Toxic Combustible Vehicle Exhaust Gas Analyzer
1 Piece
$1,0001 Piece
$1Product information
High-quality Toxic Combustible Vehicle Exhaust Gas Analyzer supplied by Shandong China Coal Industrial & Mining Supplies Group Co., Ltd.. Bulk wholesale pricing ranges from $1 to $1,000 per Piece with a minimum order of 1 Piece. Inquiry for latest prices.
Hc:
0~10000X10-6 (Ppm)Vol
Co:
0~10X10-2 (%)Vol
CO2:
0~20X10-2 (%)Vol
O2:
0~25X10-2 (%)Vol
No:
0~40000 10-6 (Ppm)Vol
Minimum Order Quantity:
1 Set
Production Capacity:
1000 Sets Per Month
Package Gross Weight:
24.000kg
Specifications
Hc:
0~10000X10-6 (Ppm)Vol
Co:
0~10X10-2 (%)Vol
CO2:
0~20X10-2 (%)Vol
O2:
0~25X10-2 (%)Vol
No:
0~40000 10-6 (Ppm)Vol
Minimum Order Quantity:
1 Set
Production Capacity:
1000 Sets Per Month
Package Gross Weight:
24.000kg
Packing Size:
420*320*250mm
Package Size:
60.00cm * 70.00cm * 30.00cm
Gross Weight:
9.8kg
Certification:
CE
Specification:
CE, SGS
Transport Package:
Carton Box, Plastic Bagsor as Your Payment
Origin:
China
Brand:
China Coal
Trademark:
China Coal
Refund Policy:
Claim a refund if your order doesn't ship, is missing, or arrives with product issues.
Measuring Range:
Co, CO2, Hc, O2, No
Shipping Cost:
Contact the supplier about freight and estimated delivery time.
Customized:
Customized
Trade Term:
FOB
Price Terms:
Fob
Model NO.:
HPC501
Gas:
Hc, Co, CO2, O2
Type:
Infrared Absorption Analyzer
Payment Term:
LC, T/T, Western Union
Portable:
Portable
Port Of Loading:
Qingdao, Ningbo,Shanghai,Shenzhen
Payment Methods:
Support payments in USD
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
2008-08-01
Annual Revenue Amount:
Not specified
Numbers Of Employees:
Not specified
Preferred Payment Term:
LC, T/T, Western Union
Preferred Trade Term:
FOB
Port Of Loading:
Qingdao, Ningbo,Shanghai,Shenzhen
Certificates:
Alibaba Certification, Cayman Business License, CE Certificate of Gas Detector, CE Certificate of Mine Car, CE Certificate of Packaging Machine, CE Certificate of Railway Maintenance Machine, CE Certificate of Winch, CE for Drills Equipment, Crawler Crane CE Certificate, ISO, MA Certificate, Mining Car CE Certificate, Rock Loader CE Certificate, Self Rescuer CE, SGS, Shaft Sinking Winch CE Certificate, Sliding Stop Buffer Utility Model Patent Certificate, Spiral Handle Tight Sealing Mine Door Utility Model Patent Certificate, TUV SUD Certification and Testing
Product descriptions from the supplier
An Exhaust Gas Analyzer (EGA), also commonly known as an emission analyzer, is a sophisticated diagnostic instrument designed to measure the concentration of specific gases present in the exhaust stream of internal combustion engines. It is a critical tool for automotive repair, environmental compliance testing, and engine performance research.
The primary function of the analyzer is to quantify key pollutant gases, most notably hydrocarbons (HC), carbon monoxide (CO), carbon dioxide (CO2), and oxygen (O2). For modern vehicles equipped with catalytic converters, it also precisely measures oxides of nitrogen (NOx). The device operates by extracting a sample of exhaust gas, typically via a probe inserted into the vehicle's tailpipe. This sample is conditioned (filtered, dried, and cooled) before being channeled into a series of dedicated sensors. Each gas component is detected using specific technologies: Non-Dispersive Infrared (NDIR) sensors for HC, CO, and CO2; electrochemical cells for O2 and NOx.
