Vacuum Forming Machine for Producing Food Storage Containers, Pizza Storage Containers

Vacuum Forming Machine for Producing Food Storage Containers, Pizza Storage Containers - Image 1
Vacuum Forming Machine for Producing Food Storage Containers, Pizza Storage Containers - Image 2
Vacuum Forming Machine for Producing Food Storage Containers, Pizza Storage Containers - Image 3
Vacuum Forming Machine for Producing Food Storage Containers, Pizza Storage Containers - Image 4
Vacuum Forming Machine for Producing Food Storage Containers, Pizza Storage Containers - Image 5
Vacuum Forming Machine for Producing Food Storage Containers, Pizza Storage Containers - Image 6
Vacuum Forming Machine for Producing Food Storage Containers, Pizza Storage Containers - Image 1
Vacuum Forming Machine for Producing Food Storage Containers, Pizza Storage Containers - Image 2
Vacuum Forming Machine for Producing Food Storage Containers, Pizza Storage Containers - Image 3
Vacuum Forming Machine for Producing Food Storage Containers, Pizza Storage Containers - Image 4
Vacuum Forming Machine for Producing Food Storage Containers, Pizza Storage Containers - Image 5
Vacuum Forming Machine for Producing Food Storage Containers, Pizza Storage Containers - Image 6

1 Piece

$111,111,111

1 Piece

$1

Product information

High-quality Vacuum Forming Machine for Producing Food Storage Containers, Pizza Storage Containers supplied by Qingdao Fineyear Industry Co., Ltd.. Bulk wholesale pricing ranges from $1 to $111,111,111 per Piece with a minimum order of 1 Piece. Inquiry for latest prices.

Specification:

5700x2200x2200mm

Production Capacity:

7000 Sets/Year

After Sales Service:

7X24h

HS Code:

8477409000

Origin:

China

Computerized:

Computerized

Trade Term:

FOB, CFR, CIF, DAT, FAS, DDP, DAP, CIP, CPT, FCA, EXW, Others

Driven Type:

Hydraulic

Specifications

Specification:

5700x2200x2200mm

Production Capacity:

7000 Sets/Year

After Sales Service:

7X24h

HS Code:

8477409000

Origin:

China

Computerized:

Computerized

Trade Term:

FOB, CFR, CIF, DAT, FAS, DDP, DAP, CIP, CPT, FCA, EXW, Others

Driven Type:

Hydraulic

Certification:

ISO9001:2008, CE, QS, GMP, Ghost

Cabinet:

Incluced

PLC:

Included

HMI:

Included

Payment Term:

LC, T/T, D/P, PayPal, Western Union, Small-amount payment, Money Gram

Application:

Machinery & Hardware, Food & Beverage, Medical, Toys, Commodity, Textiles, Chemical, Apparel, Package

Raw Material:

PA

Port Of Loading:

QINGDAO

Fat:

Supply

Shaping Mode:

Vacuum

Transport Package:

Wooden Case

Trademark:

fineyear

Model NO.:

jc

Business Details

Country:

China

Business Types:

Not specified

Main Markets:

Not specified

Main Products:

Year Established:

2014-01-01

Annual Revenue Amount:

Not specified

Numbers Of Employees:

Not specified

Preferred Payment Term:

LC, T/T, D/P, PayPal, Western Union, Small-amount payment, Money Gram

Preferred Trade Term:

FOB, CFR, CIF, DAT, FAS, DDP, DAP, CIP, CPT, FCA, EXW, Others

Port Of Loading:

QINGDAO

Certificates:

SGS

Product descriptions from the supplier

Key attributes



plastic type
PP, PS
warranty
6 Months
product type
Fast Food Box
automatic
Yes
video outgoing-inspection
Provided
core components
PLC, Pressure vessel
machinery test report
Provided
key selling points
Easy to Operate
voltage
380V
weight (t)
4
max.forming height(mm)
180
forming width (mm)
710
forming length (mm)
1220
heating power (kw)
112
production speed(times/h)
20
place of origin
QINGDAO, China
brand name
JC
dimension(l*w*h)
7200*2200*2400mm
Power(kW)
33
Plastic Type
PPPS,PC.PETPEPVC,PETG.PLA
Video outgoing-inspection
Provided
Machinery Test Report
Provided
Core Components
PLC, Engine, Gearbox, Motor, Pump
Place of Origin
China
Applicable Industries
Manufacturing Plant, Food & Beverage Factory, Food Shop
Processing Type
Plastic Thermoforming Machine
Application
Making Plastic Disposable Container
Certification
Video technical support, Free spare parts, Field installat
After-sales Service Provided
Enaineers avallable to service machinery overseas

Packaging and delivery

Selling Units
Single item
Single package size
720X220X240 cm
Single gross weight
4000.000 KG
Are you facing these problems?

