High Pressure High Temperature Sterilizer
Operation:
Intermittent
Payment Term:
LC, T/T, D/P, PayPal, Western Union, Small-amount payment
Control Mode:
Manual / PLC
Scale:
Medium
Port Of Loading:
Ningbo Port, Shanghai Port
Automation:
PLC Control
Property:
Physical Sterilization
Trademark:
Ranking
Principle:
Static
Construction Material:
Steainless Steel
Payment Methods:
Support payments in USD
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
2016-02-04
Annual Revenue Amount:
Not specified
Numbers Of Employees:
8
Preferred Payment Term:
LC, T/T, D/P, PayPal, Western Union, Small-amount payment
Preferred Trade Term:
FOB, CIF, CFR, EXW
Port Of Loading:
Ningbo Port, Shanghai Port
Certificates:
Our Business License
Product descriptions from the supplier
Steam-Spray-Counter Pressure Retort sterilizer
Steam Water Spray Retort
A sterilization retort is frequently known as a retort sterilizer or a sterilization vessel. In certain regions and countries, the term sterilizer is often used interchangeably with autoclave or autoclave sterilizer. Additionally, 'clave' is sometimes applied as a name for a sterilization retort.
A wide variety of containers are used for fruits, juices, meat, fish, tin cans, glass jars, PP bottles, and vacuum-sealed packaging—most of these require sterilization prior to reaching the supermarket. A sterilization retort is the ideal equipment for processing these items.
Hot Sell Sterilizer Retort Sterilizer Customer Case
Customer request
Autoclave / Sterilizer Rtort price specification
Sterilizer retort working flow
A steam spray or steam heating sterilizer employs a steam jet to raise the internal temperature to approximately 121°C for a duration between 10 and 30 minutes. Once heated, the chamber is cooled by injecting cold water or ice water to achieve quick temperature reduction. Upon completion of this cooling phase, the sterilization cycle is considered finished. Therefore, the operational sequence of a steam heating or steam spray sterilizer follows this pattern:
During operation, the steam spray sterilizer injects steam that mixes uniformly with the fine water mist, creating a highly consistent thermal distribution across the entire autoclave or retort chamber. With water streams directed into the sterilization trays both from above and the lateral sides, the system ensures balanced and swift heating and cooling cycles.
Counter Pressure in sterilizer retort
Before heating, counter pressure is not required. Once the material inside the sterilizer reaches 121°C or another set sterilization temperature, counter pressure becomes essential—particularly when processing glass bottles and tin cans. This pressure is primarily supplied by compressed air. It ensures the bottle lid remains securely in place and does not pop off due to internal pressure buildup. In essence, applying counter pressure during sterilization enables autoclave operators to enhance the effectiveness of the sterilization process.
Compressed air serves as a push mechanism to expel both hot and chilled water from the sterilizer housing into the respective hot or cold water holding tanks.
Benefits of water spray sterilizer retort
Price for sterilizer retort sterilization machine
The cost of our retort sterilizer varies depending on the retort's diameter and the machine's body length, as these factors differ based on application needs. To provide you with a precise quote, kindly share either the desired diameter and length of the sterilizer or the dimensions of your product packaging along with the batch size you intend to process. Based on this information, we’ll recommend the best fit and deliver a tailored price.
Steam Water Spray Retort
A sterilization retort is frequently known as a retort sterilizer or a sterilization vessel. In certain regions and countries, the term sterilizer is often used interchangeably with autoclave or autoclave sterilizer. Additionally, 'clave' is sometimes applied as a name for a sterilization retort.
A wide variety of containers are used for fruits, juices, meat, fish, tin cans, glass jars, PP bottles, and vacuum-sealed packaging—most of these require sterilization prior to reaching the supermarket. A sterilization retort is the ideal equipment for processing these items.
