1000c Calcium Silicate Thermal Insulation Board N14/N17
|
25 views
2000 Kilogram
$1.2MOQ:
2000 Kilogram
Payment Term:
D/P, L/C, T/T
Trade Term:
CFR, CIF, CIP, CPT, DAT, EXW, FAS, FCA, FOB
Port Of Loading:
Qingdao port
Key Takeaways
Freshdi AI is analyzing this product...
1000C Thermal Insulation Board Supplier
High-Temperature Insulation Board Wholesale
HCS-20 HCS-25 Thermal Insulation Board
Product Specifications
Thermal Conductivity:
0.06–0.12 W/m·k
Thermal Conductivity High Density:
0.09–0.18 W/m·k
Maximum Operating Temperature:
1100°c
Density:
170–270 Kg/m³
High Density Density:
850–1200 Kg/m³
Grade:
A1
Place Of Origin:
China
Reinforcement Material:
Glass Or Carbon Fibers
Type:
HCS-20/HCS-23/HCS-25/HCS-27
Feature:
Heat resistant up to 1000℃
Thermal Shock Resistance:
High
Base Components:
High-purity Quartz, Lime
Insulation Type:
High-temperature
Application:
Industrial Furnaces, Kilns, Boilers, Duct Insulation, Heat Treatment Furnaces, Steel Reheating Furnaces, Glass Regenerators, Cement Preheaters, Power Plant Ducts, Launders, Spouts, Hot-top Rings, End Dams, Furnace Lids
Dimensional Stability:
Maintained Up To 1100°c
Comparable International Grades:
Marinite A, N-14, M1a
Structure:
Needle-like Porous Xonotlite Crystal Network
Compressive Strength:
Up To 5 Mpa
Crystal Structure:
Xonotlite
Cnc Machinability:
Yes
Asbestos Free:
Yes
Non Wettable To Molten Aluminum:
Yes
Chemical Inertness:
Yes
Electrical Insulation:
Yes When Dry
Address:
lzmfgr1@gmail.com
Color:
white
Product Certificates
4.1
China
1 yrs
Exporter/Wholesaler
Wenquan East Street, Laizhou City, Shandong Province, China
Activity signals
Avg Response Time
≤ 4 days
Response Rate
3%
Inquiry Open Rate
69%
Total inquiries received
29
Export Markets
Based on the information provided by the supplier.
United States
Germany
China
United Kingdom
Canada
North America
33%
Western Europe
33%
East Asia
17%
Oceania
17%
Verification information
Verify business documents
By Freshdi Verification System
Verify phone number
Buyer Verification Team
Verify account email
By Freshdi.com
Verify work email
Product descriptions from the supplier
Calcium silicate board is a high-temperature insulation material widely used in industrial furnaces, kilns, and boilers. Made primarily from xonotlite crystals and reinforced fibers, it combines excellent thermal insulation, mechanical strength, and dimensional stability under severe heat exposure. Unlike flexible materials such as ceramic fiber, calcium silicate board serves as both an insulator and a structural support layer, providing lasting performance and energy efficiency in demanding thermal environments.
1. Composition and Microstructure Firebird’s calcium silicate boards are composed of high-purity quartz (SiO₂), lime (CaO), and glass or carbon fibers as reinforcement. During production, these materials undergo a hydrothermal synthesis process inside a pressure vessel, forming xonotlite crystals (Ca₆Si₆O₁₇(OH)₂) — a needle-like, porous structure.
This xonotlite structure creates a network of microscopic hollow spheres and channels that:
• Trap air for excellent thermal insulation
• Maintain rigidity under load
• Resist thermal shock and cracking
• Remain dimensionally stable up to 1100°C
The boards are 100% asbestos-free, chemically inert, and electrically insulating when dry, making them safe and sustainable for industrial use.
2. Available Grades and Types
Mingfa produces multiple grades of calcium silicate boards to serve different industries and installation needs.
(1) Standard Grade – 1000°C Series
Density: 170–270 kg/m³
Thermal conductivity: 0.06–0.12 W/m·K
Typical use: boiler walls, kiln linings, duct insulation, heat treatment furnaces
(2) High-Temperature Grade – 1100°C Series
Density: 250–500 kg/m³
Compressive strength: up to 5 MPa
Used in: steel reheating furnaces, glass regenerators, cement preheaters, and power plant ducts
(3) High Density Calcium Silicate Board
Density: 850–1200 kg/m³
Thermal conductivity: 0.09–0.18 W/m·K
Features: non-wettability to molten aluminum, high thermal shock resistance, CNC machinability
Applications: launders, spouts, hot-top rings, end dams, furnace lids
Comparable to international grades such as Marinite A, N-14, and M1A, Mingfa HD boards deliver strength and stability in environments where other insulations cannot survive.
