CNC Machined Levers with Hardened Treatment
|
5 views
|
1 Inquiries
10 Piece
$8MOQ:
10 Piece
Payment Term:
T/T
Trade Term:
CIF, DDP, EXW, FOB
Port Of Loading:
Port of Shenzhen
Key Takeaways
Freshdi AI is analyzing this product...
CNC Machined Levers High Tensile Strength
Hardened Alloy Steel Levers -40 to 300°C
Precision Pivot Hole Levers for Machinery
Product Specifications
Operating Temperature Range:
-40°C To 300°C
Operating Temperature:
-40°c To 300°c
Processing Capabilities:
3/4-axis CNC Precision Milling/turning, Drilling (precision Mounting Holes), Tapping (M6–M24 ISO 6g Threads), Slotting (for Lever Pivot Connections), Chamfering, Deburring; Surface Grinding (flatness Calibration For Pressure Plates); 100% CMM Dimensional Inspection; Hardness Testing (Rockwell Scale); Load-bearing Performance Verification, 3/4-axis Cnc Precision Milling/turning, Drilling (precision Mounting Holes), Tapping (m6–m24 Iso 6g Threads), Slotting (for Lever Pivot Connections), Chamfering, Deburring, Surface Grinding (flatness Calibration For Pressure Plates), 100% Cmm Dimensional Inspection, Hardness Testing (rockwell Scale), Load-bearing Performance Verification
Material:
Alloy Steel (4140/4340), Steel
Compatibility:
Fits Forging Presses, Stamping Machinery, Industrial Automation Clamping Systems, Agricultural Equipment, And Construction Machinery; Compatible With Mounting Brackets, Pivot Shafts, Hydraulic Pistons, And Linkage Mechanisms
Further Treatment:
Grinding, Hardening
Batch Size:
Individual Parts, Large Batches, Medium Batches, Prototypes, Small Batches
Workpiece Dimensions:
Medium, Small
Hardening Treatment:
Quenching + Tempering (core Hardness 28–32 HRC For Toughness) + Surface Nitriding (surface Hardness ≥650 HV For Wear Resistance); Or Induction Hardening (local Hardness Up To 58–62 HRC For Stress-bearing Areas); Meets Industrial Machinery Material Strength Standards. Deburred Edges (prevents Machinery Jamming And Operator Injury), Quenching + Tempering (core Hardness 28–32 Hrc For Toughness) + Surface Nitriding (surface Hardness ≥650 Hv For Wear Resistance); Or Induction Hardening (local Hardness Up To 58–62 Hrc For Stress-bearing Areas); Meets Industrial Machinery Material Strength Standards
Surface Roughness:
Ra 0.4–1.6μm
Dimensional Tolerance:
±0.01–±0.03mm
Lever Pivot Hole Concentricity:
≤0.008mm
Hole Position Tolerance:
≤0.02mm
Pressure Plate Flatness:
≤0.02mm/m
Load Capacity:
≤100 Tons, ≤100 Tons (customizable For Heavy-duty Applications)
Yield Strength:
≥700 MPa, ≥700 Mpa
Tensile Strength:
≥850 MPa, ≥850 Mpa
4.4
China
1 yrs
Exporter/Wholesaler, Non-food manufacturing, Others
101, No68, Ditangshan Road 2, Dalingshan Town, 523821,Dongguan, Guangdong, China
Activity signals
Avg Response Time
≤ 5 days
Response Rate
5%
Inquiry Open Rate
95%
Total inquiries received
19
Export Markets
Based on the information provided by the supplier.
Germany
Sweden
Hungary
Denmark
Australia
Western Europe
43%
Eastern Europe
29%
North America
14%
Oceania
14%
Verification information
Verify business documents
By Freshdi Verification System
Verify work email
By Freshdi.com
Verify phone number
Buyer Verification Team
Verify account email
By Freshdi.com
Product descriptions from the supplier
High-strength hardened alloy steel pressure plates and precision CNC-machined levers, engineered for heavy-load bearing, wear resistance, and mechanical transmission stability—ideal for industrial machinery, hydraulic systems, and automation equipment.
ParameterKey Details
Material
Alloy Steel (4140/4340): High tensile strength, excellent hardenability; base material for pressure plates and levers requiring heavy-load performance.
Processing Capabilities
3/4-axis CNC precision milling/turning, drilling (precision mounting holes), tapping (M6–M24 ISO 6g threads), slotting (for lever pivot connections), chamfering, deburring; surface grinding (flatness calibration for pressure plates); 100% CMM dimensional inspection; hardness testing (Rockwell scale); load-bearing performance verification
Tolerance & Precision
Dimensional tolerance ±0.01–±0.03mm; pressure plate flatness ≤0.02mm/m; lever pivot hole concentricity ≤0.008mm; hole position tolerance ≤0.02mm; surface roughness Ra 0.4–1.6μm (smooth contact surface to reduce friction); strict alignment with customer CAD/STEP drawings
Surface Finish & Post-Treatment
Hardening Treatment: Quenching + tempering (core hardness 28–32 HRC for toughness) + surface nitriding (surface hardness ≥650 HV for wear resistance); or induction hardening (local hardness up to 58–62 HRC for stress-bearing areas); meets industrial machinery material strength standards. deburred edges (prevents machinery jamming and operator injury)
Mechanical & Operational Properties
Tensile strength ≥850 MPa (4140 alloy steel post-hardening); yield strength ≥700 MPa; operating temperature -40°C to 300°C; load capacity ≤100 tons (customizable for heavy-duty applications); fatigue resistance ≥10⁷ cycles (suitable for continuous mechanical transmission); compatible with hydraulic cylinders, pneumatic actuators, and gear systems
Compatibility
Fits forging presses, stamping machinery, industrial automation clamping systems, agricultural equipment, and construction machinery; compatible with mounting brackets, pivot shafts, hydraulic pistons, and linkage mechanisms
