Thick Rubber Anti-Impact Heavy-Load Ground Protection Mat
100-1999 kg
$4.82000-4999 kg
$4.35000-9999 kg
$3.510000 kg
$2.1Product information
High-quality Thick Rubber Anti-Impact Heavy-Load Ground Protection Mat supplied by QINGDAO WAYTOP INDUSTRY CO., LTD.. Bulk wholesale pricing ranges from $2.1 to $4.8 per kg with a minimum order of 100 kg. Inquiry for latest prices.
Density:
0.93-0.96 g/cm3
Warranty:
1 Year
Package Size:
100.00cm * 100.00cm * 1.00cm
Package Gross Weight:
2000.000kg
Tensile Strength:
30~40MPa
HS Code:
3926100000
Production Capacity:
5000000kg/Years
Thickness:
6mm-45mm Customization
Specifications
Density:
0.93-0.96 g/cm3
Warranty:
1 Year
Package Size:
100.00cm * 100.00cm * 1.00cm
Package Gross Weight:
2000.000kg
Tensile Strength:
30~40MPa
HS Code:
3926100000
Production Capacity:
5000000kg/Years
Thickness:
6mm-45mm Customization
Surface:
Anti Slip Surface
Sample:
Availble
Origin:
China Shandong Qingdao
Refund Policy:
Claim a refund if your order doesn't ship, is missing, or arrives with product issues.
Transport Package:
Conforming Wooden Pallets / Iron Pallets
Shipping Cost:
Contact the supplier about freight and estimated delivery time.
Processing Service:
Cutting
Hardness:
D 65
Trade Term:
EXW, CFR, CIF, FOB
Kind:
Engineering Plastic Sheet
Model No.:
Ground Mats
Certificate:
ISO9001:2008
Material:
PE
Application:
Plastic Car Packing Mats Heavy Machinery on The Co
Port Of Loading:
Qingdao Port
Specification:
Size can be customized accordingto customer needs
Payment Term:
Small-amount payment, PayPal, Western Union, D/P, T/T, LC
Payment Methods:
Support payments in USD
Trademark:
Waytop
Model NO.:
mats
Water Absorption:
＜0.01%
Contraction Percentage:
＜0.4%
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
2019-03-05
Annual Revenue Amount:
Not specified
Numbers Of Employees:
17
Preferred Payment Term:
Small-amount payment, PayPal, Western Union, D/P, T/T, LC
Preferred Trade Term:
EXW, CFR, CIF, FOB
Port Of Loading:
Qingdao Port
Certificates:
CE, RoHS
Product descriptions from the supplier
Engineering data of the ground mats
| Unit | HDPE | |
| Mechanical Properties | ||
| Tensile strength | MPa | 23-26 |
| Flexural strength | MPa | 25-28 |
| Flexural modulus | MPa | 1936-1967 |
| Charpy Notched Impact Strength | KJ/m² | 5-6 |
| Poisson's ratio | (theoretical) | 0.35-0.38 |
| Compression testing(max value before test terminated) | Tons | 250 |
| General Properties | ||
| Density | KG/m³ | 940-965 |
| Shrinkage | % | 2-4 |
| Water absorption | % | 0.01 |
| Thermal expansion | e-6/K | 110-130 |
| Thermal conductivity | W/mk | 0.46-0.52 |
| Specific heat | J/kg.k | 1800-2700 |
| Melting temperature | ºC | 108-134 |
| Glass temperature | ºC | -110- +110 |
| Service temperature | ºC | -30- +85 |
| Resistivity | ohm.mm²/m | 5e+17-1e+21 |
| Break down potential | kV/mm | 17.7-19.7 |
| Dielectric loss factory | 0.0005-0.0008 | |
| Friction coefficient | 0.25-0.30 | |
| Refraction index | 1.52-1.53 |
Popular size of composite HDPE/UHMWPE ground protection mats:
Other size can be customized as your requirement,these are the best size to load the container.
|
Item No.
