Product information

High-quality Vertical Planetary Concrete Mixer Industrial High Efficiency Equipment Customizable supplied by Weifang CP Machinery Co., Ltd.. Bulk wholesale pricing is negotiable. Inquiry for latest prices.

Warranty Of Core Components:

1 Year

Power:

110kw

Production Capacity:

4000 Pieces

Drum Mixing Capacity:

5.5cbm

Dimension:

7820X4750X4400

HS Code:

84295100

Weight:

9200kg

Trade Term:

CFR, EXW, CIF, FOB

Specifications

Warranty Of Core Components:

1 Year

Power:

110kw

Production Capacity:

4000 Pieces

Drum Mixing Capacity:

5.5cbm

Dimension:

7820X4750X4400

HS Code:

84295100

Weight:

9200kg

Trade Term:

CFR, EXW, CIF, FOB

Model NO.:

CPM5.5

Origin:

China

Trademark:

Cloud Pillar

Type:

Concrete Mixer

Core Components:

Gearbox

Unique Selling Point:

High Operating Efficiency

Machining Process:

Hydraulic

Certification:

ISO9001: 2000, CE

Fuel Consumption:

Idle State 2L-3L, Working State 8L-10L

Payment Term:

LC, PayPal, Small-amount payment, Western Union, D/P, T/T

Applicable Industries:

Manufacturing Plant, Farms, Construction Works , E

Condition:

New

Marketing Type:

New Product 2024

Showroom Location:

Philippines, Pakistan, Mexico, Kenya, Ukraine, Mal

Machinery Test Report:

Provided

Video Outgoing Inspection:

Provided

Port Of Loading:

Qingdao Port

Gear Number:

Three Forwards, Three Backwards

Engine Brand:

Yunchai

Business Details

Country:

China

Business Types:

Not specified

Main Markets:

Not specified

Main Products:

Year Established:

2013-03-14

Annual Revenue Amount:

Not specified

Numbers Of Employees:

5

Preferred Payment Term:

LC, PayPal, Small-amount payment, Western Union, D/P, T/T

Preferred Trade Term:

CFR, EXW, CIF, FOB

Port Of Loading:

Qingdao Port

Certificates:

