Woodworking Small Size Electric Wood Planer Thickness Machine
1 Piece
$1,4002 Piece
$1,300Product information
High-quality Woodworking Small Size Electric Wood Planer Thickness Machine supplied by Zouping Wosen Machinery Co., Ltd.. Bulk wholesale pricing ranges from $1,300 to $1,400 per Piece with a minimum order of 1 Piece. Inquiry for latest prices.
Production Capacity:
100 Sets/Month
Working Depth:
100-200mm
Max. Process Thickness:
130mm
Cutter Shaft:
2
Working Width:
200-400mm
Min Process Length:
200mm
Voltage:
380V or Customized
Package Gross Weight:
400.000kg
Specifications
Production Capacity:
100 Sets/Month
Working Depth:
100-200mm
Max. Process Thickness:
130mm
Cutter Shaft:
2
Working Width:
200-400mm
Min Process Length:
200mm
Voltage:
380V or Customized
Package Gross Weight:
400.000kg
Pressure Gauge:
5mm
HS Code:
8465920000
Package Size:
90.00cm * 85.00cm * 120.00cm
Specification:
900*850*1200mm
Color:
Blue
Refund Policy:
Claim a refund if your order doesn't ship, is missing, or arrives with product issues.
Shipping Cost:
Contact the supplier about freight and estimated delivery time.
Power:
Electric Engine
Trade Term:
FOB
Drivetrain:
Feed Drivetrain
Certification:
ISO
Model NO.:
MB204, MB206
Enter Method:
Mechanical
Process Type:
Medium-Sized Processing
Transport Package:
PE Film or Plywood Box
After Sales Service:
Provide
Origin:
Shandong Province, China
Blade Type:
Straight Blade
Payment Methods:
Support payments in USD
Payment Term:
To be discussed
Process Material:
Wood Boards
Product Name:
Wood Planer Thicknesser
Trademark:
Wosen
Spindle Speed:
＜5000rpm
Motor Power:
＜5Kw
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
Not specified
Annual Revenue Amount:
Not specified
Numbers Of Employees:
Not specified
Preferred Payment Term:
Not specified
Preferred Trade Term:
FOB
Port Of Loading:
Not specified
Certificates:
CE
Product descriptions from the supplier
Double Side Wood Planer
A dual-face planer is a mechanical tool designed for woodworking, enabling simultaneous smoothing of both sides of a wooden piece to meet specified thickness and surface level. This machine plays a vital role in wood manufacturing, offering benefits such as superior speed, accurate results, and user-friendly handling.
Main features:
Double-sided processing: can process the upper and lower sides of wood at the same time to improve efficiency.
High precision: equipped with precision adjustment device to ensure processing accuracy.
High efficiency and energy saving: using advanced motors and transmission systems to reduce energy consumption.
Safe and reliable: equipped with multiple safety protection devices to ensure safe operation.
2.Heavy Duty Wood Planer
Main features:
Double-sided processing: can process the upper and lower sides of wood at the same time to improve efficiency.
High precision: equipped with precision adjustment device to ensure processing accuracy.
High efficiency and energy saving: using advanced motors and transmission systems to reduce energy consumption.
Safe and reliable: equipped with multiple safety protection devices to ensure safe operation.
| Specification | MB203 | MB204 |
| Max. Planing Width | 300mm | 400mm |
| Max. Press Thickness | 130mm | 130mm |
| Pressure Gauge | 5mm | 5mm |
| Min. Cutting Length | 200mm | 200mm |
| Max. Cut Surface Knife | 4mm | 4mm |
| Bottom Knife Cutting Quantity | 2mm | 2mm |
| Motor Power | 4KW 380V | 5.5KW 380V |
| Over Dimensions | 800x800x1100mm | 800x800x1100mm |
1.Four Side Planer
| Specification | MB404A |
| Max. Planing Width | 400mm |
| Max. Planing Thickness | 20-120mm |
| Max. Planing Depth | 5mm/3mm/5mm/5mm |
| Arbor Speed | 8000 r/min |
| Arbor Motor Power | 5.5KW/380V |
| Left & Right Spindle Speed | 7000 r/min |
| Left & Right Spindle Motor | 3KW/380V |
| Feeding Speed | 9.2m/min / 7.5m/min |
2.Heavy Duty Wood Planer
| Model | WS410 | WS610 |
| Process Wood Width | 10-410mm | 10-610mm |
| Process Wood Thickness | 9-160mm | 9-200mm |
| Min Process Length | 300mm(200mm) | 300mm(200mm) |
| Max.Cutting Depth | Top/Bottom 5mm | Top/Bottom 5mm |
| Saw Spindle Diameter | 100mm | 100mm |
| Spindle Speed | 5000 r/min | 5000 r/min |
| Feeding Speed | 6-13m/min | 3-24 m/min |
| Total Power | 15.57KW | 21.07KW |
| Total Weight | 2000kg | 2400kg |
Our company is China leading manufacturer of woodworking machinery,we are able to offer professional woodworking machinery to customers.
Our products are mainly included wood crusher,band saw, circular sawmill, wood pallet machine, wood pellet machine, wood planer, production line and so on. We have exported our machines to more than 70 countries and regions around the world, such as Southeast Asia, North America, South America, Africa, Europe, Middle East, Australia, Russia and so on.
To address diverse customer needs, we continuously enhance our product technology, craftsmanship, and post-purchase support. By tailoring machines to specific client demands, we have secured strong satisfaction and trust from numerous customers.
If you are interested in our machine, please feel free to contact us
1.What is the machine delivery time ?
Delivery time is 10-15 days.
2.What is the payment term ?
Payment term is 30% TT advance and balance before delivery machine.
3.Could the machine customized according to client requirements ?
Yes, can customize according to client requirements.
4.What terms of trade can provide?
We accept EXW, FOB, CIF, Express Delivery.
5. What is your company business scope ?
Our company main sell woodworking machine, including wood crusher, wood sawmill, wood pallet machine, wood pellet machine, drying kiln, wood planer and so on.
In order to make our customers satisfaction,we have perfect pre-sale, on purchase and after-sales service system.
Pre-sale service:
1.Reply customer's email or call customer back in 1 work hour if missed any calls.
2.Design the best processes and programs according to customer's requirement.
3.Answer customer's questions patiently,remove customer concerns.
On purchase service :
1.We will timely tell the customer's machine production situation, provide production video or pictures.
2.We will commissioning the machines and provide pictures or video before shipment.
3.Arrange customs declaration, sea shipping, insurance, and assist customers in customs clearance.
After-sales service :
1.Our machines' warranty period is 12 month.
2.Provide the solution of the installation or use problem within 3 working hours.
