Insulation Calcium Silicate Board 100mm Density 230kgm3 for Furnace Backup Lining Fireproof Thermal Barrier Rigid Panel
|
12 views
1 Box
$40MOQ:
1 Box
Payment Term:
L/C, T/T, W/U
Trade Term:
CFR, CIF, EXW, FCA, FOB
Port Of Loading:
Qingdao PORT
Key Takeaways
Freshdi AI is analyzing this product...
Calcium Silicate Board 1100C Furnace Lining
High-Temp Insulation Board 400C Thermal Barrier
230kgm3 Compressive Strength Calcium Silicate Panel
Product Specifications
Density:
230±10 Kg/m3, 230±10 Kg/m³
Maximum Operating Temperature:
650°-1050°
Use Temperature:
650°c
Continuous Operating Temperature Range:
650°c To 1100°c
Operating Temperature Range:
650°c To 1100°c
Application:
Cave Dwelling Inside For Insulation, Inner Of Brick, Cave Dwelling Wall Outside, Fireplace, Oven, Boiler, Furnace, Oven Outside, Glass, Brick, Ceramic, Cement Factory Area, Cave Dwelling Inside For Insulation, Inner Of Brick, Cave Dwelling Wall Outside; Different Fireplace, Oven, Cave Dwelling, Outside; Different Boiler, Furnace, And Oven's Outside For Heat Insulation In Glass, Brick, Ceramic, Cement Factory Area; Reheating Furnace, Annealing Furnace, Transfer Ladle, Rotary Kiln, Glass Tank Dip Tubes And Spouts Nozzles, Shuttle Kiln, Tunnel Kiln, Aluminum Melting And Holding Furnace, Distribution Boxes, Flow Gates, Hot Pipe Supports, Other High Temperature Ovens Or Heat Processing Equipment; Ceiling, Fireproof And Heat Insulation Materials Of Wall, Sound Absorption Materials Of Decoration
Place Of Origin:
China
Intended Use:
Heat Insulation And Fire Resistant In Industrial And Building Applications
Feature:
Heat resistant up to 1000℃
Certification:
ISO9001-2015
Material Composition:
Made Of Sio2 And Cao With Environmental Protection Fiber
Shape:
bulk solid
Packaging:
pallet
Thermal Conductivity At 100°C:
≤0.05 W/(m.k)
Thermal Conductivity At 200°C:
≤0.06 W/(m.k)
Thermal Conductivity At 300°C:
≤0.071 W/(m.k)
Thermal Conductivity At 400°C:
≤0.079 W/(m.k)
Flexural Strength:
≥0.42 Mpa
Compressive Strength:
≥0.5 Mpa
Product Certificates
4.1
China
1 yrs
Exporter/Wholesaler
Wenquan East Street, Laizhou City, Shandong Province, China
Activity signals
Avg Response Time
≤ 4 days
Response Rate
3%
Inquiry Open Rate
69%
Total inquiries received
29
Export Markets
Based on the information provided by the supplier.
United States
Germany
China
United Kingdom
Canada
North America
33%
Western Europe
33%
East Asia
17%
Oceania
17%
Verification information
Verify business documents
By Freshdi Verification System
Verify phone number
Buyer Verification Team
Verify account email
By Freshdi.com
Verify work email
Product descriptions from the supplier
Product Description Calcium silicate board products are made of SIO2 and CAO through high temperature and high pressure reaction, adding environmental protection fiber, new energy-saving insulation material without asbestos, the product can be long-term use in 650°-1050° high temperature environment, extend the service life of equipment Technical Specification Density 230±10 kg/m3 Compressive strength ≥0.5Mpa Flexural strength ≥0.42Mpa Thermal conductivity 100ºC ≤0.05 W/(M.K)
200ºC ≤0.06 W/(M.K)
300ºC ≤0.071 W/(M.K)
400ºC ≤0.079 W/(M.K) The use of temperature 650ºC Application 1.cave dwelling inside for insulation, inner of brick , cave dwelling wall outside. for heat insulation and fire resistant.
2.different fireplace, oven, cave dwelling, outside for heat insulation and fire resistant.
3. different boiler, furnace, and oven's outside for heat insulation in glass, brick, ceramic, cement factory area
Product Description Product Description
Heat Insulation Material Calcium Silicate Board
Calcium silicate board is an asbestos-free thermal insulation product that can withstand continuous operating temperature from 650C up to 1100C. It is light weight, low thermal conductivity, high strength, easy to install, reliable and durable. There are 2 grades available namely 650 & 1000 & 1100 which are commonly used as furnace backup insulation in steel, petrochemical, ceramic, cement & glass industry or fire protection in building construction. It not only provides energy saving, also increases production efficiency and gives personnel protection in industrial safety aspect. And in the housing construction Calcium Silicate Board is also used as the ceiling, fireproof and heat insulation materials of wall and sound absorption materials of decoration.
Calcium Silicate Board Typical Application
Reheating furnace - Annealing furnace - Transfer ladle - Rotary kiln - Glass tank Dip tubes and spouts Nozzles - Shuttle kiln - Tunnel kiln - Aluminum melting and holding furnace - Distribution boxes, Flow gates Hot pipe supports - Other high temperature ovens or heat processing equipments
1. What kind of product can you offer?
Our company can offer industrial refractory insulation materials. For example: Ceramic Fiber Products, Soluble Fiber Products, Fiberglass Products, Calcium Silicate Products, Mineral Wool, Rock Wool, Insulating Firebricks Etc.
2. Can you provide free samples?
Free samples are available!
3. What is your MOQ?
We don't have particular MOQ, we can accept any order for any different projects.
Price depends on quantity.
4. Can we have a visit to your factory?
Yes! Of course, welcome to visit our factory at anytime!
