Xtpack Full Automatic Horizontal Waste Cardboard Carton Trim Baling Compactor
Set
Negotiable
Product information
High-quality Xtpack Full Automatic Horizontal Waste Cardboard Carton Trim Baling Compactor supplied by Jiangsu Xutian Environmental Protection Machinery Co., Ltd.. Bulk wholesale pricing is negotiable. Inquiry for latest prices.
Oil Reservoir:
1100L
Machine Weight:
14tons
Feeding Opening Size:
1600X1050
Voltage:
220-480V
Main Motor Power:
22kw
Number Of Belting:
4 Lines
Throuhput:
4-8tons/H
Bale Density(Occ):
420-500kgs/M3
Specifications
Oil Reservoir:
1100L
Machine Weight:
14tons
Feeding Opening Size:
1600X1050
Voltage:
220-480V
Main Motor Power:
22kw
Number Of Belting:
4 Lines
Throuhput:
4-8tons/H
Bale Density(Occ):
420-500kgs/M3
Production Capacity:
500-1000sets/Year
Specification:
60Tons/80Tons
Pressure:
60tons
HS Code:
8422400090
Cooling System:
Air Cooler/Water Cooler
Automatic Grade:
Automatic
Bale Ejection:
Continuously
Customized:
Customized
Wire Size:
D2.7-3.2
After Sales Service:
Engineers Available to Service Machinery Overseas
Trade Term:
FOB, CIF, CFR, EXW
Bale Size:
L*1100*750
Payment Term:
LC, T/T, D/P, PayPal, Western Union, Small-amount payment
Transport Package:
Loaded in 40hq
Origin:
Nantong China
Condition:
New
Port Of Loading:
Shanghai Port
Application:
Waste Cardboards, Cartons, Paper, Plastic LDPE,
Trademark:
XTPACK
Model NO.:
XTY-600W11075-30
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
2012
Annual Revenue Amount:
Not specified
Numbers Of Employees:
Not specified
Preferred Payment Term:
LC, T/T, D/P, PayPal, Western Union, Small-amount payment
Preferred Trade Term:
FOB, CIF, CFR, EXW
Port Of Loading:
Shanghai Port
Certificates:
CE
Product descriptions from the supplier
XTPACK Full Automatic Horizontal Waste Cardboard Carton Trim Baling Compactor
Usage
Widely used for compressing waste cardboards,cartons,paper,plastic film,straw etc.
Features
Photoelectric switch activates baler when charge box is full
Unique double-cutting design of cutters improves the cutting efficiency and lengthens the lifespan of the cutters
Particular anti-slide design of the machine makes nicer bales
Unique trunnion-mounted frame and ball-end joint design for the main cylinder avoid the torque on the rod, which lengthens the lifespan of the seals
Equipped with rapid automatic tying system, easy for cleaning and maintaining
Use differential technique for the hydraulic system, makes shorter cycle time so that improve the working efficiency and save electricity
Automatic tension system ensures "brick-like" bales on all loose materials.
Adjustable bales length and bales quantity accumulating function make the operation of the machine more convenient
Automatically detect and show the errors of the machine which improve the machine inspection efficiency
International standard electric circuit layout, graphic operation instruction and detailed parts marks makes the operation been more easily understanding and improves the maintenance efficiency
The press heads are specially processed by planomiller, ensures the precise running of the ram
Use high quality hydraulic system from Taiwan, ensures the stable running of the machine
The heavy duty machine body makes sure only flat ground is required by the installation
Specifications
| Model | XTY-600W11075-30 | XTY-800W11080E-30 | XTY-800W11075-50 XTY-800W11075KL-50 |
XTY-800W11075L-50 |
| Pressure | 60tons | 80tons | 80tons | 80tons |
| Main Motor Power | 22kW | 22kW | 37.5kW | 37.5kW |
| Cooling System | air cooler/water cooler | air cooler/water cooler | air cooler/water cooler | air cooler/water cooler |
| Cycle Time(Unload) | 24s | 22s | 16s | 28s |
| Oil Reservoir | 1000L | 1200L | 1100L | 1100L |
| Number of Belting | 4lines | 4lines | 4lines | 4lines |
| Wire Size | Ø2.7-3.2 | Ø2.7-3.2 | Ø2.7-3.2 | Ø2.7-3.2 |
| Feeding Opening Size(L×W) | 1780×1050mm | 1480×1050mm | 1780×1050mm | 2580×1050mm |
| Bale Size (L×W×H,L can be adjustable) |
L×1100×750mm | L×1100×800mm | L×1100×750mm | L×1100×750mm |
| Bale Density(OCC) | 400-500kgs/m³ | 420-500kgs/m³ | 420-500kgs/m³ | 420-500kgs/m³ |
| Throughput(30-60kgs/m³) | 3-7tons/h | 3-6tons/h | 4-8tons/h | 5-9tons/h |
| Machine Weight | 13tons | 12tons | 14tons | 15tons |
| Machine Overall Dimension | 7950×4100×3500mm | 6800×4100×3500mm | 8100×4100×3500mm 9500×4200×3500mm |
9500×4100×3500mm |
| Tying | Horizontal Tying or Vertical Tying | |||
| Feeding Device | Conveyor | Conveyor | Conveyor | Conveyor |
| Conveyor | ||||
| Feeding Width | 1600mm | 1200mm | 1600mm | 2000mm |
| Speed | 18m/min | 18m/min | 18m/min | 18m/min |
| Power | 4kW/5.5kW | 4kW/5.5kW | 4kW/5.5kW | 4kW/5.5kW |
| Weight | 5tons | 4tons | 5tons | 6tons |
| Overall Dimension | 9000×2100×4500mm | 9400×1550×4300mm | 9000×2100×4500mm | 9000×2500×4500mm |