The price of new equipment is too high, and the quality risk of second-hand equipment is too high?

Second-hand equipment + new equipment, covering customers with different budgets


Once the equipment has problems, it is difficult and costly to repair?


6-month warranty for second-hand equipment, 1-year warranty for new equipment, 24-hour online service, engineers can provide service for overseas machinery

Operating second-hand equipment may require more technical support, but are you worried that the buyer won't provide it?

We have agents and partners in Southeast Asia, 24-hour Arabic/English technical lifetime support, on-site installation training team, and equipment lifetime upgrade service

Worried about incomplete equipment refurbishment, false reporting of machine age, or hidden faults?

Each device undergoes a 72-hour load test before leaving the factory, and supports third-party machine inspection
The whole process of the cup making machine
Raw material preparation → Sheet heating → Heating and softening → Molding → Cooling → Demolding → Cutting → Trimming → Finished product
1. Plastic packaging industry: Blister machines are widely used to produce variousplastic packaging boxes, decoration boxes, frames and other products, suitable forbatteries, toys, gifts, hardware, home appliances, electronics, stationery, decoratiorand other fields.
2. Food packaging industry: In the field of food packaging, blister machines can makefast food boxes, fruit trays, biscuit boxes, etc., to keep the freshness and hygiene offood.
3. Pharmaceutical industry: In the pharmaceutical field, blister machines are used toproduce pill packaging, tablet packaging, etc. to ensure the safety and hygiene of drugs.
4. Industrial application: Blister machines are also used to produce industrialaccessories such as cooling water guide plates for industrial cooling towers.
5. Daily necessities and electronic product packaging: Blister machines are suitablefor the production of blister packaging for daily necessities, electronic productscomputer peripherals, toys, sporting goods, and stationery
Mechanical parameters
Moldinglength:
1220mm
Forming width:
410mm-710mm(Any adjustment)
Material width:
450mm-750mm(Any adjustment)
Molding height:
180mm
Molding thickness:
0.12-2.0mm
Using electric:
380V/50HZ
Molding speed:
3-20 times per minute,depending onthe product and materialthickness
Totalpower:
35KW
Machine size :
7200*2200*2400mm
Products that machines can make

egg tray making machine

plastic cup cover machine

plastic lunch box making machine

Fruit tray machine

seeding tray machine

fast food box making machine

sushi box making machine

plastic pallet making machine

cake box making machine

Our Exhibitions

FAQ
1,What products can the vacuum forming machine make?
Egg trays, fruit boxes, seedling trays, fast food boxes, sushi boxes, electronic trays, cake boxes, plastic trays, etc.
2,What does the full set include?
Vacuum forming machine, air compressor, chiller, vacuum pump, gas tank, cutting machine
3,Area occupied?
Full equipment workshop area: 200-400 square meters.
4,How many workers are needed?
Only 1-3 people are needed (responsible for equipment monitoring, packaging and maintenance).
5. What is the hourly output of the vacuum forming machine?
Different products have different outputs (depending on the product)
6,Payback period?
The payback period is about 4 months (depending on the order quantity and unit price).
7,What after-sales maintenance is there?
24-hour Arabic/English technical support, on-site installation training team, equipment lifetime upgrade service.
8,What are the special advantages of the machine?
Install cooling fan, moisture-proof circuit;Filtered dust-proof air intake, high temperature resistance; Customizable voltage, rat-proof cable.Easy to operate, can be on duty in a few hours





FAQ
1,What products can the vacuum forming machine make?
Egg trays, fruit boxes, seedling trays, fast food boxes, sushi boxes, electronic trays, cake boxes, plastic trays, etc.
2,What does the full set include?
Vacuum forming machine, air compressor, chiller, vacuum pump, gas tank, cutting machine
3,Area occupied?
Full equipment workshop area: 200-400 square meters.
4,How many workers are needed?
Only 1-3 people are needed (responsible for equipment monitoring, packaging and maintenance).
5. What is the hourly output of the vacuum forming machine?
Different products have different outputs (depending on the product)
6,Payback period?
The payback period is about 4 months (depending on the order quantity and unit price).
7,What after-sales maintenance is there?
24-hour Arabic/English technical support, on-site installation training team, equipment lifetime upgrade service.
8,What are the special advantages of the machine?
Install cooling fan, moisture-proof circuit;Filtered dust-proof air intake, high temperature resistance; Customizable voltage, rat-proof cable.Easy to operate, can be on duty in a few hours
Vacuum Forming Machine for Producing Food Storage Containers, Pizza Storage ContainersVacuum Forming Machine for Producing Food Storage Containers, Pizza Storage ContainersVacuum Forming Machine for Producing Food Storage Containers, Pizza Storage ContainersVacuum Forming Machine for Producing Food Storage Containers, Pizza Storage ContainersVacuum Forming Machine for Producing Food Storage Containers, Pizza Storage ContainersVacuum Forming Machine for Producing Food Storage Containers, Pizza Storage ContainersVacuum Forming Machine for Producing Food Storage Containers, Pizza Storage Containers

