Ultraviolet Infrared Single Crystal CaF2 Prisms
200 Piece
$9.9200 Piece
$28.6Product information
High-quality Ultraviolet Infrared Single Crystal CaF2 Prisms supplied by Changchun Yutai Optics Co., Ltd.. Bulk wholesale pricing ranges from $9.9 to $28.6 per Piece with a minimum order of 200 Piece. Inquiry for latest prices.
Package Gross Weight:
1.000kg
Flatness:
1/4 Lambda
Package Size:
20.00cm * 20.00cm * 20.00cm
Specification:
5-300mm
Production Capacity:
50000/Year
Surface Quality:
60-40,40-20,20-10 etc
HS Code:
9001909090
Transport Package:
Carton
Specifications
Package Gross Weight:
1.000kg
Flatness:
1/4 Lambda
Package Size:
20.00cm * 20.00cm * 20.00cm
Specification:
5-300mm
Production Capacity:
50000/Year
Surface Quality:
60-40,40-20,20-10 etc
HS Code:
9001909090
Transport Package:
Carton
Origin:
Changchun
Refund Policy:
Claim a refund if your order doesn't ship, is missing, or arrives with product issues.
Shipping Cost:
Contact the supplier about freight and estimated delivery time.
Shape:
Cube Corner Prism
Customized:
Customized
Port Of Loading:
Dalian Port
Application:
Digital Device
Trade Term:
FOB
Material:
Glass
Products Advantages:
High Precision, High Quality Control, High Efficie
Coating:
Specified by Customers
Payment Methods:
Support payments in USD
Payment Term:
T/T, PayPal, Western Union
Trademark:
YuTai
Model NO.:
yt015
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
2015-04-27
Annual Revenue Amount:
Not specified
Numbers Of Employees:
11
Preferred Payment Term:
T/T, PayPal, Western Union
Preferred Trade Term:
FOB
Port Of Loading:
Dalian Port
Certificates:
Audited supplier, FForeign trader operation registration form, ISO9001
Product descriptions from the supplier
Calcium Fluorideis often used in spectroscopic windows and lenses due to its high transmission from 350nm to 7μm. Calcium Fluoride is also commonly found in cryogenically cooled thermal imaging systems. Its low absorption and high damage threshold makes it a popular choice for excimer laser optics. Calcium Fluoride's low refractive index allows it to be used without an antireflective coating. The Knoop hardness of Calcium Fluoride is 158.3.
Specifications:
| Material | CaF2 |
| Diameter | 1.5-450mm |
| Surface Figure | λ/2 |
| Diameter Tolerance | +0.1, -0.1 mm |
| Thickness Tolerance | ±0.2 mm |
| Paraxial Focal Length | ±2% |
| Centration | <3 arc minutes |
| Clear Aperture | >85% |
| Surface Quality | 60-40 scratch and dig |
| Coating | Specified by customers |
Application:
Microscopic instruments
Optical metrological instruments
Laser protective windows
Optical instruments of surveying and mapping
Machine vision devices
Optical detection instruments
The popular science optical
A digital optical
Optical test instruments
Fiber optic instruments
Laser Instruments
Electro-optic displays
Medical optical
Infrared thermography
Observation instrument measuring instrument and photography
Other Items
Factory information
Yutai Optics, we specialize in the design and volume manufacturing of high performance optical components such as lens,prisms, windows,filters,mirrors and more for use in optical instruments and laser systems, as well as for telecommunications,medical, environment monitoring industry,material is widely ranged from optical glass to IR and UV glass.
As a Fast-growing supplier in Optics, Yutai Optics offers excellent service and good quality items,our products have been appreciated by many European and American customers,of course we build a long-term cooperation.YuTai Optics has quickly established itself as a leader in optical components from its advanced technology and quality control.
Our Advantage
Sales TeamYutai Optics has a professinal sales team with excellent service, we tracking from inquiry to delivery of items.We try our best to meet each customers'request.
Production Team
Yutai Optics has many experienced engineers and advanced machines, they are the important guarantee for the higher quality products.Our advanced production machines list:
Ring polishing machine, Single axis machine, Two axis machine, Four axis machine,Centering edging machine,Mechanical milling machine,Spectrograph, Grinding machine,nanotech.250upl,talysurfi120.
Inspection Team
Advanced testing equipment and methods are important guarantee for the production of high-precision products.Our testing machine is ZYGO, Stereo interferometer,Horizontal interferometer.We provide testing report for each batch for your items.
Process for most optics
Material-cutting-rounding-milling-grinding-polishing-edging-cleaning-coating-gluing-edging-blacking-accembly-packing-shipping
Packaging & Shipping
1 Package Detail: A. Standard carbon and envelop with plastic foam.
B. Safety green carton.
C. Customized.
2 Delivery Detail: Within 30 days.(Also depand on the quantity)
