Xzh Test Xhjb634 Protection Relay Test Set Origin Shaanxi Model NO. XHJB634 Trademark XZH TEST Specification 38*78*62 Production Capacity
1-2 Piece
$3,3003 Piece
$3,200Product information
High-quality Xzh Test Xhjb634 Protection Relay Test Set Origin Shaanxi Model NO. XHJB634 Trademark XZH TEST Specification 38*78*62 Production Capacity supplied by Xian XZH Electric Power Technology Co., Ltd.. Bulk wholesale pricing ranges from $3,200 to $3,300 per Piece with a minimum order of 1 Piece. Inquiry for latest prices.
Ambient Temperature:
-10℃ ~ +50
Output Accuracy:
0.2 Level
Harmonic Frequency:
1~20 Times
Production Capacity:
20000
Specification:
38*78*62
Power Supply:
AC 220V±10%, 50/60Hz
Trade Term:
FOB, CIF, CFR, EXW
Origin:
Shaanxi
Specifications
Ambient Temperature:
-10℃ ~ +50
Output Accuracy:
0.2 Level
Harmonic Frequency:
1~20 Times
Production Capacity:
20000
Specification:
38*78*62
Power Supply:
AC 220V±10%, 50/60Hz
Trade Term:
FOB, CIF, CFR, EXW
Origin:
Shaanxi
Port Of Loading:
Shenzhen Port, Ningbo Port, Yiwu Port
Payment Term:
T/T, PayPal
Transport Package:
Wooden Case
Model NO.:
XHJB634
Trademark:
XZH TEST
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
2022-08-12
Annual Revenue Amount:
Not specified
Numbers Of Employees:
5
Preferred Payment Term:
T/T, PayPal
Preferred Trade Term:
FOB, CIF, CFR, EXW
Port Of Loading:
Shenzhen Port, Ningbo Port, Yiwu Port
Certificates:
ISO14001:2015, Others, ISO9001:2015
Product descriptions from the supplier
XHJB634 microcomputer relay protection calibrator is a new type of miniaturized microcomputer relay protection tester fully realized by modern advanced microelectronic technology.
AC current output
Output accuracy 0.2 level
Phase current output (effective value) 0~40A
Triple current output (effective value) 0~120A
Maximum output power of phase current 420VA
Maximum output power at the maximum output of triple parallel current 900VA
Allowable working time at maximum output of triple parallel current: 10s
Frequency range (fundamental wave) 20~1000Hz
Harmonic frequency 1~20 times
DC current output
Output accuracy 0.2 level
Current output 0~±10A / each phase, 0~±30A / triple parallel
Maximum output load voltage 20V
AC voltage output
Output accuracy 0.2 level
Phase voltage output (effective value) 0~120V
Line voltage output (effective value) 0~240V
Phase voltage/line voltage output power 80VA / 100VA
Frequency range (fundamental wave) 20~1000Hz
Harmonic frequency 1~20 times
DC voltage output
Output accuracy 0.2 level
Phase voltage output amplitude 0~±160V
Line voltage output amplitude 0~±320V
Phase voltage/line voltage output power 70VA / 140VA
Output accuracy 0.2 level
Phase current output (effective value) 0~40A
Triple current output (effective value) 0~120A
Maximum output power of phase current 420VA
Maximum output power at the maximum output of triple parallel current 900VA
Allowable working time at maximum output of triple parallel current: 10s
Frequency range (fundamental wave) 20~1000Hz
Harmonic frequency 1~20 times
DC current output
Output accuracy 0.2 level
Current output 0~±10A / each phase, 0~±30A / triple parallel
Maximum output load voltage 20V
AC voltage output
Output accuracy 0.2 level
Phase voltage output (effective value) 0~120V
Line voltage output (effective value) 0~240V
Phase voltage/line voltage output power 80VA / 100VA
Frequency range (fundamental wave) 20~1000Hz
Harmonic frequency 1~20 times
DC voltage output
Output accuracy 0.2 level
Phase voltage output amplitude 0~±160V
Line voltage output amplitude 0~±320V
Phase voltage/line voltage output power 70VA / 140VA
Switch quantity and time measurement
Industrial Control Type Remarks
Switch input 8 channels Empty contact: 1~20mA, 24V
Potential contact access: "0": 0~ +6V; "1": +11 V~ +250V
Switch output 4 pairs DC: 220V/0.2A; AC: 220V/0.5A
Time measurement Measuring range 0.1ms ~ 9999s Measuring accuracy 0.1mS
volume and weight
Industrial control type
Dimensions 410×360×200mm³
Single machine weight 20kg
Power supply AC 220V±10%, 50/60Hz
Ambient temperature -10ºC ~ +50ºC
