Three Motor Seven Motor System Medium-Speed Plastic Film Rotogravure Printing Machine
1-49 Piece
$105,00050 Piece
$65,000Product information
High-quality Three Motor Seven Motor System Medium-Speed Plastic Film Rotogravure Printing Machine supplied by Wenzhou Yibo Machinery Co., Ltd. Bulk wholesale pricing ranges from $65,000 to $105,000 per Piece with a minimum order of 1 Piece. Inquiry for latest prices.
Register Precision:
0.1mm
Colors:
1-12colors
Package Size:
12000.00cm * 2600.00cm * 2800.00cm
Speed:
150-350m/Min
Package Gross Weight:
25000.000kg
Production Capacity:
500sets/Year
Specification:
650-1550mm
Unwinder Diameter:
800mm
Specifications
Register Precision:
0.1mm
Colors:
1-12colors
Package Size:
12000.00cm * 2600.00cm * 2800.00cm
Speed:
150-350m/Min
Package Gross Weight:
25000.000kg
Production Capacity:
500sets/Year
Specification:
650-1550mm
Unwinder Diameter:
800mm
Rewinder Diameter:
800mm
HS Code:
844317009
Automatic Grade:
Automatic
Origin:
China
Refund Policy:
Claim a refund if your order doesn't ship, is missing, or arrives with product issues.
System Supported:
Computer
Shipping Cost:
Contact the supplier about freight and estimated delivery time.
Drying Method:
Electric Heating
After Sales Service Provided:
Engineers Available to Service Machinery Overseas
Trade Term:
FOB, EXW, CFR, CIF, DAT, DDP, DAP, FCA
Transport Package:
Film
Applicable Material:
Film, Paper, Plastic
Payment Term:
LC, T/T
Suitable Material:
LLDPE Pet BOPP CPP Film
Color & Page:
Multi-Colour Printing Press
Condition:
NEW
Port Of Loading:
NINGBO, WENZHOU
Warranty Of Core Components:
One Year
Usage:
Rigid Packaging Gravure, Flexible Packaging Gravure Printing Machine, Publication Gravure Machine
Structure:
Rotary Type Printing Machine
Name:
Rotogravure Printing Machine
Arrangement Position Of Color Groups:
Satellite Gravure Machine
Payment Methods:
Support payments in USD
Printing Interface:
USB3.0
Feeding Mode:
Web Gravure Printing Machine
Model NO.:
ZB
Trademark:
ZONBAN
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
2020-11-11
Annual Revenue Amount:
Not specified
Numbers Of Employees:
Not specified
Preferred Payment Term:
LC, T/T
Preferred Trade Term:
FOB, EXW, CFR, CIF, DAT, DDP, DAP, FCA
Port Of Loading:
NINGBO, WENZHOU
Certificates:
BAG MAKING MACHINE, EXTRUDER MACHINE, FLEXO PRINTING MACHINE, SLITTING MACHINE
Product descriptions from the supplier
Main technical parameters:
Print flow direction from left to right
Printing color number 7 colors 11unit
Printing width range 750-1150mm
Max mechanical Speed 170m/min
Max Printing Speed 150m/min
Plate cylinder dia. Ф150mm-Ф350mm
Plate cylinder width 750-1150mm
Color control precision Vertical:±0.1mm(Automatic) ±0.1mm()
Horizontal:±0.1mm(Manual) ±0.1mm()
Max. Unwinding dia. ∮800mm
Max. Rewinding dia. ∮800mm
Tension adjusting range 3-30kg
Unwinder &Rewinding air shaft 3"*1300mm(With safely chuck )
Air supply pressure 0.8Mpa
Press of impression 500kg
Doctor move range ±5mm
Dry method Electricity
Dry Power 180KW
Total power: about 260KW
Size: 20000x3500x3000(mm)
Weight: 24000kg
Base material & compound material
PVC 80-350um PET 12-60um
OPP 20-60um BOPP 19-60um
CPP 20-60um NY 12-50um
PE 30-100um Lamination film 15-60um
And other materials are familiar with the above films.
Unwinder Parts
Unattached tower type double arm& double station whirling stand and wallboard stander 1 set
Web used 3" pneumatic shaft 3" 2 pieces
Unwinder drive device: AC7.5KW (SIEMENS motor+ Vector transducer, Yaskawa, )2 pieces
Auto splicing device-including cutting blade 1 set
Dance roll tension inspecting device(including Fujikura ,Japan low friction cylinder, Shanghai ,precision regulation
resistance , SMC ,Japan precision air pressure regulator) 1 set
Web turning AC gear down motor 0.75KW: 1 set
Web diameter inspection &alarm device 1 set
Operation control box 1 set
|
item
|
value
|
|
Type
|
Rotogravure Printing Machine
|
|
Applicable Industries
|
Food & Beverage Factory, Printing Shops
|
|
Showroom Location
|
Italy, Saudi Arabia, Thailand, Bangladesh, Uzbekistan
|
|
Video outgoing-inspection
|
Provided
|
|
Machinery Test Report
|
Provided
|
|
Marketing Type
|
Ordinary Product
|
|
Warranty of core components
|
1 Year
|
|
Core Components
|
PLC, Gearbox, Motor
|
|
Condition
|
New
|
|
Place of Origin
|
China
|
|
|
Zhejiang
|
|
Brand Name
|
zonban
|
|
Usage
|
Paper Printer, Label Printer
|
|
Automatic Grade
|
Automatic
|
|
Color & Page
|
Multicolor
|
Packaging & Delivery
1.Packaging Details: wooden pallet or plastic film
2.Delivery Detail: 30-60 days
3.Port: Ningbo port
1.Where is your factory Located
Our Factory Located in Ruian City ,Zhejiang Province ,China .
It is about 40minutes by plane from Shanghai, about 5 hours by train from
Shanghai .
We are pleasured to pick up you when you arrived .
2. What should we charge for your engineer?
Our engineer is available to go to your country to install the machine for you. Buyer have to bear the charges including round-trip tickets, cost of visa and accommodations .Salary for one engineer is 150USD per day.
3. How long is your machine's warranty period?
All our machine have one year guarantee, starting from finished installation.
