Testing Machine Tester/Machine/Equipment with Yield Strength
1 Piece
$9,1271 Piece
$5,888Product information
High-quality Testing Machine Tester/Machine/Equipment with Yield Strength supplied by Suzhou Qiantong Instrument Equipment Co., Ltd.. Bulk wholesale pricing ranges from $5,888 to $9,127 per Piece with a minimum order of 1 Piece. Inquiry for latest prices.
Accuracy Grade:
0.5
Production Capacity:
1000 Set/Year
Maxcapacity:
100kn
Specification:
1050*600*2010mm
Maximum Stretch Stroke:
1100mm
Weight:
500-1000Kg
HS Code:
9024101000
Power Source:
AC380V
Specifications
Accuracy Grade:
0.5
Production Capacity:
1000 Set/Year
Maxcapacity:
100kn
Specification:
1050*600*2010mm
Maximum Stretch Stroke:
1100mm
Weight:
500-1000Kg
HS Code:
9024101000
Power Source:
AC380V
Control:
Computer Control
Customerized Or Not:
Customerized
Loading Method:
Dynamic Load
Oil Cylinder Position:
Electronic
Load Way:
Electronic Load
Trade Term:
FOB, CIF, CFR
Origin:
Jiangsu, China
Payment Term:
LC, T/T
Display:
PC Computer
Model NO.:
QT-6100 Series
Trademark:
SUZHOU QIANTONG
Port Of Loading:
Shanghai Port
Type:
Universal Testing Machine
Transport Package:
Wooden Case
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
2014-12-03
Annual Revenue Amount:
Not specified
Numbers Of Employees:
39
Preferred Payment Term:
LC, T/T
Preferred Trade Term:
FOB, CIF, CFR
Port Of Loading:
Shanghai Port
Certificates:
Differential pressure valve, Double column gantry tensile testing machine, Double-range testing machine, Electromagnetic strip stripping fixture, extensometer, Gantry tensile testing machine, HALOGEN MOISTURE METER, ISO, Lock testing machine, Melt Flow Rate Measurer, Microelectronic balance(300g), National High Tech Enterprises, PV peeling testing fixtures, SGS CE ccertificate, Single column tension machine, Type approval certificate for measuring instruments, Wire rope tensile testing fixtures, Wire rope winding tension fixture
Product descriptions from the supplier
1. Qiantong main scope of testing machine
Electronic universal material testing machine, Horizontal tension testing machine, Hydraulic universal testing machine, MFI, Charpy Impact, Izod Impact, HDT-Vicat tester, Hardness tester, Torsion tester, Metallographic series, Oven and so on. (We accept customization.)
2. Product
Brief: It adopts full digital power, displacement and speed three closed loop control, using AC motor and control drive system, with Taiwan precision worm gear reducer and Taiwan TBI precision screw drive to achieve the transmission efficiency and signal-to-noise ratio of the best effect.Function: Tester is used to test physical properties of elongation, compression, peeling, tearing bending, 3-point bending, shearing of metallic and non-metallic material and so on.
Meeting standards: It can be customized to meet GB, ISO, JIS, ASTM, DIN requirement and the standard provided by client to test and data processing.
Application ranges: This machine is commonly applied in material analysis in auto-parts, fastener, aerospace, cable and wire, plastic and rubber, paper packing industries.
3. Features of control and data processing system
1) With advanced chipping technology and professionally designed data gathering and amplifying system,the tester is highly integrated,reliable and convenient. Control software automatically derives data of tensile strength, yield strength, fracture strength, modulus of elasticity, elongation.The open formula edition function allows automatic calculation of force, tension displacement deformation at any designated point. The standard in the process of control and data processing meet national requirement for testing metallic material and non-metallic material.
2) Control method: fixed speed, fixed displacement, fixed loading, fixed load increasing rate,fixed tension, fixed tension increase rate.
3) Automatically resetting: After the test begins, measuring system automatically reset to zero.