Parameters.

No.
Item Technical

Parameters
1 Maximum wellhead size Length:2600 mm,
width: 1600 mm
2 Molding depth 500 mm
3 Applicable material thickness 1-10mm
4 Total power supply Three-phase five-wire 380V±15V, 50Hz
5 Heating power Upper furnace: 128kw;
Lower furnace: 128kw
6 Total power 280kw (subject to actual, normal use between 50-70%)
7 Mold forming method concave mold forming
(one time molding)
8 Upper furnace power servo motor
9 Upper and lower mold table power servo motor
10 Cooling Form Powerful fan
11 Heating unit Fast medium wave infrared heating tube, analog pressure control
12 Vacuum state Matching size secondary vacuum
13 Upper pressing frame structure According to the different size of the mold can be arbitrarily adjusted
14 sheet transportation manual placement
15 Product demolding pickup Pneumatic blowback demolding
16 Other functions bubble blowing, anti-sagging, size vacuum, mold core extraction
17 Adaptation of processing materials PP.PC.PE.PVC.ABS.PMMA.PS and other thermoplastic plates
18 Machine size 3800mm long, 4600mm wide, 3200mm high
(excluding the upper mold)
Equipment composition and technical description
This equipment consists of pressing device, heating system, temperature control system, mold table lifting device, vacuum forming system, bubble blowing (anti-sagging) system, cooling system, electrical system, safety device system and so on.

I. Pressing device
The press frame is driven by pneumatic cylinder, according to the size of the product to adjust the size of the window and the opening of the press frame, the press frame and the window can be adjusted to different sizes of length and width at will.

II. Heating system
1. This machine is double-sided heating, the upper furnace is driven by servo motor, or you can choose the upper or lower furnace separately, and it is heated by fast medium wave infrared heating tube. Heating tube features: fast heating, no need to preheat, boot can be produced, good permeability, strong penetration.
2. The electric furnace will automatically turn on the heating only after it enters the heating station, and it will automatically turn off when it returns, which saves a lot of energy consumption;
3. The heating furnace is accurately positioned when it moves to the heating station, driven by servo motor (the lower electric furnace is driven by cylinder), the process is smooth.


III. Temperature control system
1. The heater is equipped with a terminal controller in the working state, all process parameters, settings are used digital display, on the touch screen can intuitively display the action in place conditions and a variety of equipment parameters, data;
2. Temperature control using digital analog adjustment, control by the voltage output to adjust the heating temperature, temperature control is accurate; using 485 communication, you can directly adjust the parameters on the touch screen, and can store multiple sets of data;
3. The temperature of each heating unit in the heating zone is independently adjustable (one control and one adjustment mode, you can turn off part of the heating element to save energy), and each heating element is labeled on the line.


IV. Upper and lower mold table lifting device
1. The upper and lower mold table power lifting system is driven by servo motors, the lifting speed is smooth, and when you need to adjust the mold height, you can directly input the specified height in the touch screen, and you don't need to adjust the limit switches additionally;
2. The lifting speed of the mold table can be adjusted individually, and the mold table can adopt multi-stage demolding method to realize automatic demolding for the products which are difficult to demold.


V. Vacuum molding system
1. It mainly consists of vacuum pump, vacuum tank, vacuum pipeline, vacuum control valve and so on.
2. Equipped with two-stage vacuum system (large and small vacuum), according to the complexity of the product to choose.
3. Choose oil vacuum pump, no noise.


VI. Blowing bubble (anti-sagging) system
1. This equipment is equipped with a sealed workspace, blowing up the heated plate before molding, the blowing bubble function can ensure that the thickness of the workpiece is uniform;
2. Equipped with adjustable blowing bubble air pressure, equipped with pressure regulating valve, according to the different products to be adjusted;
3. Equipped with a sagging device, that is, the plate is baked soft in the heating process, resulting in self-weight aggravation and sagging, the system will automatically detect and blow up the plate with the mold cavity to prevent the material from falling to the lower furnace, without manual operation, automatic control.


