Ridge Cap Making Machine Roof Ridge Cap Forming Machine Roof Ridge Cap Roll Forming Machine
Piece
Negotiable
Product information
High-quality Ridge Cap Making Machine Roof Ridge Cap Forming Machine Roof Ridge Cap Roll Forming Machine supplied by Cangzhou Zhongkuo Cold Bending Forming Equipment Co., Ltd.. Bulk wholesale pricing is negotiable. Inquiry for latest prices.
Worker:
1 Only
Forming Speed:
10-20m/Min
Production Capacity:
30sets/Month
Voltage:
380V or Customized
Hydraulic Station:
4kw
Motor:
4kw
Weight:
5 Tons
HS Code:
8455221000
Specifications
Worker:
1 Only
Forming Speed:
10-20m/Min
Production Capacity:
30sets/Month
Voltage:
380V or Customized
Hydraulic Station:
4kw
Motor:
4kw
Weight:
5 Tons
HS Code:
8455221000
Origin:
Botou
Certification:
CE, ISO, TUV, SGS, ISO9001
Tile Type:
Colored Steel
Customized:
Customized
Trade Term:
FOB, CIF, CFR, EXW
Transmission Method:
Hydraulic Pressure
Payment Term:
LC, T/T, D/P, PayPal, Small-amount payment, Western Union
Type:
Metal Roofing Sheet Roll Forming Machine
Condition:
New
Usage:
Roof, Wall, Floor, Frame
Transport Package:
Standard Export Package
Port Of Loading:
Tianjin Port
Trademark:
ZHONGKUO
Specification:
customize
Business Details
Country:
China
Business Types:
Not specified
Main Markets:
Not specified
Main Products:
Year Established:
2023-01-06
Annual Revenue Amount:
Not specified
Numbers Of Employees:
8
Preferred Payment Term:
LC, T/T, D/P, PayPal, Small-amount payment, Western Union
Preferred Trade Term:
FOB, CIF, CFR, EXW
Port Of Loading:
Tianjin Port
Certificates:
CE
Product descriptions from the supplier
Color steel Ridge Capping Cold Roll Forming Machine Metal Roof Ridge Cap making Machine
| R Panel Roll Forming Machine Hot Sale To America | |
| Raw Material | PPGI,PPGL |
| Material Thickness:24/26 Gauge (0.4-0.6 Mm) | |
| Machine Frame | 350mm H Beam Structure, With 18mm Welded Steel Middle Support Plate. |
| Material Of Rollers | High Grade 45# Forged Steel |
| Chromed Treatment (Chrome Thickness:0.05 Mm), Make The Rollers Surface More Smoothly, Improve The Hardness And PreventAbrasion,Anti Corrosion Increase Of Service Life. | |
| Forming Stations | Roller Stations :18 Rows |
| Rolling Type: Separate Rolling Design Concept, It Can Release Internal Stress From The Sheets, Then The Sheet Will Be In Good Shape And High Precision. | |
| Diameter Of Shafts | Φ80mm Solid |
| Material Of Shafts | High Grade 45#,With Heat Treatment |
| Forming Speed | 15 M/Min |
| Voltage | 380v/50hz/3p (As Requested) |
| Transmission Way | By 1 Inch Chain (Double Chains) |
| Main Motor | 11 kw |
| Cutting Blade Material | Gcr12 quenched treatment |
| Cutting Type | hydraulic post cutting |
| Driving Method | By pillar type Cylinder |
 |
Hydraulic Cutting Device 1.Work type:hydraulic servo track cutting servo motor 5.5KW 2.Driving method:By pillar type Cylinder 3.Hydraulic motor power:4 kw 4.Cutter material :GB-Cr12 with heat treatment 5.Cutting length tolerance ±10m/2mm |
| Roll Forming And Transmission Device 1.rollers thick chromed good hardness for long service time. 2. Each roller has number and with keynotes, it can fix on the shaft stablely 3.gear and double chain,stable |
 |
 |
Feeding Device 1.Hand wheels on both sides can be used to adjust the feeding width. 2.Four stainless rollers can make the material go into the machine smoothly and prevent the scratch on the material surface. 3.There are three rows of orange plastic rollers can make the steel coil go into the machine smoothly. |
| PLC control system PLC brand:Delta(Taiwan) PLC, and transducer and touched screen Encoder brand:Omron Electrical components:Schneide r Operating language:English and Chinese(or as requested) You can set the orders on this part,changing product length and quantity,it is really easy to operate,and there are aviation plugs to make it much easier to install the machine while it arrived. |
 |
 |
5T Manual Decolier For Free Capacity:5 tons Coil inner diameter:450-550mm Feeding width: max 1220mm Structure: welded by the steel plates and profiled bar. The shrink and expand of core is manually, with manual brake,The coil moving forward or reverse is pulled by roll forming machine |
| Hydraulic station Hydraulic station motor:5.5KW Hydraulic oil:46# hydraulic oil Main components:Include a set of hydraulic tank, a set of hydraulic oil pump, two hydraulic pipes. And one of electromagnetism valve |
 |
FAQ
Q1. What's your payment terms and delivery time?
A1: 30% as the deposit by T/T in advance, 70% as the balance payment by T/T after your inspect the machine well and before delivery. Of course your payment terms are acceptable.
After we get down payment, we will arrange production. About 30-45 days for delivery.
Q2. Do you have after-sales support?
A2: Yes, we are happy to provide advice and we also have skilled technicians available across the world.
Q3. Do you sell only standard machines?
A3: No, most of our machines are built according to customers specifications, using top brand components.
Q4. What will you do if the machine is broken?
A4: We provide 18 months free warranty and free technical support for the whole life of any machine.
If the broken parts can't repair, we can send the new parts replace the broken parts freely, but you need pay the express cost by yourself. If it is beyond the warranty period, we can negotiate to solve the problem, and we supply the technical support for the whole life of the equipment.
Q5. Can you be responsible for transport?
A5: Yes, please tell me the destination port or address. we have rich experience in transporting.
Q6. How to visit your company?
A6: 1) Fly to Beijing airport, By high speed train From Beijing Nan to Cangzhou Xi (1 hour).
2) Fly to Shanghai Airport: By high speed train From Shanghai Hongqiao to Cangzhou Xi(4.5 hours), then we can pick up you.