HPC501
| Model | HPC501 |
| Measurement Range | HC: 0 ~ 10,000 ppm (vol) CO: 0 ~ 10% (vol) CO2: 0 ~ 20% (vol) O2: 0 ~ 25% (vol) NOx: 0 ~ 5,000 ppm (vol) λ (Air-Fuel Ratio): 0.50 ~ 3.00 COcor (Corrected CO): 0 ~ 10% (vol) |
| Indication Error | HC: ±12 ppm (Absolute) or ±5% (Relative) CO: ±0.06% (Absolute) or ±5% (Relative) CO2: ±0.5% (Absolute) or ±5% (Relative) O2: ±0.1% (Absolute) or ±5% (Relative) NOx: ±25 ppm (Absolute) or ±4% (Relative) |
| Repeatability | Error ≤ ±2% |
| Stability | Automatic zero calibration; Span drift ≤ ±3% |
| Resolution | HC: 1 ppm CO: 0.01% CO2: 0.1% O2: 0.01% NOx: 1 ppm λ: 0.01 |
| Response Time | ≤ 10 seconds (for 95% response) |
| Warm-up Time | 8 minutes (3-minute emergency warm-up available) |
| Output | Direct digital display. Supports optional printer for output of gas names, max concentrations, test time/date, etc. Equipped with interfaces for computer networking. |
| Environmental Conditions | Operating Temperature: -5°C to +50°C Relative Humidity: ≤ 90% |
| Power Supply | AC 100-240V, 50/60Hz, or DC 12V (requires optional power inverter) |
| Power Consumption | 40 VA |
| Dimensions (L × W × H) | 420 mm × 310 mm × 170 mm |
| Weight | Approx. 9 kg |
HPC500
| Model | HPC500 |
| Measurement Range | HC:0~10000×10-6(ppm)vol CO:0~10×10-2(%)vol CO2:0~20×10-2(%)vol O2: 0~25×10-2(%)vol NOx:0~5000×10-6(ppm)vol λ:0.50~3.00 COcor:0~10×10-2(%)vol |
| Engine Speed | 0-9990rpm |
| Oil Temperature | 0-150ºC |
| Indication Error | HC: ±12 × 10^-6(ppm) vol (absolute error) or ±5% (relative error) CO: ±0.06 × 10^-²(%) vol (absolute error) or ±5% (relative error) CO2: ±0.5 × 10^-²(%) vol (absolute error) or ±5% (relative error) O2: ±0.1 × 10^-² (%) vol (absolute error) or ±5% (relative error) NOx: ±25 × 10^-6(ppm) vol (absolute error) or ±4% (relative error) |
| Repeatability | Repeat error ≤ ±2% |
| Stability | Automatic zero calibration; span drift ≤ ±3% |
| Resolution | HC:1×10-6(ppm)vol CO: 0.01×10-2(%)vol CO2: 0.1×10-2(%)vol O2: 0.01×10-2(%)vol NOx:1×10-6(ppm)vol λ:0.01 |
| Engine Speed | 10rpm |
| Oil Temperature | 0.1ºC |
| Response Time | 95% response ≤ 10 seconds |
| Warm-up Time | 8 minutes (emergency testing possible after 3-minute preheat) |
| Output Method | Can display on screen or print maximum, average, and minimum gas concentrations, license plate number, test time, date, engine speed, oil temperature, λ, and COcor values. Equipped with interface for computer networking. |
| Environmental Conditions | Temperature: -5 to 50°C; relative humidity ≤ 90% |
| Power Supply | AC 100-240 V, 50/60 Hz, or DC 12 V (with optional power inverter) |
| Power consumption | 40 VA |
| Dimensions | 420 mm (L) × 310 mm (W) × 170 mm (H) |
| Weight | Approximately 9 kg |
HPC518
| Model | HPC518 |
| Measurement Range | HC: 0-10000×10^-6ppm vol (Gasoline, n-Hexane equivalent) or C3H8: 0-20000×10^-6ppm vol (LPG, Propane equivalent) |
| CO: 0-10×10^-²% vol | |
| CO2: 0-20×10^-²% vol | |
| O2: 0-25×10^-²% vol | |
| NOx: 0-5000×10^-6ppm vol | |
| λ (Lambda): 0.50-3.00 COcor | |
| 0-10×10^-²% vol | |
| Indication Error | HC (0-2000 ppm): ±4 ppm or ±3% |
| HC (2001-5000 ppm): ±5% | |
| HC (5001-10000 ppm): ±10% | |
| CO (0.00-10.00×10^-²%): ±0.02×10^-²% or ±3% | |
| CO (10.01-14.00×10^-²%): ±5% | |
| CO2(0.0-16.0×10^-²%): ±0.3×10^-²% or ±3% | |
| CO2 (16.1-20.0×10^-²%): ±5% | |
| O2: ±0.1×10^-²% or ±5% | |
| NOx: ±25 ppm or ±4% | |
| Stability | Automatic zero calibration, span drift ≤ ±3% |
| Repeatability | Repeat error ≤ ±2% |
| Resolution | HC: 1 ppm; CO: 0.01×10^-²%; CO2: 0.1×10^-²%; O2: 0.01×10^-²%; NOx: 1 ppm; λ: 0.01; RPM: 10 r/min; Oil Temp: 0.1 ºC |
| Response Time | ≤10 s (95% response) |
| Warm-up Time | 3 min (1 min for emergency testing) |
| Operating Conditions | Temperature: -5 to 50 ºC |