VII. Cooling system
The machine is equipped with a powerful fan for product cooling, and the start, delay and length of cooling time can be set on the touch screen.

VIII. Electrical system
1. The lines are beautifully arranged and not exposed.
2. The lines in the electric control box are beautiful and practical, neatly numbered and easy to maintain.
3. All heating units have short-circuit protection devices.


IX. Safety device system
1. Equipped with safety grating, when the machine is working automatically, all the actions will stop immediately when the personnel enter the working area to ensure the safety of personnel.
2. The press frame is equipped with safety anti-drop device, which will be locked automatically when the operator loads and removes materials to ensure the safety of the operator.
3. The machine is equipped with operation light indication (running, standby, stop) and sound and light alarm.


Environmental requirements
(1) Power supply voltage: three-phase five-wire 380V ± 10%, 50Hz
(2) Working environment temperature: -20 ºC ~ 40 ºC;
(3) The ideal height of the workshop: 5.5M
(4) compressed air pressure: 0.6MPa ≤ X ≤ 0.8 MPa


Equipment use
It is suitable for vacuum forming of thermoplastic plates of ABS, PS, PE, PP, PC, PVC, PMMA and so on with thickness of 1~10mm.

product picture
Vacuum Forming Machine for Producing Food Storage Containers, Pizza Storage Containers
Vacuum Forming Machine for Producing Food Storage Containers, Pizza Storage Containers



User Reviews

Like
Write a review
File a complaint

Supplier Review

Summary by Vivian

TRUST STARS

4.0/5

0 Reviews

Qingdao Fineyear Industry Co., Ltd. is a company based in China, established on 2014-01-01, with operations centered at Excellent Financial Plaza, Shuangzhu Road, New West Coast District, Qingdao, Shandong, China. The company offers export of Belt Making Machines, Rubber Kneaders, Rubber Machinery, Tire Changers and engages in trade via LC, T/T, D/P, PayPal, Western Union, Small-amount payment, Money Gram with terms including FOB, CFR, CIF, DAT, FAS, DDP, DAP, CIP, CPT, FCA, EXW, Others, loading at QINGDAO. Its product range includes 12.8FT 3.9meters Inflatable Pontoon Fishing Boat China Luxury Yacht, 13r22.5 Truck Bus Tyre TBR Tire, 25FT (7.75m) Cheap Aluminum Luxury Double Decker Pontoon Yacht, 30FT Sport Fishing Luxury Yacht Made in China for Sale, 80W CO2 Small MDF Wood Acrylic Granite Stone Paper Fabric Laser Cutting Machine, Anti Slip Rubber Flooring Mats Custom Pattern Fine Ribbed/Checker/Corrugate/Diamond/Orange Peel Coin Rubber Sheet, Anti-Slip Checkered Rubber Flooring Safety Garage Mats Custom Cutting Rubber Sheets, Anti-Slip Diamond Checker Runner Willow Leaf Rubber Matting for Bus Garage Rubber Floor, Anti-Slip PVC Stud Circular Rubber Sheet Coin Mat Flooring Rolls for Garage Use for Shoes Sofa Bag Upholstery Car Seat Stretch, Automatic Positive Negative Pressure Vacuum Forming Machine for Plastic Trays Food Packaging PP PE PS PC Pet, Black Checker or Grid Relief Rubber Flooring Mat 15/20mm Thick Anti-Slip for Gym Application, Carbon Black Carbon White Black Chemicals Carbon Chemicals Carbon Powder, Constant Tension Green Belt Building Table Rubber Fabric Belt Layers Compress, Conveyor Belt Vulcanizing Line Rubber Belt Curing Line Nylon Belt Curing Press Fabric Belt, Diamond Checker Plate Rubber Mats for Boats Anti-Slip Custom Processing & Moulding Services Available, Durable Flooring Non Slip Round Button Coin/Diamond/Willow/Orange Peel/Ribbed/ Pattern Rubber Sheet Mat Rolls, ESD Rubber Mat with PVC / EPDM Foam / Rubber Material Yellow and Black Antifatigue Mat Antistatic Rubber Mat, Factory 1m*1m High Quality Non-Toxic Gym Rubber Flooring Protective Rubber Floor for Crossfit Easy Installation Rubber Mats, Factory Supply PVC Upper Hydraulic Vertical Plastic Injection Molding Machine, High Efficiency Car Bumper Automatic Thermoforming Machine Thick Sheet Vacuum Forming Machine, High-Efficiency Vacuum Forming Machine for Plastic Packaging, Industrial Anti-Slip Rubber Floor Mat Roll Electrical Insulation Rubber Matting, Inexpensive PP PC PVC PE ABS Plastic Food Packaging Boxes Cup Lids Negative Pressure Vacuum Forming Machine, Manufacturer Wholesale High-Performance Anti-Slip PVC Coin Mat Black Colors, Molded Stud Rubber Door Mat/Button Rubber Mat/Coin Rubber Mat Product Type Rubber Sheets, Q32 Tumblast Tumbler Belt Die-Casting Cleaning Abrator, Tumblast Tumble Belt Shot Blaster Blasting Machine Crawler Rubber Belt, Rubber Checker Anti Slid Mat Sheet Pad, Rubber Diamond Plate Soft Para Studded Flooring Bus Checker Rear Board Gummi Matting Mats, Rubber Flooring Mat Anti Slip Round DOT Coin Pattern Rubber Flooring Mat, Rubber Nylon Fabric Green Conveyor Belt Compress Laminate Building Press Line Machine Equipment, Used Banbury Gk Hbxm Ge X (S) M-270/250/180/160/110/90/80 X (S) N-110/75/55L/35/20L/15/6/3L Secondhand Kneader Rubber Mixer Internal Mixer Used Kneading Machine, Used Secondhand Old Recycle Waste Transfer Rubber Tyre Tire Plastic Silicone Extruding Tread Extruder, Vacuum Forming Machine for Manufacturing Egg Trays, Plastic Packaging, Disposable Lunch Boxes, Vacuum Forming Machine for PP ABS and Other Products, Vacuum Forming Machine for Producing Food Storage Containers, Pizza Storage Containers, Vacuum Forming Machines for Plastic Packaging Boxes Coffee Cups Thermoforming Machines. The company holds SGS certification.

