X5 Split Type Air Source Heat Pump
Pieces
Negotiable
Product information
High-quality X5 Split Type Air Source Heat Pump supplied by GZ Theodoor Tech Co., Ltd.. Bulk wholesale pricing is negotiable. Inquiry for latest prices.
Working Temp:
-10-43 Degrees
Specification:
100L-500L
Water Tank:
100L-500L
Production Capacity:
2000PCS
HS Code:
8418
Type:
Air Source Heat Pump
Heat Source:
Air-source
Certification:
CE, ISO9001, CCC, CB
Specifications
Working Temp:
-10-43 Degrees
Specification:
100L-500L
Water Tank:
100L-500L
Production Capacity:
2000PCS
HS Code:
8418
Type:
Air Source Heat Pump
Heat Source:
Air-source
Certification:
CE, ISO9001, CCC, CB
Transport Package:
Carton Box
Work Environment:
Common Heat Pump
Trade Term:
FOB, CFR, CIF, FAS, DAP, CIP, CPT, FCA, EXW
Origin:
Guangzhou, China
Port Of Loading:
Huangpu, Guangzhou, Shenzhen
Payment Term:
LC, T/T, PayPal
Heating Type:
Multi-power Heat
Compressor:
Panasonic
Refrigerant:
R410A or R417A
Model:
RS-3.6fj Series
Housing Material:
SUS 304 Stainless Steel
Heat Exchanger:
SUS 316 Stainless Steel
Brand:
Theodoor
Trademark:
Theodoor
Application:
Villa Family, Sauna and Swimming Pool, Hotels, Factory Hospital, Student Apartments, Beauty Salons
Model NO.:
X5 series
Auto Defrost:
Yes
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
2002-11-20
Annual Revenue Amount:
Not specified
Numbers Of Employees:
Not specified
Preferred Payment Term:
LC, T/T, PayPal
Preferred Trade Term:
FOB, CFR, CIF, FAS, DAP, CIP, CPT, FCA, EXW
Port Of Loading:
Huangpu, Guangzhou, Shenzhen
Certificates:
CB, CCC, CE -5G, CE -FM32-35-40, CE -X7, ISO 9001 certificates, ISO14001:2015, ROHS, UL
Product descriptions from the supplier
Product Description
Heat pump and heat exchanger water storage units are independently placed from the main unit, linked via a dedicated pipe, where the main system circulates and warms the storage tank to a preset level. Typically positioned outside the primary unit, heat exchanger tanks may be placed either indoors or outdoors, making them common in residential, villa, and small business settings.
Constant temperature and comfortable
Advanced dual temperature regulation ensures precise control, featuring innovative resistive water blending for stable thermal output. A 360° enhanced foaming process achieves up to 50mm of polyurethane insulation.
Superior materials
Features a Panasonic compressor specifically designed for air-source heat pumps. Equipped with an extended heat exchanger coil made from aluminum alloy or 316 stainless steel. The outer casing uses 304 stainless steel, digitally welded for corrosion resistance and long-term strength. Features a thick-walled, food-safe 304 stainless steel inner chamber.
Class 1 energy efficiency
4.5 COP exceeds national average, offering superior energy performance. Strong heat output supported by a backup heater, capable of delivering hot water up to 70ºC.
Easy control
Offers three temperature settings: AUTO, ECO (cost-effective), and HEATER (rapid warm-up). Features integrated magnesium anode rods for water purification and scale resistance. Smart reverse defrost technology.
