Stainless Steel SS316 Food Grade Round Pressure Inward Cm 2 Shell Tank Manway
1-9 Piece
$50010 Piece
$450Product information
High-quality Stainless Steel SS316 Food Grade Round Pressure Inward Cm 2 Shell Tank Manway supplied by Wenzhou Xusheng Machinery Industry and Trading Co., Ltd.. Bulk wholesale pricing ranges from $450 to $500 per Piece with a minimum order of 1 Piece. Inquiry for latest prices.
Pressure:
1-3 Bar
Height Of Neck:
100mm, 120mm, 150mm, 240mm
Temperature Range:
120degree Celsius~200 ℃degree Celsius
Specification:
25"-49"
Specifications:
25"/31"/37"/43"/49"
Package Size:
50.00cm * 50.00cm * 35.00cm
Production Capacity:
500 Sets/Month
HS Code:
7326909000
Specifications
Pressure:
1-3 Bar
Height Of Neck:
100mm, 120mm, 150mm, 240mm
Temperature Range:
120degree Celsius~200 ℃degree Celsius
Specification:
25"-49"
Specifications:
25"/31"/37"/43"/49"
Package Size:
50.00cm * 50.00cm * 35.00cm
Production Capacity:
500 Sets/Month
HS Code:
7326909000
Package Gross Weight:
75.000kg
Material Quality:
AISI304(1.4301)/316L(1.4404)
Certification:
CE
Trademark:
COMPASS
Model NO.:
CP-CM66005
Custom:
Customizable According to Needs
Customized:
Customized
Seat Material:
EPDM, Silione, FKM, NBR
Trade Term:
FOB, CIF, CFR, EXW
Power Source:
Head
Way Of Openning:
Inward Openning Manway
Payment Term:
LC, D/P, T/T, PayPal, Western Union, Small-amount payment
Origin:
Made in China
Automatic Grade:
Manual
Surface Treatment:
Mirror Polished, Matte, Sand-Blasting Finished
Port Of Loading:
Ningbo Port, Shanghai Port
Service:
OEM ODM
Application:
Pet Food, Chocolate, Ice Cream, Vegetable, Fruit, Dairy, Beverage
Handle Wheel Type:
Plastic or Stainless Steel
Type:
Pressure Tank Cover
Name:
Quick Open Inward Manway
Internal Surface:
Ra-0.8um-0.4um
Transport Package:
Shrink Wrap-Carton Case-Exporting Plywood Case
Connection Standard:
Welded
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
2011-07-07
Annual Revenue Amount:
Not specified
Numbers Of Employees:
26
Preferred Payment Term:
LC, D/P, T/T, PayPal, Western Union, Small-amount payment
Preferred Trade Term:
FOB, CIF, CFR, EXW
Port Of Loading:
Ningbo Port, Shanghai Port
Certificates:
Audited Supplier, Audited Supplier for Wenzhou Xusheng Machinery CO.,LTD, Bureau Veritas, CE Electrical Certification, EPDM FDA Report, ISO9901-2008 Certificate of Registration, SGS, Siliocne FDA Report
Product descriptions from the supplier
Stainless Steel SS316 Food Grade Round Pressure inward CM-2 Shell Tank Manway
Compass CM-2 quick-release manways extend into the tank, forming a watertight seal using a standard ASME flanged, dished cap and a user-replaceable gasket. The handwheel mechanism activates exclusively when the container is fully drained, enabling rapid entry in just seconds—no bolts to remove or tools required. Meets OSHA standards for permit-required confined spaces.Model CM-2 manways offer direct access to the sides of both new and existing stainless or carbon steel tanks, whether bolted or welded. Every CM-2 unit is custom-built to match your exact needs, such as material type, wall gauge, tank curvature, hydrostatic pressure, and appropriate sealing for the stored substance.
For areas where welding is not allowed, obtain a custom mounting flange ring aligned with your exact requirements (Model CM-2P - Steel Wall Tank). These rings are formed to match the tank’s curvature and secured to the manway sleeve for bolted assemblies in steel tanks. The unit supports special configurations and may include sightglass and sampling fittings as needed.
Every manway includes an OSHA-compliant lockout/tagout mechanism to stop unintended opening or closing. Due to the tank’s internal pressure pushing the lid firmly against the seal, the cover remains securely closed whenever the contents exceed the manway’s level. Additionally, a Security Cover is available that fits over the outside of the manway, locking the handwheel and hinge mechanism in place for added protection.
Specification:
|
Product Name:
|
Sanitary CM-2 Shell Manway Manhole |
|
Material:
|
Contacted parts with medial AISI304 , AISI316L /Other parts are AISI304
|
|
Pressure:
|
Standard pressure 0-3Bar,Max.is up to 1.6MPA
|
|
Welding Size:
|
25"(635mm)-49"(1244.6mm),Larger size can be manufcture according to the client requirment
|
|
Height:
|
Standard 100- 240MM , but can be changed as per customer's demands
|
|
Wall thickness of neck:
|
Standard 3-20MM , but can be changed as per customer's demands
|
|
Wall thickness of cover:
|
Standard 3MM/16MM , but can be changed as per customer's demands
|
|
Gasket:
|
Silicone , EPDM , NBR ,FKM
|
|
Internal surface:
|
0.8um-0.4um
|
|
External surface:
|
Mirror polished , Matter , Sand-blasting finished
|
|
Handle wheel Type:
|
Plastic or Stainless Steel
|
|
Certificate:
|
ISO9001
|
|
Temperature:
|
120-200 ºC
|
| For more information or any question, please feel freely to contact with us here | |
| Size Designed By WENZHOU COMPASS MACHINERY COMPANY | |||
| TYPE | SIZE | A | B |
| Inward quick open manway | 20" | 20" | 25" |
| 24" | 24" | 31" | |
| 30" | 30" | 37" | |
| 36" | 36" | 43" | |
| 42" | 42" | 49" | |
Sanitary manhole lids are fabricated from stainless steels SS304 and SS316L. Both outer and inner surfaces can be finished to a 600-grit polish. Additionally, dimensions, frame design, lid structure, and gasket configurations can be customized as per customer needs.