Company Verification

0/4

Profile Completeness

56%

Avg. Product Score

0/5

Responsiveness

0%

Certification

SGS

Related searches

Frequently Asked Questions (FAQs)


You can contact verified China supplier Qingdao Fineyear Industry Co., Ltd. through platforms like Freshdi.com to purchase Vacuum Forming Machine for Producing Food Storage Containers, Pizza Storage Containers. For direct inquiries, please contact Ms. Melinda, the company’s representative. The supplier has a 4.0-star rating on Freshdi and has verified. You’ll receive product details, pricing, and shipping terms directly from supplier.


For Vacuum Forming Machine for Producing Food Storage Containers, Pizza Storage Containers, Qingdao Fineyear Industry Co., Ltd. accepts LC, T/T, D/P, PayPal, Western Union, Small-amount payment, Money Gram as the preferred payment method, the trade term is FOB, CFR, CIF, DAT, FAS, DDP, DAP, CIP, CPT, FCA, EXW, Others, and shipments are typically arranged from port QINGDAO, ensuring secure and timely international delivery.


The supplier Qingdao Fineyear Industry Co., Ltd. offers Vacuum Forming Machine for Producing Food Storage Containers, Pizza Storage Containers at negotiation.


Vacuum Forming Machine for Producing Food Storage Containers, Pizza Storage Containers is sourced from China and meets international export standards. Key specifications include: Computerized: Computerized, Specification: 5700x2200x2200mm, Trademark: fineyear, Transport Package: Wooden Case, Application: Machinery & Hardware, Food & Beverage, Medical, Toys, Commodity, Textiles, Chemical, Apparel, Package, Raw Material: PA, Trade Term: FOB, CFR, CIF, DAT, FAS, DDP, DAP, CIP, CPT, FCA, EXW, Others, Payment Term: LC, T/T, D/P, PayPal, Western Union, Small-amount payment, Money Gram

You are viewing details for Vacuum Forming Machine for Producing Food Storage Containers, Pizza Storage Containers. The information provided here is either posted directly by the supplier, who is responsible for its accuracy, or collected by Freshdi AI from publicly available sources. Freshdi strives to make product information as useful and reliable as possible, but we do not guarantee complete accuracy. If you notice any incorrect or misleading details, please use the Report Product option so our team can review and address it quickly.

$111,111,111

/ Piece

Min. order: 1 Piece

Qingdao Fineyear Industry Co., Ltd.
1 yrs

China FlagChina

4.0

Ms. Melinda

Year Established: 2014-01-01

Visit Store