4) Automatic shifting: automatically changes range when load changes to make sure precise collection of data.
5) Automatic saving: testing data and testing condition are automatically stored to avoid data loss caused by forgetting saving.
6) Batch testing: For specimen with same setting, batch test can be performed after setting the test sequence.
7) Display mode: data and curve are presented while testing.
8) Curve display: after testing, it is possible to revisit the curve to analyze. Move your mouse on the curve to find relative data at each point.
9) Curves: parameters: stress-strain, force-displacement, force-time, displacement-time results are displayed and printable.
10) Parameters: force parameters(g,kg,N,lb)
stress parameters(kg/mm2,N/mm2,Mpa,lbf/in2)
Displacement parameters (m,mm,in)
11) Test report: test reports are edited and printed according to the desired format by client and can be output as Excel files
12) Safety protection : safety mechanism is triggered when overloading is above 2~10%
13) The tester is able to automatically test and calculate mechanic property of specimen. It is also possible to intervene manually in the analyzing process. Automatic analyzing test results are revised according to relevant standard to improve data accuracy.
4. Specifications
| Type | QT-6100S | QT-6100W | QT-6100S | QT-6100W |
| Load capacity | 5T | 5T | 10T | 10T |
| Precision level | 0.5 | 0.5 | 0.5 | 0.5 |
| Test force resolution | 1/±500000 | 1/±300000 | 1/±500000 | 1/±300000 |
| displacement resolution | 0.0005mm | 0.0005mm | 0.0005mm | 0.0005mm |
| Speed (mm/min) | 0.005-500 | 10-300 | 0.005-350 | 10-300 |
| Motor | Servo motor(upgrade) | Servo motor | Servo motor(upgrade) | Servo motor |
| Control method | Fully closed loop | Semi closed loop | Fully closed loop | Semi closed loop |
| Display method | PC software | PC software | PC software | PC software |
| Recovering speed (mm/min) | 300 | 100 | 300 | 100 |
| Measurement range | 2%-100%FS | 2%-100%FS | 2%-100%FS | 2%-100%FS |
| Relative deviation | ±0.5% within indication | ±0.5% within indication | ±0.5% within indication | ±0.5% within indication |
| Maximum stretch stroke | 1100mm | 1100mm | 1100mm | 1100mm |
| Effective stretching space | 680mm | 680mm | 680mm | 680mm |
| Effective testing width | 420*420mm | 420*420mm | 420*420mm | 420*420mm |
| Dimension | 1050*600*2010mm | 1050*600*2010mm | 1050*600*2030mm | 1050*600*2030mm |
| Power | 220V 50Hz 1.5kW | 220V 50Hz 2kW | 380V 50Hz 2kW | 220V 50Hz 2.6kW |
| Weight | 600kg | 600kg | 650kg | 850kg |
Some cooperative brands(This ranking is in no order)
About certifications
FAQ
Q:Are you a trade company or factory?
A:Our company is a factory and directly sales.
Q:Can your company accept customization?
A: Yes. Our machines can be customized by client.
Q:How to guarantee your after-sales service?
A:Our philosophy is one year warranty and lifetime service. After the warranty period is exceeded, if there is any problem, we will provide support for you in time. (only charge travel expense and parts cost at most.)
Q:What is the different between Type-S and Type-W?
A:Type-S can test multistep experiment, hold loading,bending, yield strength, modulus of elasticity with import upgrade servo, but the Type-W can not do these tests.
Q:May the customer not use your company's computer?
A:Sure. But please tell us what type your computer is. We need to confirm your computer can install the software. And we can subtract the price of computer from offer.
Q:How to install and operate?
A:We will give a U disk with operating video. About the installing, just plug in and use.
Q:Do you have other testers?
A:Sure.If there is no machines which can make you satisfied. We can give you the catalogue of complete products by email.
Attention please: the price of all the machines is negotiable. If you need one, please contact