CE certificate of tractor, CE certificate of wheel loader, ISO9000, ROPS

Product descriptions from the supplier

SONA2024 2.2.1
Vertical Planetary Concrete Mixer Industrial High Efficiency Equipment Customizable
Our concrete mixer fits rural house-building, road construction, renovation & prefab projects—trusted by global contractors & DIY users.
Built for strength and longevity: Operate with diesel (ideal for outdoor use, independent of power) or electric (perfect for indoor or compact operations); processing 500L per batch reduces operation time by 30%. Stainless steel drum with dual-axis or planetary agitation delivers consistent blending, and a rust-inhibiting finish boosts durability by 2 to 3 years.
Flexible & Portable: Small models have wheels/tricycle designs for easy movement; self-loading versions enable one-person load-mix-discharge. Optional lifters & 360° rotatable drums reduce waste.
Safe & User-Friendly: CE/EPA certified, with overload protection & emergency stops. Intuitive panels suit new users; ergonomic handles/seats ease fatigue.
Global Support: 1–2-year warranty (free core part replacement), sufficient spare parts, local service in SEA/Africa. New/used options, bulk discounts, sea/air shipping with customs docs.
Vertical Planetary Concrete Mixer Industrial High Efficiency Equipment Customizable
Vertical Planetary Concrete Mixer Industrial High Efficiency Equipment Customizable
Vertical Planetary Concrete Mixer Industrial High Efficiency Equipment Customizable
Vertical Planetary Concrete Mixer Industrial High Efficiency Equipment Customizable
Vertical Planetary Concrete Mixer Industrial High Efficiency Equipment Customizable
Vertical Planetary Concrete Mixer Industrial High Efficiency Equipment Customizable
Vertical Planetary Concrete Mixer Industrial High Efficiency Equipment Customizable
Specification
Applicable Industries
Manufacturing Plant, Farms, Construction works , Energy & Mining
Showroom Location
Philippines, Pakistan, Mexico, Kenya, Ukraine, Malaysia
Video outgoing-inspection
Provided
Machinery Test Report
Provided
Marketing Type
New Product 2024
Warranty of core components
1 Year
Core Components
Gearbox
Condition
New
Place of Origin
China
Weight
9200kg
Warranty
1 Year
UNIQUE SELLING POINT
High operating efficiency
Brand Name
CloudPillar
Dimension
7820x4750x4400
Power
110KW
Model
CPM5.5
Gear number
Three forwards, three backwards
Engine Brand
Yunchai
Fuel consumption
Idle state 2L-3L, working state 8L-10L.
Drum mixing capacity
5.5CBM
Drum capacity
6.8m3
Shovel
0.72CBM
Weighing system
Electronic weighing system
Cab
Adjustable steering wheel
Type
16/70-24
Model
CPM5.5
Type
Integral frame chassis movable, self loading, mixing, transporting
Function
concrete, sand, fertilizer compound, wet or dry feed materias mixing and discharging
Productivity
BATCH≤15MINS, 4BATCHS(22CBM)/HOUR
Drive
4 x 4
Steering
Front steering
Engine
YUCHAI Engine: Four-Cylinder 2200RPM,110KW
Speed
High Speed: 38.5KM/H; Low Speed:7.5KM/H
Gear number
Three forwards, three backwards
Fuel consumption
Idle state 2L-3L, working state 8L-10L.
Tyre
16/70 24 (Steel wire tyre)
Drum
Geometric volume 6.8 cubic meters, the best stirring 4.5-5.5 cubic meters
Spiral blade in tank
Double helix mixing, with the guide screw, so that the mixing material more uniform.Turn the feed left, turn the discharge right
Mixing tank 270°discharges
The tank rotates horizontally to 270 degrees.There is no dead Angle for discharging around the vehicle
Tipping Chute
16°
Shovel
Shovel capacity: 0.72³
Bucket discharge switch
Hydraulic gate, electric control
Operation Handle
Electric control button four-way guide handle
Moving Hydraulic
Pump:DENGHONG
Torque converter(CloudPillar)
Work hydraulic
LIUFENG
Mixing system
Speed Reducer:(CloudPillar)
Mixing motor(ZHENJIANG DALI)
Drive axle
LIUFENG
Water Supply
Hydraulic driving self-primiing pumps
High-Pressure Water Pump Wash
High-pressure water pump wash
Weighing system
Electronic weighing system (language optional)
Voltage
Battery 24V-100A 2 pieces
Hydraulic oil box
Tankage 180L, Summer:NO68 Hydraulic Oil, Winter:NO46 Hydraulic Oil, Very Cold Zone: NO35 Hydraulic Oil,
Water tank capacity
620L
Diesel tank capacity
190L
Whole weight
Complete vehicle kerb mass 9200KG
Cab
Prevent falling objects cab
Adjustable steering wheel
Adjustable seat
Seat belts
Fire extinguisher
Astern image
Alarm Lamp
Standard configuration
Radio
Standard configuration
Cabin A/C
Optional
Escape hammer
Standard configuration
Astern sound prompt
Standard configuration
Walking control mode
Standard configuration:Electric control
Model
CPM4.0
Type
Integral frame chassis movable, self loading, mixing, transporting
Function
concrete, sand, fertilizer compound, wet or dry feed materias mixing and discharging
Productivity
BATCH≤15MINS, 4BATCHS(16CBM)/HOUR
Drive
4 x 4
Steering
Front steering
Engine
YUNNEI Engine: Four-Cylinder 2200RPM,92KW
Speed
High Speed: 36.5KM/H; Low Speed:6.5KM/H
Gear number
Three forwards, three backwards
Fuel consumption
Idle state 2L-3L, working state 6L-8L
Tyre
16/70 20 (Steel wire tyre)
Drum
Geometric volume 5.5 cubic meters, the best stirring 3.5-4 cubic meters
Spiral blade in tank
Double helix mixing, with the guide screw, so that the mixing material more uniform.Turn the feed left, turn the discharge right
mixing tank 270°discharges
The tank rotates horizontally to 270 degrees.There is no dead Angle for discharging around the vehicle
Tipping Chute
Equipped with 2 chute for detachable to increase discharging length
Shovel
Shovel capacity: 0.55³
Bucket discharge switch
Hydraulic gate, electric control
Operation Handle
Electric control button four-way guide handle
Moving Hydraulic
Pump:DENGHONG
Torque converter(CloudPillar)
Work hydraulic
Pump/valve: DENGHONG
Mixing system
Speed Reducer:(CloudPillar)
Mixing motor(ZHENJIANG DALI)
Drive axle
LIUFENG
Water Supply
Hydraulic driving self-primiing pumps
High-Pressure Water Pump Wash
High-pressure water pump wash
Weighing system
Electronic weighing system (language optional)
Voltage
Battery 24V-100A 2 pieces
Hydraulic oil box
Tankage 180L, Summer:NO68 Hydraulic Oil, Winter:NO46 Hydraulic Oil, Very Cold Zone: NO35 Hydraulic Oil,
Water tank capacity
520L
Diesel tank capacity
180L
Whole weight
