API6D API608 ISO BS DIN Manual Oil Industrial Cryogenic Ball Valve Suitable for Oxyogen Liquid Bola Valvulas
Piece
$300MOQ:
1 Piece
Payment Term:
L/C, Money Gram, Other, PayPal, T/T
Trade Term:
CFR, CIF, EXW, FOB
Port Of Loading:
Ningbo, China, Cn (NGB/NIB/NIN)
Key Takeaways
Freshdi AI is analyzing this product...
Working Temperature -46℃ to +200℃
Double Block and Bleed Safety
Anti-static Design for Oxygen Systems
Product Specifications
Working Temperature Product Range:
-196℃ - +573℃
Working Temperature:
-46℃ - +200℃
Working Temperature Range:
-46℃ - +200℃
Normal Diameter:
1/2 - 4 Inch (dn15 - Dn100)
Size Range:
1/2" - 48"
Pressure Range Product Range:
150 - 2500 Lb (pn16 - Pn420)
Normal Diameter Product Range:
2 - 60 Inch (dn50 - Dn1500)
Nominal Size Example:
20 Inch
Nominal Class Example:
600 Lb
Hs Code:
84818040
Anti Blow Out Feature:
Anti-blow Out Stem
Anti Static Design:
Anti-static Design
Test And Inspection Standard Top Entry:
Api 598
Design Standard Api:
Api 6d
Standard:
Api 6d
Face To Face Dimension:
As Per Asme B16.10
Face To Face Dimension Top Entry:
As Per Asme B16.10
Ball And Stem Material:
Astm A182 F316
Body Material:
Astm A216 Wcb, Carbon Steel, Stainless Steel, Alloy Steel, Duplex Stainless Steel, B61, B62, Copper, Wcb, Lcb, Lcc, Wcc, Wc5, C5, Wc6, Wc9, Wc11, Cf8, Cf8m, Cf3, Cf3m, Cd-4mcu, Ss2205
Body Material Alternative:
Astm A351 Cf8m
Product Name:
Ball Valves
Hand Lever Color:
Blue Ral 5005 As Client’s Requirements
Painting Specification:
Body/bonnet (silver, Grey, Dark Grey), Painting Min. 110μm – Ral 9006 Or As Client’s Requirements
End Connection Type:
Bw, Flanged
End Connection Product Range:
Bw, Flanged
Body Material Product Range:
Carbon Steel, Stainless Steel, Alloy Steel
Body Material Top Entry:
Carbon Steel, Stainless Steel, Alloy Steel, Duplex Stainless Steel, B61, B62, Copper, Wcb, Lcb, Lcc, Wcc, Wc5, C5, Wc6, Wc9, Wc11, Cf8, Cf8m, Cf3, Cf3m, Cd-4mcu, Ss2205
Pressure Class:
Class 800lb, 150lb, 300lb, 600lb, 900lb, 1500lb, 2500lb
Nominal Size:
Dn15 - Dn500
Double Block And Bleed:
Double Block And Bleed
Test And Inspection Standard:
En 12266-1
Design Standard:
En 12516-1
Face To Face Standard:
En 558-1/14
Fire Safety:
Fire Safe
End Connection:
Flanged Rf
Valve Type:
Full Bore, Reduced Bore, 2-pc Type, 3-pc Type
Ball Valve Type:
Full Bore, Reduced Bore, Trunnion Mounted Ball, Floating Ball Type
Operation Method:
Lever Type, Gear Operated, Electric Actuator, Pneumatic Actuator, Hydraulic Actuator
Nominal Class:
Pn10 - Pn100
Pressure Range:
Pn10 - Pn100
Seat Material:
Ptfe, Rptfe, Peek, Ppl, Metal Seat
End Connection Alternative:
Rf Flange
End Connection Top Entry:
Rf Flange, Bw Connection
Entry Type:
Side Entry
Ball Type:
Solid Ball, Hollow Ball
Material:
Stainless Steel, carbon steel
Top Entry Valve:
Top Entry Ball Valve
4.4
China
Exporter/Wholesaler
Heyi industrial zone oubei yongjia wenzhou city zhejiang province China
Activity signals
Inquiry Open Rate
91%
Total inquiries received
11
Inquiries Read
10
Number of Employees
11-50 employees
Export Markets
Based on the information provided by the supplier.