Technical Requirment:
Gasket:Silicone/EPDM/NBR/FKM in accordance with FDA177.2600.
Material:SS304(1.4301),SS316L/1.4404
Material:SS304(1.4301),SS316L/1.4404
Internal surface:0.8um-0.4um
Outside surface:Mirror polished,Matte,Sand-blasting Finished
The Feature of product:
Outside surface:Mirror polished,Matte,Sand-blasting Finished
The Feature of product:
1.safe quick-opening access
2.clean-out processes.
3.Inward opening and pressure application
4.Easy to observe the liquid in the tank
5.install in the tank side or at the bottom
5.install in the tank side or at the bottom
6.Corrosion resistant.
Other materials are available
• Sightglasses and Lights
• Drilled Mounting Flanges for retro-fit to existing bolted cover manways
• Custom Fittings for special applications
Other materials are available
• Sightglasses and Lights
• Drilled Mounting Flanges for retro-fit to existing bolted cover manways
• Custom Fittings for special applications
The Advantage of product:
Manhole refers to the open structure used for personnel to enter and exit the equipment for installation, maintenance, and safety inspection.
Constructed from FRAME, GASKET, COVER, and HANDLE, this unit serves as a dependable part used across Water Storage Tanks, Wastewater Systems, Treatment Plants, and Ethanol Processing and Storage Tanks—available in diverse dimensions and materials, suitable for both pressurized and non-pressurized environments.
Widely used in hygiene processes across breweries, dairy, food, cosmetics, and bio-pharmaceutical sectors. Applied in industrial settings including paper production, thick pulp storage, sewage management, wastewater facilities, municipal water reservoirs, processing tanks, farm silos, and various engineered storage units. Suitable for both newly built facilities and retrofitted sites. Modernizes outdated screwed-on tank lids to enable rapid access—within seconds instead of hours
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
Stainless steel manhole covers feature an intelligent, user-centered design with a refined look and full wall reinforcement offering superior resistance to pressure, heat, and rust, significantly boosting longevity. The design is straightforward, easy to install, and adaptable to various applications. Crafted with precision, each piece undergoes rigorous quality checks, ensuring attention to every component and every standard.
Established in 2011, Xusheng Machinery, a worldwide leader in sanitary valve solutions, has evolved into a top-tier producer of high-precision stainless steel sanitary valves, pipe fittings, pumps, and tanks.
The facility employs 112 staff members, spans 4035 square meters, and includes a 1000 square meter warehouse. We operate 29 LG Mazak and other Japanese-origin CNC machines, along with 2 fully automated machining systems.
We ensure superior quality through comprehensive quality control tools: one Ra roughness tester, three stainless steel spectrometers, multiple roundness testers, and several thickness gauges instrument, numbers of radius instrument, 3 nos pressure testing center.
Xusheng Machinery is still developing and innovating new products to ensure that the products are more energy-efficient, efficient and competitive.
Q1. Are you a trading company or factory?
We are a manufacturing factory.
Q2. What's the payment terms?
For small testing orders,we accept Paypal,Western Union,T/T and credit Card.
For mass orders,we accept T/T and L/C.
Q3.How do you control the quality?
Strict quality management ensures no material cross-contamination or substandard output. Quality checks are implemented at every stage, from sourcing to final delivery. We exclusively use 304 and 316L stainless steel variants. Every raw batch undergoes full verification. Throughout manufacturing, materials are segregated and handled separately. Upon completion, a random 10% sample is tested. Should even 0.1% of that sample show defects, we refuse to proceed with full-scale inspection.
Q4.If there is any quality problem,how do you solve it?
We take pride in never losing a single customer. We understand no product is flawless, and minor defects may occur. We strive to deliver accurate materials from the outset, minimizing the time needed to resolve issues. Should any defects arise, we fully own them. We trust that the partnership we build will yield positive results in the future. If we fail to uphold our duties, customers will walk away. But as long as we consistently fulfill our commitments, we retain their trust and loyalty.
Q5.How long is your delivery time?
For normal production in 7-10days.For bulk order in 15-25days.
Q6.Warranty
One year warranty for all of our stainless steel products.Gaskets are not included due to the different application for customers.
How to order ?Sanitary pressure quick open manway
1. What's type? inward or outward
2. What size ? 20" to 49"
3. What's material ? SS304/SS316L
4. What size of frame thickness?5-15MM
5. what height of manhole?100-300MM
6. What's handle type ? stainless steel
7. What's seal material ? FKM,SILICONE,NBR
8. Do you need mirror or matte polish ?