Complete vehicle kerb mass 7600kg
Cab
Prevent falling objects cab
Adjustable steering wheel
Adjustable seat
Seat belts
Fire extinguisher
Astern image
Alarm Lamp
Standard configuration
Radio
Standard configuration
Cabin A/C
optional
Escape hammer
Standard configuration
Astern sound prompt
Standard configuration
Walking control mode
Standard configuration: Mechanical
Optional:Electric control
Model
CPM3.0
Type
Integral frame chassis movable, self loading, mixing, transporting
Function
concrete, sand, fertilizer compound, wet or dry feed materias mixing and discharging
Productivity
BATCH≤15MINS, 4BATCHS(12CBM)/HOUR
Drive
4 x 4
Steering
Front steering
Engine
YUCHAI Engine: Four-Cylinder 2200RPM,85KW
Speed
High Speed: 36.5KM/H; Low Speed:6.5KM/H
Gear number
Three forwards, three backwards
Fuel consumption
Idle state 2L-3L, working state 6L-8L.
Tyre
16/70 20(Steel wire tyre)
Drum
Geometric volume 4.2 cubic meters, the best stirring 2.6-3 cubic meters
Spiral blade in tank
Double helix mixing, with the guide screw, so that the mixing material more uniform.Turn the feed left, turn the discharge right
Tipping Chute
16°
mixing tank 270°discharges
The tank rotates horizontally to 270 degrees.There is no dead Angle for discharging around the vehicle
Shovel capacity
0.35³
Bucket discharge switch
Hydraulic gate, electric control
Operation Handle
Electric control button four-way guide handle
Moving Hydraulic
Pump:DENGHONG
Torque converter(CloudPillar)
Work hydraulic
Pump/valve: DENGHONG
Mixing system
Speed Reducer:(CloudPillar)
Mixing motor(ZHENJIANG DALI)
Drive axle
LIUFENG
Water Supply
Hydraulic driving self-primiing pumps
High-Pressure Water Pump Wash
High-pressure water pump wash
Weighing system
Electronic weighing system (language optional)
Voltage
Battery 24V-100A 2 pieces
Hydraulic oil box
Tankage 180L, Summer:NO68 Hydraulic Oil, Winter:NO46 Hydraulic Oil, Very Cold Zone: NO35 Hydraulic Oil,
Water tank capacity
370L
Diesel tank capacity
180L
Whole weight
Complete vehicle kerb mass 6800kg
Cab
Prevent falling objects cab
Adjustable steering wheel
Adjustable seat
Seat belts
Fire extinguisher
Astern image
Alarm Lamp
Standard configuration
Radio
Standard configuration
Cabin A/C
Optional
Escape hammer
Standard configuration
Astern sound prompt
Standard configuration
Walking control mode
Standard configuration:
Mechanical
Optional:Electric control
Model
CPM2.5
Type
Integral frame chassis movable, self loading, mixing, transporting
Function
concrete, sand, fertilizer compound, wet or dry feed materias mixing and discharging
Productivity
BATCH≤15MINS, 4BATCHS(10CBM)/HOUR
Drive
4 x 4
Steering
Front steering
Engine
YUNNEI Engine: Four-Cylinder 2200RPM,76KW
Speed
High Speed: 32.5KM/H; Low Speed:5.5KM/H
Gear number
Three forwards, three backwards
Fuel consumption
Idle state 1.8L-2L, working state 5L-7L.
Tyre
23.5 16 (Steel wire tyre)
Drum
Geometric volume 3.6 cubic meters, the best stirring 2.2-2.5 cubic meters
Spiral blade in tank
Double helix mixing, with the guide screw, so that the mixing material more uniform.Turn the feed left, turn the discharge right
Tilt of mixing tank
16°
mixing tank 270°discharges
The tank rotates horizontally to 270 degrees.There is no dead Angle for discharging around the vehicle
Tipping Chute
Equipped with 2 chute for detachable to increase discharging length
Shovel
Shovel capacity: 0.35³
Bucket discharge switch
Hydraulic gate, electric control
Operation Handle
Electric control button four-way guide handle
Moving Hydraulic
Pump:DENGHONG
Torque converter(CloudPillar)
Work hydraulic
Pump/valve: DENGHONG
Mixing system
Speed Reducer:(CloudPillar)
Mixing motor(ZHENJIANG DALI)
Drive axle
LIUFENG
Water Supply
Hydraulic driving self-primiing pumps
High-Pressure Water Pump Wash
High-pressure water pump wash
Weighing system
Electronic weighing system (language optional)
Voltage
Battery 24V-100A 2 pieces
Hydraulic oil box
Tankage 180L, Summer:NO68 Hydraulic Oil, Winter:NO46 Hydraulic Oil, Very Cold Zone: NO35 Hydraulic Oil,
Water tank capacity
370L
Diesel tank capacity
180L
Whole weight
Complete vehicle kerb mass 6600kg
cab
Prevent falling objects cab
Adjustable steering wheel
Adjustable seat
Fire extinguisher
Astern image
Alarm Lamp
Standard configuration
Radio
Standard configuration
Cab A/C
optional
Escape hammer
Standard configuration
Astern sound prompt
Standard configuration
Walking control mode
Standard configuration:Mechanical
Optional:Electric control
Packing & Delivery
Vertical Planetary Concrete Mixer Industrial High Efficiency Equipment Customizable
Vertical Planetary Concrete Mixer Industrial High Efficiency Equipment Customizable
1 unit in a 40' container
Company Profile
Cloud Pillar Machinery
Cloud Pillar Machinery is based in Weifang, Shandong, China, established in 2009. As a dedicated machinery producer, we specialize in manufacturing construction equipment—including wheel loaders, backhoe loaders, and excavators—as well as agricultural machinery. Equipped with modern technology, skilled engineering expertise, and a robust quality assurance framework, every production step follows a rigorous quality control process. Our products are certified under ISO9001:2000, CE, and GOST standards. After five years of domestic and international operations, our equipment has earned strong trust and consistent praise from clients across the globe, particularly in extreme climates like Russia and Canada, where we offer cold-resistant models, and in the Middle East, where we provide heat-resistant solutions. Upon receiving specific client needs, we swiftly implement design upgrades and initiate production schedules. To meet the growing demand from international markets, we launched Weifang Cloud Pillar Import-Export in 2013 to enhance global customer support. Staffed with experienced trade professionals, we maintain constant communication, address concerns promptly, and ensure high customer satisfaction. Our long-standing commitment to quality, proven ability to customize solutions, and dedicated export services form the foundation of our partnerships. We firmly uphold integrity and reliability in every business interaction. We warmly invite both new and returning clients to establish lasting relationships through phone or mail.

