WiFi6 Wireless 5G MiFi Router Mobile 5G WiFi SIM Card Routers with battery
1 Piece
$451 Piece
$42Product information
High-quality WiFi6 Wireless 5G MiFi Router Mobile 5G WiFi SIM Card Routers with battery supplied by Shenzhen E-Lins Communication Co., Limited. Bulk wholesale pricing ranges from $42 to $45 per Piece with a minimum order of 1 Piece. Inquiry for latest prices.
SIM Card Slot:
1
USB:
1 x Type C
Size:
135mm x 70mm x 17mm
Weight:
179g
Transfer Rate:
300Mbps
Production Capacity:
50, 000PCS/Month
Battery:
5000 mAh
Specification:
5G Cellular
Specifications
SIM Card Slot:
1
USB:
1 x Type C
Size:
135mm x 70mm x 17mm
Weight:
179g
Transfer Rate:
300Mbps
Production Capacity:
50, 000PCS/Month
Battery:
5000 mAh
Specification:
5G Cellular
Class:
5G MiFi Router
Network:
5G NR / 4G / 3G
Charging:
5V/2A
WiFi:
802.11 a/b/g/n/ax, Wi-Fi6
HS Code:
8517629900
Transport Package:
Box
Certificates:
CE, RoHS, CCC
Trademark:
E-Lins, OEM, ODM, Neutral
Trade Term:
FOB
Firewall:
Firewall
Antenna:
Internal
VPN:
L2TP, PPTP
Performance:
Line-Rate Router
Model NO.:
MN20
Port Structure:
Modular
Application:
SOHO
Origin:
Shenzhen, China
Architecture:
Single Bus Master-slave CPU
Payment Term:
To be discussed
Ports:
≤4
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
Not specified
Annual Revenue Amount:
Not specified
Numbers Of Employees:
Not specified
Preferred Payment Term:
Not specified
Preferred Trade Term:
FOB
Port Of Loading:
Not specified
Certificates:
RoHS
Product descriptions from the supplier
Main
Basic Information | Model Name | MN20 |
Prodcut Type | 5G
Portable MiFi | |
Dimension | Body: 135*70*17mm Package: 167*105*38mm | |
Weight | Body:
about 179g Package: 296g | |
Color | White-grey, Black, customization is available | |
OEM | Yes | |
Air Interface | Technical
Standard | Compatible
withWCDMA, FDD-LTE, TDD-LTE, 5G 802.11 a/b/g/n/ax |
Frequency | LTE TDD: B34/38/39/40/41 LTE FDD: B1/B3/B5/B8 |B1+B3 B1+B1 B3+B3 B39+Bq1 B39+B39 Bq0+Bq0 Bq1+Bq1 5G NR FDD:N1/N3/N28TID:N41/N78 | |
WiFi | 2.4GHz&5Ghz
(5.8GHz),WiFi 2*2 MIMO,802.11 a/b/g/n/ac | |
Performance | Maximum
Data Throughput | 2Gpbs/500Mbps |
Hardware | Receive
Diversity | Support
Receive Diversity |
MIMO | Support
DL 2x2 MIMO | |
Internal Power | 5000mAH | |
Power DC IN | DC5V/2A | |
USIM/SIM | 1 x SIM Card, ESIM option | |
LED | Power
Indication, WiFi Indication, 4G Status, 5G Status | |
USB | Type
C | |
Antenna | Internal
Antenna | |
Buttons | POWER,
Reset | |
Software | Main | SIM PIN, APN, Band Lock, Cell Lock, Carrier SIM Lock, TR069, AT Command, FOTA, RNDIS, Web GUI |
Environment | Operating
Temperature | Normal:-10°C to +45°C; |
Storage Temperature | -30° Cto +60° C | |
Humidity | 5%~
95% |
E-Lins IoT / M2M products are widely used in many fields, such as smart home, smart city, CCTV, finance, ATM, kiosk, vending machine, power control, water schedule, traffic, oil field, weather forecast, environmental protection, street lamp control, post, bank and many other areas.
MN20 is a superior 5G wireless routing product, using a professional 5G smart chip, which can provide 10 times the download speed of a 4G network and stable and reliable network performance.
The latest generation of Wi-Fi6 applications enhances the throughput and anti-interference capabilities of WiFi signals.
