Voltage Stabilizers Voltage Regulation Accuracy ±1% Of Rated Output Voltage Installation Location Installed On The Input Side Of
Negotiable
Product information
High-quality Voltage Stabilizers Voltage Regulation Accuracy ±1% Of Rated Output Voltage Installation Location Installed On The Input Side Of supplied by A.M Infra. Bulk wholesale pricing is negotiable. Inquiry for latest prices.
Regulation Mechanism:
Carbon Rollers On Fiber Glass Carrier Board Traverse Helical Coil Track
Core Flux Compensation:
Compensating Windings Connected In Parallel And Short Circuited To Reduce Core Flux Fringing
Reactance Stability:
Fairly Constant At Any Position Of Rolling Contact
Installation Location:
Installed On The Input Side Of Transformers
Output Voltage Stability:
Maintained At Rated Output Voltage Through Servo Motor Control
Control System:
Solid State Relay Operates On 230 V, 1 Phase Supply
Trade Term:
To be discussed
Payment Term:
To be discussed
Specifications
Regulation Mechanism:
Carbon Rollers On Fiber Glass Carrier Board Traverse Helical Coil Track
Core Flux Compensation:
Compensating Windings Connected In Parallel And Short Circuited To Reduce Core Flux Fringing
Reactance Stability:
Fairly Constant At Any Position Of Rolling Contact
Installation Location:
Installed On The Input Side Of Transformers
Output Voltage Stability:
Maintained At Rated Output Voltage Through Servo Motor Control
Control System:
Solid State Relay Operates On 230 V, 1 Phase Supply
Trade Term:
To be discussed
Payment Term:
To be discussed
Application:
Used To Provide Stable Input Voltage For Individual Distribution Transformers
Voltage Regulation Accuracy:
±1% Of Rated Output Voltage
Business Details
Country:
India
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Not specified
Year Established:
2013
Annual Revenue Amount:
Not specified
Numbers Of Employees:
Not specified
Preferred Payment Term:
Not specified
Preferred Trade Term:
Not specified
Port Of Loading:
Not specified
Product descriptions from the supplier
Servo voltage stabilizers (Automatic voltage regulators) are auto wound transformers having helical coils mounted on a conventional laminated core. Carbon rollers assembled on a fiber glass carrier board traverse the length of the coil track. These rollers are electrically connected to the out put terminals and as they are driven over the track, a variable voltage is obtained .Beneath the regulating coil a number of compensating winding are connected in parallel and short circuited to reduce the effect of core flux 'fringing' and keeps the reactance of the regulator fairly constant at any position of the rolling contact. The variation of more than +_ 1% of the rated output voltage of the stabilizers are sensed through solid state relay which send signals to the controlling servo motor which further drives the roller mechanism in such a direction so as to increase or decrease the voltage and stabilize it to the rated out put voltage .solid state relay operates on 230 V,1phase supply .H.T automatic voltage stabilizers are used to get stable input voltage for individual distribution transformer , irrespective of High / low voltage being received from electricity authority. These are installed on the input side of the transformers.