Vertical Planetary Concrete Mixer Industrial High Efficiency Equipment Customizable
Vertical Planetary Concrete Mixer Industrial High Efficiency Equipment Customizable
Vertical Planetary Concrete Mixer Industrial High Efficiency Equipment Customizable
FAQ
This loader adheres entirely to EU Stage V emission regulations. Unlike Stage IV models, it cuts HC/NOx/PM emissions by at least 40%. It satisfies EU and global key environmental transparency rules, ensuring no compliance issues arise in international projects.
Q2: What is the real fuel usage during operation? How does energy efficiency work? A: Thanks to an advanced transmission setup and smart fuel control, fuel use drops to 8–10 liters per hour under light loads and reaches 15–18 liters per hour under heavy loads—25% less than comparable vehicles; the LiDAT system tracks fuel consumption in real time and adjusts operational parameters to enhance energy savings.
The equipment comes with a 1-year coverage; nationwide, over 30 service centers ensure on-site fixes within 48 hours. Emission-related parts are backed by a 5-year quality assurance.
What options are available for customization and what is the production timeline? Available features include a choice of bucket types (rock or food bucket), Z-shaped or extended lift arms, and optional attachments like wood grippers or impact hammers. Standard units ship in 7 to 10 days, custom orders take 15 to 30 days, and international container shipping is available.
Q5: Is the device hard to use? Do you offer training? A: With the single-handle control system, new users can become proficient within 1 to 2 days; a complimentary training class covering safe handling and routine care is included upon purchase, along with digital user guides and instructional video clips for maintenance.
Q6: Does upkeep become expensive? Are replacement components available promptly? A: Hydraulic fluid needs changing every 2,000 hours, and the DIN double-sealed system cuts leakage issues by 30%; Original equipment like tires and filters is provided straight from the factory, stocked in ample quantities, and shipped across the country within 3 to 5 days after order placement, resulting in 20% to 30% reduced maintenance expenses compared to rivals.
Vertical Planetary Concrete Mixer Industrial High Efficiency Equipment Customizable