Its DBDC dual-frequency concurrent features enable a multi-user, long-distance, high-speed WiFi experience.
Supports up to 32 terminals, such as mobile phones, laptops, and tablets, to connect
Features
Platform | CPU | UDX710 |
OS | Linux | |
Memory | RAM | 4Gb,LPDDR4X |
ROM | 2Gb,NAND | |
RF | 3GPP | R8,R9..., R15 |
Throughpu
rate | HSDPA:42.2Mbps (DL) (Category 24) | |
HSUPA:11Mbps (UL)(Category 7) | ||
WCDMA:384Kbps (DL) / 384Kbps (UL) | ||
LTE FDD:300Mbps (DL) / 50Mbps | ||
LTE TDD:260Mbps (DL) / 30Mbps | ||
5G NR TDD:2Gbps (DL) / 500Mbps (UL) | ||
Antenna | LTE ANT: 1T2R;5G ANT: 1T4R | |
WCDMA / HSPA | B1 | |
TDD-LTE | B34 / 38 / 39 / 40 / 41 | |
FDD-LTE | B1 / B3 / B5 / B8 | |
CA | B1+B3 B1+B1 B3+B3 B39+B41 B39+B39 B40+B40 B41+B41 | |
5G NR | FDD:N1 / N3 / N28 TDD:N41 / N78 | |
Output power | Class 3 (24 dBm +1 / -3 dB), WCDMA Class 3 (23 dBm ±2 dB), LTE Class 3 (23 dBm ±2 dB),5G NR |
WIFI6 2.4GHz | Protocol | IEEE 802.11 a/b/g/n/ac/ax |
Frequency | 2.4GHz | |
Bandwidth | 20/40MHz | |
Receive Sensitivity | MCS9: -63dBm@10% PER MCS7: -68dBm@10% PER 54M: -70dBm@10% PER 11M: -83dBm@8% PER 6M: -88dBm@10% PER 1M: -90dBm@8% PER | |
Transmit Power | 16dBm(Max) in 11b mode 14dBm(Max) in 11g mode 14dBm(Max) in 11n mode 13dBm(Max) in 11ax mode | |
Throughput | 11ax: 286.8Mbps@TX and 229.4Mbps@RX 11g: 54/48/36/24/18/12/9/6 Mbps 11b: 11/5.5/2/1 Mbps 11n: 150 Mbps /…/6.5Mbps | |
WIFI6 5GHz | Protocol | IEEE 802.11
a/b/g/n/ac/ax |
Frequency | 5GHz | |
Bandwidth | 20/40/80MHz | |
Receive Sensitivity | MCS9: -63dBm@10% PER MCS7: -68dBm@10% PER 54M: -70dBm@10% PER 11M: -83dBm@8% PER 6M: -88dBm@10% PER 1M: -90dBm@8% PER | |
Transmit Power | 16dBm(Max)
in 11b mode 14dBm(Max) in 11g mode 14dBm(Max) in 11n mode 13dBm(Max) in 11ax mode | |
Throughput | 11ax:
600.4Mbps 11ac: 433/390/325…32.5Mbps 11g: 54/48/36/24/18/12/9/6 Mbps 11b: 11/5.5/2/1 Mbps 11n: 150 Mbps /…/6.5Mbps |
Other | Buttons | Power on, WPS,
Reset |
Indicators | 2 x 4G indicator 2 × Power indicator 2 x 5G indicator 1 x WiFi indicator | |
USB | TYPE-C | |
Battery | 5000 mAH | |
Charging | 5V/2A | |
SIM Card | 1 x SIM Card, ESIM option | |
Temperature | Operating: -10~+45℃; Storage: -30~+60℃ | |
Dimensions | 136*72*15.74mm | |
Weight | TBD | |
Software | Language | English,
Simplified Chinese |
Protocol stack | TCP/UDP/HTTP/PING/HTTPS/FTPS/MQTT/MMS | |
SIM Card | PIN
Management | |
Support | APN
settings, Band lock, PCI lock, Cell lock, Carrier SIM lock, DHCP lock, IP
filtering, MAC filtering, TR069, AT commands, FOTA, RNDIS, Web GUI | |
WiFi | Wi-Fi
SSID settings | |
Encryption: WPA2-PSK, WPA/WPA2-PSK | ||
SSID broadcast | ||
Supports 32+ users | ||
CTA | YES |