X5 SERIES:
| Model | RS-3.6FJ/100L | RS-3.6FJ/150L | RS-4.8FJ/260L | RS-6.8FJ/260L | RS-6.8FJ/320L | RS-6.8FJ/500L |
| Rated Input Power | 0.88 KW | 1.2KW | 1.7 KW | |||
| Rated Heating Capacity | 3.6 KW | 4.8KW | 6.8 KW | |||
| Heating ampere | 4.0A | 5.45A | 7.73A | |||
| Power Supply | 220V~50Hz | |||||
| Outlet water temperature | 55 degrees | |||||
| Water output capacity | 77L/H | 103L/H | 146L/H | |||
| Capacity of Water Tank | 100L | 150L | 260L | 260L | 320L | 500L |
| Refrigerant | R417A /R410A | |||||
| Compressor | Panasonic | |||||
| Condenser | Copper coil | |||||
| Evaporator | High efficiency finned heat exchanger | |||||
| Size of Outdoor unit (mm) | 780x255x540 | 840x283x610 | ||||
| Outdoor unit N.W. (Kg) | 29 | 33 | 45 | |||
| Noise (dB) | 45 | 48 | 52 | |||
| Size of Water Tank (mm) | ∮470X1030 | ∮470X1470 | ∮560X1560 | ∮560X1560 | ∮560X1870 | ∮700X1880 |
| Water tank N.W. (Kg) | 27KG | 34KG | 52KG | 56KG | 62KG | 70KG |
| Water connection | DN15 | DN15 | DN15 | DN15 | DN15 | DN20 |
Company information
STAR BRAND
Guangzhou Theodoor Technology Co., Ltd. is a leading advanced technology firm specializing in research, development, and production of energy-efficient solutions like Air Source Heat Pumps and Air Curtains. Recognized as a top-tier name in the heat pump sector, Theodoor offers a wide range of heat pump systems and serves markets across over 80 countries and regions.
PRECISION PRODUCTION
Established in 2002, Theodoor operates within Guangzhou's Innovation and Development Zone—Sino-Singapore Knowledge City (SSGKC), spanning 30,000 square meters. Our state-of-the-art manufacturing facility leverages cutting-edge machinery and precision testing tools to ensure consistent, high-accuracy production. Theodoor offers a comprehensive product range tailored to diverse, specific requirements across international markets.
INNOVATION TECHNOLOGY
Theodoor has consistently driven innovation, establishing both a nationally recognized environmental simulation lab and a dedicated heat pump endurance testing facility. Additionally, the company holds over 80 national invention and technical patents, setting new benchmarks in product quality and advancement within the sector. Its products and operations have achieved compliance with ISO9001, ISO14001, CCC, CE, CB, ROHS, ERP, UL, SASO, INMETRO, and SAA standards, among others.
FAQ
Why the air source heat pump is the most energy saving water heater?
Instead of using a heating coil, an air source heat pump employs minimal electricity to power its compressor, drawing in cold air, compressing it to a higher temperature, and then circulating it via a piping system to warm the water—using just one-fourth the energy of conventional electric water heaters.
How to choose the suitable capacity?
Select a water tank capacity based on hot water demand, bathroom count, presence of bathtubs, kitchen usage, and other hot water needs.
| Q1. | What is your terms of packing? |
| A1: | Typically, our products are shipped in brown packaging. Once you have a legally granted patent, we can place them in your branded containers upon receiving your official permission documents. |
| Q2. | What is your terms of payment? |
| A2: | T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages before you pay the balance. |
| Q3. | What is your terms of delivery? |
| A3: | EXW, FOB,CFR,CIF,DDU etc. |
| Q4. | How about your delivery time? |
| A4: | Delivery typically occurs between 30 and 60 days following your advance payment, depending on the products and order volume. |
| Q5. | Can you produce according to the samples? |
| A5: | Yes, we can produce by your samples or technical drawings. We can build the molds and fixtures. |
| Q6. | What is your sample policy? |
| A6: | We can supply the sample if we have ready parts in stock, but the customers have to pay the sample cost and the courier cost. |
Q7. |
Do you test all your goods before delivery? |
| A7: | Yes, we have 100% test before delivery. |
| Q8: | How do you make our business long-term and good relationship? |
| A8: | 1. We keep good quality and competitive price to ensure our customers benefit ; 2. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from. |