User Reviews

Like
Write a review
File a complaint

Supplier Review

Summary by Vivian

TRUST STARS

3.6/5

0 Reviews

Company Verification

0/4

Profile Completeness

67%

Avg. Product Score

0/5

Responsiveness

0%

Certification

CE certificate of tractor, CE certificate of wheel loader, ISO9000, ROPS

Related searches

Frequently Asked Questions (FAQs)


You can contact verified China supplier Weifang CP Machinery Co., Ltd. through platforms like Freshdi.com to purchase Vertical Planetary Concrete Mixer Industrial High Efficiency Equipment Customizable. For direct inquiries, please contact Ms. Annie, the company’s representative. The supplier has a 3.6-star rating on Freshdi and has verified. You’ll receive product details, pricing, and shipping terms directly from supplier.


For Vertical Planetary Concrete Mixer Industrial High Efficiency Equipment Customizable, Weifang CP Machinery Co., Ltd. accepts LC, PayPal, Small-amount payment, Western Union, D/P, T/T as the preferred payment method, the trade term is CFR, EXW, CIF, FOB, and shipments are typically arranged from port Qingdao Port, ensuring secure and timely international delivery.


The supplier Weifang CP Machinery Co., Ltd. offers Vertical Planetary Concrete Mixer Industrial High Efficiency Equipment Customizable at negotiation.


Vertical Planetary Concrete Mixer Industrial High Efficiency Equipment Customizable is sourced from China and meets international export standards. Key specifications include: Marketing Type: New Product 2024, Gear Number: Three Forwards, Three Backwards, Unique Selling Point: High Operating Efficiency, Power: 110kw, Fuel Consumption: Idle State 2L-3L, Working State 8L-10L, Type: Concrete Mixer, Trade Term: CFR, EXW, CIF, FOB, Payment Term: LC, PayPal, Small-amount payment, Western Union, D/P, T/T

You are viewing details for Vertical Planetary Concrete Mixer Industrial High Efficiency Equipment Customizable. The information provided here is either posted directly by the supplier, who is responsible for its accuracy, or collected by Freshdi AI from publicly available sources. Freshdi strives to make product information as useful and reliable as possible, but we do not guarantee complete accuracy. If you notice any incorrect or misleading details, please use the Report Product option so our team can review and address it quickly.

Negotiable

Min. order: Negotiable

Weifang CP Machinery Co., Ltd.
1 yrs

China FlagChina

3.6

Ms. Annie

Year Established: 2013-03-14

Visit Store
