Fast-Response Ceramic Pressure Sensors for Gas Flow Applications
10-999 Pieces
$521000-2999 Pieces
$263000-5999 Pieces
$236000 Pieces
$22Product information
High-quality Fast-Response Ceramic Pressure Sensors for Gas Flow Applications supplied by AIoTSensing Inc.. Bulk wholesale pricing ranges from $22 to $52 per Pieces with a minimum order of 10 Pieces. Inquiry for latest prices.
Temperature:
-40°C ~ +85°C
Response Time:
0.5ms
Production Capacity:
10000/Month
Specification:
12.5*9.9*11.7mm
Output:
14bit,I2c/Spi
Package Gross Weight:
2.000kg
Nozzle Dia:
3.5mm
Package Size:
40.00cm * 37.00cm * 7.00cm
Specifications
Temperature:
-40°C ~ +85°C
Response Time:
0.5ms
Production Capacity:
10000/Month
Specification:
12.5*9.9*11.7mm
Output:
14bit,I2c/Spi
Package Gross Weight:
2.000kg
Nozzle Dia:
3.5mm
Package Size:
40.00cm * 37.00cm * 7.00cm
Lead Time:
5 days (1 - 10 Pieces)7 days (11 - 100 Pieces)35 days (101 - 3000 Pieces)To be negotiated ( > 3000 Pieces)
Transport Package:
72PCS/Reel
HS Code:
90269000
Trademark:
AIoT
Model NO.:
AS1318C
Model No.:
As1318c-002ND5ai-Dsd
Material:
Ceramics
Refund Policy:
Claim a refund if your order doesn't ship, is missing, or arrives with product issues.
Shipping Cost:
Contact the supplier about freight and estimated delivery time.
Customized:
Customized
Packaging:
DIP8
Output Signal Type:
Digital Type
Trade Term:
FOB, CIF, CFR, EXW
Measuring Medium:
Gas
Origin:
Hefei
Wiring Type:
Iic
Payment Term:
LC, T/T, PayPal, Western Union, Small-amount payment
Production Process:
Mems
Thread Type:
No Screw
Port Of Loading:
Shanghai Port
For:
Strain Gauge Pressure Transmitter
Payment Methods:
Support payments in USD
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
2019-09-12
Annual Revenue Amount:
Not specified
Numbers Of Employees:
45
Preferred Payment Term:
LC, T/T, PayPal, Western Union, Small-amount payment
Preferred Trade Term:
FOB, CIF, CFR, EXW
Port Of Loading:
Shanghai Port
Certificates:
ISO14001, Others, ISO45001:2018
Product descriptions from the supplier
SONA2024 2.2.1
Ceramic board Differential pressure sensor
AS1318C Series
Specification
AS1318C-002ND5AI-DSD
Specification
Specification
Gauge pressure:±2inH2O
Power supply: 5V
IIC output
14bit AD Output
Nonlinear±0.25%FSS
TEB±1%FSS@(0~70°C)
Size: 12.5*9.9*11.7mm
Size: 12.5*9.9*11.7mm
DIP8; Side double port
AS1318C CERAMIC BOARD MOUNT DIGITAL OUTPUT PRESSURE SENSOR
Standard Pressure Ranges ±125 Pa to ±1 MPa
Pressure | Pressure Range | Pressure Pmin | Pressure Pmax | Unit | Over Pressure | Burst Pressure | Common Mode Pressure | TEB (%FSS) |
Absolute | 100KA | 0 | 100 | kPa | 200 | 400 | - | ±1% |
160KG | 0 | 160 | kPa | 400 | 800 | - | ±1% | |
250KA | 0 | 250 | kPa | 600 | 800 | - | ±1% | |
400KA | 0 | 400 | kPa | 800 | 1600 | - | ±1% | |
600KA | 0 | 600 | kPa | 1700 | 1700 | - | ±1% | |
001GA | 0 | 1 | MPa | 1700 | 1700 | - | ±1% | |
Differential | 125LD | -125 | 125 | Pa | 67500 | 100000 | 345000 | ±3% |
160LD | -160 | 160 | Pa | 67500 | 100000 | 345000 | ±2.5% | |
250LD | -250 | 250 | Pa | 67500 | 100000 | 345000 | ±2% | |
400LD | -400 | 400 | Pa | 67500 | 100000 | 345000 | ±1.5% | |
600LD | -600 | 600 | Pa | 67500 | 100000 | 345000 | ±1% | |
001KD | -1 | 1 | kPa | 75 | 125 | 545 | ±1% | |
1.6KD | -1.6 | 1.6 | kPa | 75 | 125 | 545 | ±1% | |
... | ||||||||
Gage | 250LG | 0 | 250 | Pa | 67500 | 100000 | 345000 | ±3% |
400LG | 0 | 400 | Pa | 67500 | 100000 | 345000 | ±2% | |
... |
Pressure range ±0.5 inH2O to ±150 psi |
.. |
Applications
• Medical Equipment
• Industrial Controls
• HVAC
• Environmental Controls
• Air flow
• HVAC
• Environmental Controls
• Air flow
Packing & Delivery
For sample: 5-7 days
Lead time for mass production: 35 days.