| Humidity: ≤90% | |
| Sensor Lifetime | Oxygen sensor: approx. 2 years |
| NOx sensor: approx. 14 months | |
| Power Supply | Built-in battery; DC 12 V vehicle power; AC 100-240 V, 50/60 Hz |
| Power Consumption | < 50 VA |
| Dimensions | 520×360×250 mm (L×W×H) |
HPC302
| Model | HPC302 |
| Measuring Range | HC: 0-10000×10^-6ppm vol |
| CO: 0-10×10^-²% vol | |
| NOx: 0-4000×10^-6ppm vol | |
| Indicating Error | HC: ±12×10^-6ppm (absolute error) or ±5% (relative error) |
| CO: ±0.06×10^-²% (absolute error) or ±5% (relative error) | |
| NOx: ±25×10^-6ppm (absolute error) or ±4% (relative error) | |
| Stability | Span drift ≤ ±3% |
| Repeatability | ≤ ±2% |
| Resolution | HC: 1×10^-6ppm vol |
| CO: 0.01×10^-²% vol | |
| NOx: 1×10^-6ppm vol | |
| Response Time | ≤10 s (95% response) |
| Preheating Time | 8 min (3 min for emergency detection) |
| Output Mode | Digital direct reading; printer connection available; gas name, maximum value, average value, minimum value, test time and date printable; computer network interface supported |
| Operating Conditions | Temperature: -5 to 50 ºC |
| Relative humidity: ≤90% | |
| Power Supply | AC 100-240 V, 50/60 Hz or DC 12 V (with power inverter) |
| Power Consumption | 40 VA |
| Dimensions | 420 × 310 × 170 mm (L×W×H) |
| Weight | 9 kg |
HPC400
| Model | HPC400 |
| Measuring range | HC: 0~10000×10-6(ppm)vol,CO: 0~10×10-2(%)vol ) CO2: 0~20×10-2(%)vol, O2: 0~25×10-2(%)vol R.M.P: 0~9999r.m.p OIL TEMP:0~150ºC Lambda: 0.50~3.00 COcor:0~10×10-2(%)vol |
| Indicatingerror | HC±12×10-6(ppm)vol ( absolute error ) or±5% ( relative error ) CO±0.06×10-2(%)vol ( absolute error ) or±5% ( relative error ) CO2±0.5×10-2(%)vol ( absolute error ) or±5% ( relative error ) O2±0.1×10-2(%)vol ( absolute error ) or±5% ( relative error ) |
| Stability | moment drift≤±3% |
| Repeatability | ≤±2% |
| Resolution | HC:1×10-6(ppm)vol, CO: 0.01×10-2(%)vol CO2: 0.1×10-2(%)vol, O2: 0.01×10-2(%)vol, Lambda: 0.01 R.P.M:10r.p.m, OIL TEMP:0.1ºC |
| Response time | 95% response is not more than 10 seconds |
| Preheating time | 8min ( preheating 3min emergency detection ) |
| Output Method | Output mode can display, print gas concentration maximum value, average value, the minimum value of the license plate number, test time, date, speed, temperature and COcor value of lambda, can interface with computer networking |
| And-use temperature | -5~50°C, Relative humidity: ≤90% |
| Power | AC100~240V 50/60Hz or DC12V( Add power inverter) Power consumption: 40VA |
| Dimension | 420 (L )×310(W)×170(H)mm |
| Weight | 9kg |
HPC401
| Model | HPC401 |
| Measuring range | HC:0~10000×10-6(ppm)vol CO:0~10×10-2(%)vol CO2:0~20×10-2(%)vol O2: 0~25×10-2(%)vol λ:0.50~ 3.00 COcor:0~10×10-2(%)vol |
| Indicatingerror | HC±12×10-6(ppm)vol ( absolute error ) or±5% ( relative error ) CO±0.06×10-2(%)vol ( absolute error ) or±5% ( relative error ) CO2±0.5×10-2(%)vol ( absolute error ) or±5% ( relative error ) O2±0.1×10-2(%)vol ( absolute error ) or±5% ( relative error ) |
| Stability | moment drift≤±3% |
| Repeatability | Repeatability≤±2% |
| Resolution | HC:1×10-6(ppm)vol, CO: 0.01×10-2(%)vol CO2: 0.1×10-2(%)vol, O2: 0.01×10-2(%)vol, Lambda: 0.01 R.P.M:10r.p.m, OIL TEMP:0.1ºC |
| Response time | 95% response is not more than 10 seconds |
| Preheating time | 8min ( preheating 3min emergency detection ) |
| Output mode | digital direct reading, gases can be attached printer name, in accordance with national standards and the average concentration of the maximum value, test time, date. Can interface with computer networking. |
| And-use temperature | -5~50°C, Relative humidity: ≤90% |
| Power | AC100~240V 50/60Hz or DC12V( Add power inverter)Power consumption: 40VA |
| Dimension | 420 (L )×310(W)×170(H)mm |
| Weight | 9kg |
