X8132 Universal Knee-Type Tool Milling Machine Tool Milling Machine
Set
Negotiable
Product information
High-quality X8132 Universal Knee-Type Tool Milling Machine Tool Milling Machine supplied by Supertech Machine Tool Co., Ltd.. Bulk wholesale pricing is negotiable. Inquiry for latest prices.
Specification:
1500*1700*1800
T Slots(Number/Width/D:
3/14/63
T Slots:
5/14/63
Horizontal Table Size:
750*320mm
Verital Table Size:
890*225
Milling Cutter Type:
Angle Milling Cutter
Controlling Mode:
Artificial
Structure:
Bed type
Specifications
Specification:
1500*1700*1800
T Slots(Number/Width/D:
3/14/63
T Slots:
5/14/63
Horizontal Table Size:
750*320mm
Verital Table Size:
890*225
Milling Cutter Type:
Angle Milling Cutter
Controlling Mode:
Artificial
Structure:
Bed type
Certification:
CE, ISO 9001
Trade Term:
FOB, CIF, CFR, EXW
Precision:
High Precision
Milling Cutter Structure:
Indexable Type
Origin:
Jiang Su China
Payment Term:
LC, T/T, D/P, PayPal, Western Union, Small-amount payment
Automatic Grade:
Manual
Condition:
New
Port Of Loading:
Shanghai Port
Trademark:
Supertech
Object:
Tool
Type:
Tool Milling Machine
Transport Package:
Wooden Case
Model NO.:
X8132/8140
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
2015-05-06
Annual Revenue Amount:
Not specified
Numbers Of Employees:
5
Preferred Payment Term:
LC, T/T, D/P, PayPal, Western Union, Small-amount payment
Preferred Trade Term:
FOB, CIF, CFR, EXW
Port Of Loading:
Shanghai Port
Certificates:
CE
Product descriptions from the supplier
SONA2024 2.2.1
Product Description
PERFORMANCE
X8132 is a vertical universal lifting platform tool milling machine. Its core function is to perform various types of milling operations on metal workpieces, suitable for small and medium batch production as well as mold and part repair scenarios.
Core function
Plane and step surface processing: It can machine horizontal planes, vertical planes, and step surfaces. Combined with end mills and face mills, it can achieve efficient processing.
Groove processing: It can machine straight grooves, V-shaped grooves, T-shaped grooves, and dovetail grooves, etc. It is compatible with special tools such as three-edge milling cutters and keyway milling cutters.
Formed surfaces and complex part processing: With the universal dividing head and universal milling head, it can machine complex structures such as gears, splines, inclined planes, and circular arc surfaces.
Drilling, reaming, and tapping auxiliary functions: With special accessories, it can complete simple hole processing and achieve integrated "milling + hole processing" operation.
Plane and step surface processing: It can machine horizontal planes, vertical planes, and step surfaces. Combined with end mills and face mills, it can achieve efficient processing.
Groove processing: It can machine straight grooves, V-shaped grooves, T-shaped grooves, and dovetail grooves, etc. It is compatible with special tools such as three-edge milling cutters and keyway milling cutters.
Formed surfaces and complex part processing: With the universal dividing head and universal milling head, it can machine complex structures such as gears, splines, inclined planes, and circular arc surfaces.
Drilling, reaming, and tapping auxiliary functions: With special accessories, it can complete simple hole processing and achieve integrated "milling + hole processing" operation.
Specification
Mainspecifications | Unit | X8132 | X8140 |
Horizontal table size | mm | 750*320 | 800*400 |
T-slots(Number/Width/D) | mm | 5/14/63 | 5/14/63 |
Vertical table size | mm | 890*225 | 890*225 |
T-slots(Number/Width/D) | mm | 3/14/63 | 3/14/63 |
X/Y/Z axes travel | mm | 405/305/400 | 500/400/400 |
Spindle taper(H.&V.) | / | NT40 | NT 40 |
Spindle speeds(H.&V.,variable) | rpm | 40-2000 | 40-2000 |
Stroke of vertical pindle quill | mm | 60 | 60 |
Feed rate(X/Y/Z axes) | mm/min | 10-1000 | 10-1000 |
Feed motor torque(X/Y/Z axes) | NM | 7.717.7/10 | 7.717.7/10 |
Power of spindle motor(Vertical/Horizontal) | KW | 3.7 | 3.7 |
Overalldimension | mm | 1500*1700*1800 | 1550*1750*1800 |
Net weight | kg | 1450 | 1550 |
Company Profile
Certifications
Exhibition and Customers
Packing & Delivery
After the machines' model and contract confirmed, we will calculate the space for the containers asked. Commonly we load the containers in our factory by ourselves. But also support EXW term and welcome to send other machines/good to our factory to load together. We have professional team in loading and fixing for truck, sea container, train and so on.
Please enter the title here
1.Q:Where is your factory located? How can I visit there?
A: Our factory is located in Yancheng City,Jiangsu, China. It takes about 2.5 hours from Shanghai or Nanjing by train;2 hours from Guangzhou or Beijing by airplane.
2.Q: What is the lead time?
A: It depends on your order quantity. Standard machines15-30 days, special configurations need 30-45 calendar days.
3.Q: Where is your loading port?
A: Mainly it's Shanghai port, others as discussion.
4.Q: What are your payment terms?
A: T/T 30% deposit and balance payment before shipment; or 100% LC at sight.
5.Q: Can you export and supply the customs clearance documents we need?
A: We have much experience on exporting, supply the CE certificate, Form E, price certification and so on as standard, special documents with discussion
6.Q:What's the guarantee time for your machines?
A: Our guarantee time is 15 months after machines leaving our factory, technical support for life.
A: Our factory is located in Yancheng City,Jiangsu, China. It takes about 2.5 hours from Shanghai or Nanjing by train;2 hours from Guangzhou or Beijing by airplane.
2.Q: What is the lead time?
A: It depends on your order quantity. Standard machines15-30 days, special configurations need 30-45 calendar days.
3.Q: Where is your loading port?
A: Mainly it's Shanghai port, others as discussion.
4.Q: What are your payment terms?
A: T/T 30% deposit and balance payment before shipment; or 100% LC at sight.
5.Q: Can you export and supply the customs clearance documents we need?
A: We have much experience on exporting, supply the CE certificate, Form E, price certification and so on as standard, special documents with discussion
6.Q:What's the guarantee time for your machines?
A: Our guarantee time is 15 months after machines leaving our factory, technical support for life.