Standard Export Pack:
Accept customized Services:
72 Pieces/Reel, then packed in carton.
OEM Service
After Sales Service
12-month warranty
Online guidance
Company Profile
AIoTSensing Inc.
In September 2019, the company was founded by the Founder Alex Bao, who led a group of core technology experts
and outstanding management talents from the sensor business units of Fortune 500 companies, well-known American
MEMS sensor companies, and A-share listed companies whose main business is sensors to establish AIoTSensing Inc
The company has invested approximately 60 million RMB, with investors including A-share listed company Founder Fire,Hefei High-tech Investment, and French FORVIA HELLA Automotive, etc.
In September 2021, it was recognized as a National High-Tech Enterprise and passed the re-examination in 2024;
Hefei - MEMS Air Pressure Sensor R&D and Manufacturing Center: It has more than 150 sets of MEMS sensor
packaging, calibration, and testing equipment, a 1600m² anti-static clean workshop, and a MEMS barometric pressure
sensor packaging and calibration capacity of 15 million pieces/year.
Hangzhou - MEMS Hydraulic Pressure Sensor R&D and Manufacturing Center: Hangzhou AIoTSensing Inc. was
established in July 2024 with a registered capital of 30 million RMB; a key introduction project in Hangzhou in 2024; a
new 3500m² anti-static clean workshop was put into operation in 2024, with the goal of building a MEMS hydraulic
pressure sensor assembly line with a production capacity of 5 million pieces/year.
Passed IATF16949 automotive quality system certification; Sale service network in United States, Japan, South Korea,Italy, Germany, Beijing, Shanghai, Shenzhen, Hangzhou, Qingdao, Chengdu etc.
and outstanding management talents from the sensor business units of Fortune 500 companies, well-known American
MEMS sensor companies, and A-share listed companies whose main business is sensors to establish AIoTSensing Inc
The company has invested approximately 60 million RMB, with investors including A-share listed company Founder Fire,Hefei High-tech Investment, and French FORVIA HELLA Automotive, etc.
In September 2021, it was recognized as a National High-Tech Enterprise and passed the re-examination in 2024;
Hefei - MEMS Air Pressure Sensor R&D and Manufacturing Center: It has more than 150 sets of MEMS sensor
packaging, calibration, and testing equipment, a 1600m² anti-static clean workshop, and a MEMS barometric pressure
sensor packaging and calibration capacity of 15 million pieces/year.
Hangzhou - MEMS Hydraulic Pressure Sensor R&D and Manufacturing Center: Hangzhou AIoTSensing Inc. was
established in July 2024 with a registered capital of 30 million RMB; a key introduction project in Hangzhou in 2024; a
new 3500m² anti-static clean workshop was put into operation in 2024, with the goal of building a MEMS hydraulic
pressure sensor assembly line with a production capacity of 5 million pieces/year.
Passed IATF16949 automotive quality system certification; Sale service network in United States, Japan, South Korea,Italy, Germany, Beijing, Shanghai, Shenzhen, Hangzhou, Qingdao, Chengdu etc.