Uruguay
United Arab Emirates
Ukraine
Venezuela, Bolivarian Republic of
Zambia
South America
27%
Eastern Europe
23%
Middle East
20%
Western Europe
17%
Southeast Asia
13%
Verification information
Verify business documents
By Freshdi Verification System
Verify work email
By Freshdi.com
Verify phone number
Buyer Verification Team
Verify account email
By Freshdi.com
Product descriptions from the supplier
:Ball valve, API 6D, Full Bore, Reduced bore,Trunnion Mounted Ball,Floating ball type,
Anti-blow out stem, fire safe, anti-static design,Double block&bleed.
Side entry,
Name: Ball Valves.
Type: Full Bore, Reduced bore,2-PC type,3-PC type.
Size: 1/2"-48”.
Pressure Class: CLASS 800LB, 150LB, 300LB,600LB,900LB,1500LB, 2500LB
Body Material: ASTM A216 WCB. Carbon Steel, Stainless Steel, Alloy Steel.duplex stainless steel.B61,B62,copper,WCB,LCB,LCC,WCC,WC5,C5,WC6,WC9,WC11,CF8,CF8M,CF3,CF3M,CD-4MCU,SS2205
etc.
Ball and Stem Material: ASTM A182 F316.
Ball Type: Solid Bal,Hollow ball
Seat: PTFE,RPTFE,PEEK,PPL,Metel seat.
Working temperature: -46℃ - +200℃.
HS Code: 84818040
Ends: Flanged RF.
Operation: Lever type,Gear Operated.electric actuator, pneumatic actuator,hydraulic actuator etc.
Standard: API 6D.
Flanged according RF – as per AMSE B16.5
Face to face dim. As per ASME B16.10
Painting:Body/Bonnet (silver,grey,dark grey), painting min. 110μm – RAL 9006 or as clinet’s requirements.
Hand lever (blue RAL 5005)as clinet’s requirements.
DIN 3202 F4 ball valve, short patern
Design: EN 12516-1.
Body:ASTM A216WCB, ASTM A351 CF8M.
Nominal size: DN15-500
Nominal class: PN10-PN100.
End Connection: RF flange.
Face to face: EN 558-1/14.
Test and inspection: EN 12266-1.
Operation: Lever type,Gear Operated.electric actuator, pneumatic actuator,hydraulic actuator etc.
Product Range:
Body material: Carbon Steel, Stainless Steel, Alloy Steel.B61,B62,copper,WCB,LCB,LCC,WCC,WC5,C5,WC6,WC9,WC11,CF8,CF8M,CF3,CF3M,CD-4MCU,SS2205 etc.
Normal diameter: 1/2 - 4 Inch (DN15 - DN100).
End connection: BW, Flanged.
Pressure range:PN10 - PN100.
Working temperature: -46℃ - +200℃.
Top entry ball valve.
Design: API 6D.
Body: Carbon Steel, Stainless Steel, Alloy Steel.duplex stainless steel.B61,B62,copper,WCB,LCB,LCC,WCC,WC5,C5,WC6,WC9,WC11,CF8,CF8M,CF3,CF3M,CD-4MCU,SS2205
etc.
Nominal size: 20 Inch.
Nominal class: 600 LB.
End Connection: RF flange.BW connection
Operation: Lever type,Gear Operated.electric actuator, pneumatic actuator,hydraulic actuator etc.
Face to face: as per ASME B16.10.
Test and inspection: API 598.
Product Range：
Body material: Carbon Steel, Stainless Steel, Alloy Steel.
Normal diameter: 2 - 60 Inch (DN50 - DN1500).
End connection: BW, Flanged.
Pressure range: 150 - 2500 LB (PN16 - PN420).
Working temperature: -196℃ - +573℃.