|
Size(mm)
|
Weight(kg) |
Effective area
(m2)
|
Loading capacity(ton)
|
Loading container&calculate
|
|
WP01
|
2400×1200×12.7 |
40
|
2.88
|
40
|
360 pcs in 20'GP 650 pcs in 40'GP |
|
WP02
|
2440x1220x12.7 |
42
|
2.98
|
40
|
350 pcs in 20'GP 630 pcs in 40'GP |
|
WP03
|
2000x1000x10 |
22.6
|
2
|
30
|
660 pcs in20'GP 1150 pcs in 40'GP |
|
WP04 |
2900x1100x12.7 |
45
|
3.2
|
40
|
400 pcs in 20'GP 630 pcs in 40'GP |
| WP05 | 3000x1500x15 | 74 | 4.5 | 80 | 332 pcs in 40'GP |
| WP06 | 5900x2000x28 | 345 | 11.8 | 120 | 76 pcs in 40'HQ |
| WP07 | 5800x2000x52 | 573 | 10.6 | 150 | 48 pcs in 40'HQ |
| WP08 | 3000x2500x38 | 293 | 7.5 | 120 | 82 pcs in 40'GP |
| WP09 | 4500x2000x38 | 351 | 9.0 | 120 | 70 pcs in 40'GP |
| WP10 | 3000x2500x25 | 195 | 7.5 | 120 | 126 pcs in 40'GP |
| WP11 | 5930x2130x80 | 620 | 12.0 | 120 | 42 pcs in 40'HQ |
|
Remark: --Material: UHMWPE (ultrahigh molecular weight polyethylene) --For tracked vehicle --Recommend thickness: ≥30mm --Colour: black,white,yellow,red,etc. --Customer Logo is available |
|||||
Heavy Duty Comstruction Composite HDPE Temporary Access Ground Protection Track Mats for Heavy Equipment
1.Serveral surface for your choice:
We have various non-slip texture surface of UHMWPE composite construction ground protection mat for your choice:
( Temporary Ground Protection Mats For Construction Site And Heavy Equipment)
2.Assembly method of composite HDPE/UHMWPE ground protection mats:
In addition to ground protection mats, we can also provide outrigger pads for heavy equipment, which is made of high quality UHMWPE(Ultra High Molecular Weight Polyethylene) that will not crack or splinter.These pads are easy to install and offer a safe working environment for heavy equipment with outrigger arms.These pads feature a durable design that is chemical and oil resistant.Outrigger pads from Shandong Waytop are impermeable to water,which makes them ideal for all weather conditions.
 |
 |
Multiple assembly methods are available, which can better meet your needs:
( Different assembly methods.The combined strength of HDPE/UHMWPE ground protection mats varies.)
The size,thickness,color and shape of the crane outrigger pads can be customized as you need,here I attached some pictures of custom outrigger pads for your reference.
Shandong Qingdao Waytop Chemical Co., Ltd. has become the largest manufacturer of engineering plastics in China. Waytop's main engineered plastic products include UHMWPE sheets and rods , HDPE sheets and rods PP sheets and PVC sheets,etc . We can also supply a huge range of custom machined plastic parts such as Marine fender , Ground protection mats , Compositerig mats , as well as Ice rink series products like Ice rink dasher board , synthetic ice panel and hockey shooting pads.
Our industrial plastic products are widely used in North America, Europe, Australia , Southeast Asia, Africa , Russia and many organizations and government projects due to their outstanding properties. Waytop engineered thermoplastics are chemical and extremely strong compared to common plastics.
We manufacture all plastic products in strict accordance with ISO9001 production standards. Meanwhile we passed UL factory Audit,SGS Quality Audit , and kinds of third party lab tests for different products , to guarantee a high-quality , high-standard , safe and healthy production environment for workers and customers .
We always share the things " Quality first , Customer first , keeping improving" to win more benefits for our partners .
Waytop welcome for your cooperation !
1.how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
2.what can you buy from us?
UHMWPE febder pads;
crane outrigger pads;
wear-resisting liners;
radiation sheilding material;
UHMWPE/HDPE parts;
HDPE sheets;
Light/Heavy duty ground mats;
Ice rink products
3.why should you buy from us not from other suppliers?
We are very confident with our in-house system Also as we produce variety of products used in the same field, the clients can get the variety of product mix under one roof
4.what services can we provide?
Accepted Delivery Terms: FOB;
Accepted Payment Currency:USD
Accepted Payment Type: T/T,L/C;
If you have any inquiry and interest about our UHMWPE/HDPE Temporary Ground Event Mats Plastic Construction Road Panel, please contact me freely. We are here for you for 24 hours.