Hot Sell Sterilizer Retort Sterilizer Customer Case
Customer request
- electric water spray autoclave
- for C-PET plastic trays containing tofu
- tray size 150 × 130 × 45mm
- around 200 trays each batch
- use 380V 50Hz 3phase power supply
- 121degree C sterilization temperatureSuggested Autoclave / Sterilizer Rtort price (FOB Ningbo)
| No. | Item | Unit price | Amount |
| 1 | DN800×1000 - CE electric heating water spray |
**,8** usd | **,8** usd |
| Retort capacity | 500L |
| Productivity cans/batch | 192 trays for 150 × 130 × 45mm trays |
| Pot size | Φ800*1000 mm |
| Design temperature | 143 0C |
| Operating temperature | ≤138 0C |
| Design pressure | 0.3mpa |
| Working pressure | ≤0.26Mpa |
| Heating method | Electric |
| Heating power | ≤36KW |
| Material | SUS304 |
| Raw material thickness | 7mm |
| Thermal insulation | 50mm PU insulation with 1.5mm cladding |
| Welding coefficient | 0.7 |
| Corrosion allowance | 1mm |
| Exhaust diameter | DN32-40 |
| Cold and hot water connection tube diameter | DN40-50 |
| Overflow pipe diameter | DN25-50 |
| Drain-pipe diameter | DN40-50 |
| Relief valve diameter | DN25-50 |
| Compressed air diameter | DN15-20 |
| Adjust mouth diameter | DN25-40 |
| Weight | 500 |
| Overall dimension L×W×H | 1500×1200×1200 mm |
| Design life | 12 years |
Sterilizer retort working flow
A steam spray or steam heating sterilizer employs a steam jet to raise the internal temperature to approximately 121°C for a duration between 10 and 30 minutes. Once heated, the chamber is cooled by injecting cold water or ice water to achieve quick temperature reduction. Upon completion of this cooling phase, the sterilization cycle is considered finished. Therefore, the operational sequence of a steam heating or steam spray sterilizer follows this pattern:
- Loading glass jar / fish tin can or any other package into the autoclave basket.
- Push the sterilization baskets into the sterilizer retort chamber and seal the door.
- Pump process water into the sterilizer retort body.
- Turn on the steam inlet valve to start the pre-heating process.
- When temperature arrived to 121 degree, turn down the steam inlet valve and keep the temperature at 121 degree C without any significant increase.
- Add some compressed air into the retort or open the pressure relief valve to control the pressure at a suitable level.
- Pump cooling water to the retort chamber or plate heat exchanger (if exist) for cooling
- Unloading the tin can / glass jar / bottle and finish the sterilization batch
During operation, the steam spray sterilizer injects steam that mixes uniformly with the fine water mist, creating a highly consistent thermal distribution across the entire autoclave or retort chamber. With water streams directed into the sterilization trays both from above and the lateral sides, the system ensures balanced and swift heating and cooling cycles.
Counter Pressure in sterilizer retort
Before heating, counter pressure is not required. Once the material inside the sterilizer reaches 121°C or another set sterilization temperature, counter pressure becomes essential—particularly when processing glass bottles and tin cans. This pressure is primarily supplied by compressed air. It ensures the bottle lid remains securely in place and does not pop off due to internal pressure buildup. In essence, applying counter pressure during sterilization enables autoclave operators to enhance the effectiveness of the sterilization process.
Compressed air serves as a push mechanism to expel both hot and chilled water from the sterilizer housing into the respective hot or cold water holding tanks.
Benefits of water spray sterilizer retort
- Quick heating in preheating process
- uniform heat distribution in sterilizer chamber
- Rapid and even cooling.
- Low electricity, steam and water consumption.
- Safe counter pressure control during all process phases.
- Accurate temperature control
- Suitable for different types and sizes of package.
- Pressure gauge
- Temperature thermometer
- Safety valve
- Safety lock
- Gasket sealing ring
- Pressure relief valve
- Compressed air inlet valve
- Water inlet pump
- Steam inlet valve and by pass valve (optional)
- Pipe filter for cooling water
- Filter screen for water outlet pipe (optional for glass jar sterilizer)
- Countdown Timer for sterilization period / cooking phase
- Level meter
- Plate heat exchanger (optional)
- Round Paper recorder / paper less recorder (optional)
- USB Date logger (optional)
- Insulated Hot water tank (optional)
- Conveyor Chain inside the sterilizer retort (optional)
- PLC control system (optional)
- Air compressor
- Compressed air storage tank
Price for sterilizer retort sterilization machine
The cost of our retort sterilizer varies depending on the retort's diameter and the machine's body length, as these factors differ based on application needs. To provide you with a precise quote, kindly share either the desired diameter and length of the sterilizer or the dimensions of your product packaging along with the batch size you intend to process. Based on this information, we’ll recommend the best fit and deliver a tailored price.
