Used Wire Drawing Machine for Making Nail and Screws
Sets
Negotiable
Product information
High-quality Used Wire Drawing Machine for Making Nail and Screws supplied by Wuxi Wandeshun Machine Co., Ltd.. Bulk wholesale pricing is negotiable. Inquiry for latest prices.
Outlet Diameter:
0.5-4.5mm
Drawing Speed:
10-12m/S
Max. Number Of Block:
12
Power:
18.5-30kw
Production Capacity:
300 Set One Year
Voltage:
380/415/440/220
Block Dia.:
560mm
Max.Inlet Wire Dia.:
6.5mm
Specifications
Outlet Diameter:
0.5-4.5mm
Drawing Speed:
10-12m/S
Max. Number Of Block:
12
Power:
18.5-30kw
Production Capacity:
300 Set One Year
Voltage:
380/415/440/220
Block Dia.:
560mm
Max.Inlet Wire Dia.:
6.5mm
HS Code:
8463102000
No Of Block:
According Clients Needs
Market:
All of The World
Coulor:
Any
Technology:
Complete Program in Offer
After Sell Service:
Engineers Available to Service Outside
Trade Term:
FOB, CFR, CIF, DAT, FAS, DDP, DAP, CIP, CPT, FCA, EXW, Others
Drawing Material:
High, Medium, Low Carbon
Payment Term:
LC, T/T, PayPal, Small-amount payment, cash
Condition:
New
Warranty:
One Year
Transport Package:
PE
Certification:
REACH, RoHS, ISO
Origin:
Wuxi
Model NO.:
Z94-4C
Port Of Loading:
shanghai
Trademark:
wandeshun
Specification:
weight 8 ton
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
2013-08-08
Annual Revenue Amount:
Not specified
Numbers Of Employees:
Not specified
Preferred Payment Term:
LC, T/T, PayPal, Small-amount payment, cash
Preferred Trade Term:
FOB, CFR, CIF, DAT, FAS, DDP, DAP, CIP, CPT, FCA, EXW, Others
Port Of Loading:
shanghai
Certificates:
CE, SGS
Product descriptions from the supplier
1. About us
Wuxi Wandeshun Machine Co., Ltd. one of the leading wire drawing machine manufacturers in China , is specialized in manufacturing wire drawing machines , which was established in 2000.
Our products are popular in many provinces of china and have already been exported to Vietnam , Indonesia, Uzbekistan Kenya, South Africa,Algeria,Egypt, Iran, Turkey,Bolivia,Saudi Arabia and so on
Excellent geographic location and easy transportation access, only 2k meter from Wuxi airport and adjacent to national highway 312.Welcome friends of all industries to visit and instruct our factory.
Product Details
Used Wire Drawing Machine for Making Nail and Screws
My contact way
My mobile: 86-13921534531
jeaquline zou
market manager
Product Details
Z94C series High speed ,low noise nail making machine usually used to make normal nail,concrete nail,steeless nail,D shape and T shape nail.
This type equipment is consist of lubricating systerm and driving systerm.
The driving systerm include wire feeding,wire clamping ,wire cutting and stamping.
Process
Wire-Rod → Wires-Drawing → Nail-Making → Polishing → Packing → Delivery
Characteristics
1) High Speed
2) Low Noise
3) Less Impact
4) Good Continuity
5) Main components are made of quality steel, such as shaft, cams and gear.
6) It adopts plunger and oil pipe lubricating structure.
7) It can make the high quality of asphalt felt nails and other special nails used for high speed coil nail welder and coil nailers.
First step: wire drawing machine is used to draw the wire to the fine dia we need.
Second step: nail making machine is used to make nails. we just need to put the fine dia wire into the entrance of the nail making machine. It will finish nail making fully automatic
|
Technica |
Unit |
Z94-4C |
Z94-3C |
Z94-2C |
Z94-1C |
Z94-5.5C |
Z94-6A |
|
Max diam |
mm |
4.5 |
3.4 |
2.8 |
1.6 |
5.5 |
6.0 |
|
Min diam |
mm |
2.8 |
1.8 |
1.2 |
0.9 |
4.1 |
4.1 |
|
Max length |
mm |
100 |
75 |
50 |
25 |
150 |
180 |
|
Min length |
mm |
50 |
25 |
16 |
9 |
100 |
100 |
|
Desiged output |
Pcs/min |
260 |
280 |
300 |
450 |
220 |
220 |
|
Motor power |
kw |
4 |
3 |
2.2 |
1.5 |
5.5 |
11 |
|
Weight |
kg |
1900 |
1200 |
950 |
750 |
2500 |
6000 |
Third step: nail polihsing machine is used to make the nail brighening.
Grinder which is used to make the nail knives more sharp.
Pointing rolling machine is used to make the point of the wire smaller so that it can get through the wire drawing dies before drawing.
