Veinasa-Jk-Y32 Data Acquisition Instrument Environment Center Monitoring Host with LCD Display Data Storage
1 Piece
$2391 Piece
$198Product information
High-quality Veinasa-Jk-Y32 Data Acquisition Instrument Environment Center Monitoring Host with LCD Display Data Storage supplied by Sichuan Weinasa Technology Co., Ltd.. Bulk wholesale pricing ranges from $198 to $239 per Piece with a minimum order of 1 Piece. Inquiry for latest prices.
Package Gross Weight:
1.800kg
Scope Of Supply:
10 ~ 30 V DC
Specification:
150*123*34mm
Package Size:
25.00cm * 22.00cm * 18.00cm
1 DC Voltage Acquisition:
Acquisition Range 0-100V
Origin:
China
Refund Policy:
Claim a refund if your order doesn't ship, is missing, or arrives with product issues.
Shipping Cost:
Contact the supplier about freight and estimated delivery time.
Specifications
Package Gross Weight:
1.800kg
Scope Of Supply:
10 ~ 30 V DC
Specification:
150*123*34mm
Package Size:
25.00cm * 22.00cm * 18.00cm
1 DC Voltage Acquisition:
Acquisition Range 0-100V
Origin:
China
Refund Policy:
Claim a refund if your order doesn't ship, is missing, or arrives with product issues.
Shipping Cost:
Contact the supplier about freight and estimated delivery time.
Transport Package:
Covered with Carton Packing
Trade Term:
EXW, CIF, FOB, CFR
Payment Term:
LC, T/T, D/P, PayPal, Western Union, Small-amount payment
Port Of Loading:
Mianyang port
Payment Methods:
Support payments in USD
4 Way Switch Signal Input:
The on-off State of Dry Contact Can Be Detected
Trademark:
Veinasa
Model NO.:
Veinasa-JK-Y32
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
2017-09-28
Annual Revenue Amount:
Not specified
Numbers Of Employees:
8
Preferred Payment Term:
LC, T/T, D/P, PayPal, Western Union, Small-amount payment
Preferred Trade Term:
EXW, CIF, FOB, CFR
Port Of Loading:
Mianyang port
Certificates:
Automatic Weather Station, CE certificate of Automatic Weather Station, CE certificate of Mini Weather Station, CE certificate of PM2.5/10 Sensor, CE certificate of Soil Measuring Instrument, CE certificate of Soil Temperature and Humidity EC Integrated Sensor
Product descriptions from the supplier
Veinasa-JK-Y32 Data Acquisition Instrument Environment Center Monitoring Host with LCD Display Data Storage
This is a multifunctional monitoring host developed for environmental monitoring sites such as computer rooms and warehouses. Through the RS485 interface, all of our RS485 transmitters (temperature and humidity, water immersion, power failure detection, smoke sensing, etc.) can be connected to the environmental monitoring host, and the data can be uploaded to the cloud platform provided by our company or the customer's own server in real time.The device supports either GPRS, Ethernet, or RS485 for data upload. Device built-in large LCD screen, user-friendly interface and easy operation, while the host can be connected with a maximum 1024*256 lattice LED screen. Built-in real-time clock to display real-time data and system time.
| The parameter name | Scope or interface | instructions |
| Communication interface | RJ45 internet port | Upload data through the network port |
| GPRS wireless | Upload data via GPRS | |
| GSM SMS | Support SMS alarm (function optional) | |
| Rs-485 slave station interface | Upload data via rs-485 (optional protocol) | |
| LED display interface | Monochrome LED display with a maximum lattice number of 1024*256 (optional specification) | |
| 1 dc voltage acquisition | Acquisition range 0-100v | The acquisition accuracy is ± 0.1v, and the input impedance is ≥100K The monitoring host can set conversion coefficients |
| 1 channel water immersion detection signal | Water leakage can be detected | Standard with leakage electrode, users can also choose the leakage rope, up to 30 meters |
| 4 - way switch signal input | The on-off state of dry contact can be detected | External passive dry contact, response time ≤ 0.2s |
| 2 relay output | Relay dry contact output | Relay capacity: 250VAC/30VDC 5A The relay can be associated with the upper and lower limits of any channel for alarm or automatic control. |
| Pulse signal input of 1-way inverted bucket rain gauge | The magnetic switch pulse signal is collected for rainfall measurement | Default pulse equivalent: 0.5mm You can upload instantaneous rainfall (last minute), current rainfall (from 00:00 to present), yesterday's rainfall (from 00:00 to 24:00) and permanent accumulated rainfall. (by default, the fourth switch quantity is used as the input of the rain gauge) |
| Data upload interval | 1 s ~ 10000 s | Data upload interval of 1S~10000S can be set |
| Built-in storage capacity | 520000 data | Built-in storage, can store up to 520,000 pieces |
| Master slave RS485 interface communication distance | >2000 meters | The maximum communication distance of 0.5 square RVV cable is up to 2000 meters. |
| Scope of supply | 10 ~ 30 v DC | Dc wide voltage supply. |
