Zinc Oxide Arrester Material ZnO Origin China Brand Mingzhe Shape Gyro Type Trademark MINGZHE HS Code 8538900000 Application
Piece
Negotiable
Product information
High-quality Zinc Oxide Arrester Material ZnO Origin China Brand Mingzhe Shape Gyro Type Trademark MINGZHE HS Code 8538900000 Application supplied by Wenzhou Mingzhe Electric Co., Ltd.. Bulk wholesale pricing is negotiable. Inquiry for latest prices.
Production Capacity:
2000PCS/Week
Specification:
40*50*70
Nominal Discharge Current:
5kv
Nominal Discharge Current Kv:
5kv 10kv 24kv
Max Discharge Current Kv:
6-220kv
HS Code:
8538900000
Transport Package:
Carton
Origin:
China
Specifications
Production Capacity:
2000PCS/Week
Specification:
40*50*70
Nominal Discharge Current:
5kv
Nominal Discharge Current Kv:
5kv 10kv 24kv
Max Discharge Current Kv:
6-220kv
HS Code:
8538900000
Transport Package:
Carton
Origin:
China
Certifications:
En360 CE CCC
Trade Term:
FOB, EXW, CFR, CIF, DAT, FAS, DDP, DAP, CPT, FCA
Shape:
Gyro Type
Model NO.:
HY5WZ-7.6/27
Payment Term:
LC, T/T, D/P, PayPal, Western Union, Small-amount payment
Protections:
Lighting Protection,Barchmetric Protection,Delay
Operation Voltage:
Low Voltage,Medium Voltage,High Voltage
Trademark:
MINGZHE
Housing:
Metal Zinc Oxid Arrester
Brand:
Mingzhe
Port Of Loading:
Ningbo, Shanghai, Sichuang
Protection:
Overvoltage,Overload,Overtemperature
Installation:
Parallel Arrester
Use Place:
Power Distribution,Power Station
Certification:
ROHS, ISO9001, CCC
Size:
Smal Mudium,Large
Application:
Substation
Material:
ZnO
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
2010-10-01
Annual Revenue Amount:
Not specified
Numbers Of Employees:
Not specified
Preferred Payment Term:
LC, T/T, D/P, PayPal, Western Union, Small-amount payment
Preferred Trade Term:
FOB, EXW, CFR, CIF, DAT, FAS, DDP, DAP, CPT, FCA
Port Of Loading:
Ningbo, Shanghai, Sichuang
Certificates:
arrester, FKN12 load switch, High voltage earthing switch, High voltage transformer, Indoor isolator switch, Insulator, Intelligent ACB, Pole mounted LBS, SF6, SF6 load break switch24kv, SF6 load break switchh ABBIII, SF6 switchger mechanism, Siemens CPU, Soild insulated break switch, Vacuum circuit break, ZW32 high voltage switch
Product descriptions from the supplier
The zinc oxide HY5W seriesarrester is mainly used to protect distribution transformer, cable connector and electric equipment from being damaged by lightning impulse voltage and operated over-voltage.
The zinc oxide HY5W seriesarrester is the most advanced over-voltage protector in the world. Due to make the resistor disc of core component mainly adopt zinc oxide arrester. Compared with the traditional silicon-carbide arrester, this prescription of the product improves greatly the volt-Ampere characteristics of the resistor discand increase through-current capability at over-voltage so as to bring a radical-change for the characteristics of the arrester.Under the circumstance of normal operating voltage, the current through the arrester is just on microampere degree, When suffered from over-voltage, the arrester's excellent nonlinear characteristics will make the current through the arrester increase to several thousand amperes, while the arrester will be under the circulating state and release over-voltage energy so as to protecting the power transmission equipments against the damage caused by the over-voltage
Features:
1. Small size, Light weight, resistance to impact, no collision damage during transportation, flexible installation, suitable for use in the switch cabin.
2. Special structure, the overall compression molding, no air gap, good sealing performance, moisture-proof and explosion-proof
3. Large creepage distance, good hydrophobicity, strong stains resistance, stable performance and reduce operation maintenance.
4. Unique formula of zinc oxide varistor, small leakage current, long service life.
5. With DC reference voltage, rectangular flow capacity and high current and large current withstand capacity are higher than standard requirement.
Technical Standard
The design and test of Metal Oxide Polymer Surge Arrester is complied full with IEC99-4.
Sevice Conditions
a) Ambient air temperature within the range of -55°C to +50°C.
b) Altitude not exceeding 2000m.
c) Frequency of the A.C. Power supply not less than 48hz and not exceeding 62hz.
d) Power frequency voltage applied continuous between the teminals of the arrester not
exceeding its continuous operating voltage.
e) Maximum wind speed not exceeding 35m/s.
f) Earthquake intensity not exceeding 7 degrees.
Advantage
- Low residual voltage
- Long protection distance
- High energy input capacity
- Stable U-I characteristics even after multiple strokes
- Proof against ageing
- Explosion and shatter-resistant design
- Pollution resistant and UV-stable
- Housing resistant to rough handling
- Maintenance free
- Stable against shock and vibration
- High mechanical resistance
| Model | Price | Unit | Use place | Remark |
| HY5WS-7.6/30 | set | Power distribution | ||
| HY5WS-12.7/50 | set | |||
| HY5WZ-7.6/27 | set | Power Station | ||
| HY5WZ-12.7/45 | set | |||
| HY5WZ-42/134 | set | |||
| HY5WZ-34/85 | set | |||
| HY5wR-7.6/27 | set | Parallel compensation capacitor bank |
||
| HY5wR-12.7/45 | set | |||
| HY5WR-42/134 | set | |||
| HY2.5WD-3.8/9.5 | set | Motor | ||
| HY2.5WD-7.6/19 | set | |||
| HY2.5wS-12.7/31 | set | |||
| HY5WS-5/15 | set | Power distribution | ||
| HY5wS-10/30 | set | |||
| HY5wS-17/50 | set | |||
| HY5wS-5/13.5 | set | Power Station | ||
| HY5WZ-10/27 | set | |||
| HY5WZ-17/45 | set | |||
| HY5WZ-51/134 | set | |||
| set | ||||
| HY5WR-5/13.5 | set | Parallel compensation capacitor bank |
||
| HY5WR-10/27 | set | |||
| HY5WR-17/45 | set | |||
| HY5WR-51/134 | set | |||
| HY1.5W-0.28/1.3 | set | Low voltage | ||
| HY1.5W-0.5/2.6 | set | |||
| HY5WD-4/9.5 | set | Generator | ||
| HY5WD-8/18.7 | set | |||
| HY5WD-13.5/31 | set | |||
| HY5WD-17.5/40 | set | |||
| HY5wD-20/45 | set | |||
| HY5WD-23/51 | set | |||
| HY5WD-25/56.2 | set | |||
| HY2.5WD-4/9.5 | set | Electric motor | ||
| HY2.5WD-8/18.7 | set | |||
| HY2.5WD-13.5/31 | set | |||
| HY1.5WD-2.4/6 | set | Motor neutral point |
||
| HY1.5D-4.8/12 | set | |||
| HY1.5D-8/19 | set | |||
| HY1.5D-10.5/23 | set | |||
| HY1.5D-12/26 | set | |||
| HY1.5D-13.7/29.2 | set | |||
| HY1.5D-15.2/31-7 | set | |||
| HY5D-42/120 | set | Electric Iron | ||
| HY5D-84/220 | set |
